Manual

Normal Operating Sounds

• You may hear faint gurgling or bubbling sounds

when the refrigerant is pumped through the coils

or tubing at the rear, to the cooling

plate/evaporator or to the fixed freezer shelves.

• When the compressor is on, the refrigerant is

being pumped round, and you will hear a whirring

sound or pulsating noise from the compressor.

• A thermostat controls the compressor, and you

will hear a faint ’click’ when the thermostat cuts in

and out.

Making ice cubes

The appliance is provided with one or more trays for

ice-cubes trays.

Fill the tray(s) 3/4 full to give the ice space to expand

and place them in the freezer compartment.

To release the ice cubes simply give the tray a slight

twist.

Do not use sharp or metallic instruments to remove

the trays from the freezer.

Fresh food refrigeration

To obtain the best performance, do not store warm

food or evaporating liquids in the refrigerator; do

cover or wrap the food, particularly if it has a strong

flavour.

Do not cover the shelves with any protective

material, such as paper, cardboard or plastic, which

may obstruct the air circulation through them.

To help you use your refrigerator correctly, here are

some more useful hints:

Raw meat (beef, pork, lamb & wild fowl): wrap in

polythene bags and place on top of the salad

crispers.

Meat can only be stored safely in this way for

one or two days at the most.

Fruit & vegetables: these should be thoroughly

cleaned and placed in the bottom salad crispers.

Butter & cheese: these should be placed in special

airtight containers or wrapped in aluminium foil or

polythene bags to exclude as much air as possible.

Milk bottles: these should have a cap and should be

stored in the bottle rack on the door.

Thawing

Frozen food, prior to being used, can be thawed in

the fridge or at room temperature depending on the

time available. Small food items may even be cooked

from frozen; in this case cooking will take longer.

Any frozen food which is allowed to thaw accidentally

should either be eaten as soon as possible or thrown

away. Alternatively, if the food is uncooked and has

not been completely defrosted it can be cooked and

then refrozen.

Meat, fish and fruit should be thawed in the

refrigerator compartment and small pieces of meat

can even be cooked while still frozen, but you must

ensure that it is thoroughly cooked through.

Vegetables should be directly immersed in boiling

water; ready-cooked dishes can be placed directly in

the oven in their aluminium wrapping.

A microwave oven is particularly suitable for thawing

any type of frozen or deep-frozen food: follow the

oven instructions, particularly regarding the

placement of aluminium wrapping or containers in

the oven.

Defrosted cooked food must never be refrozen.

Frozen food storage

When first starting-up or after a period of use, before

putting the products in the freezer compartment let

the appliance run for at least two hours on the

coldest setting, then turn the thermostat knob to the

normal opertion position.

Do not exceed the storage period indicated by the

manufacturer.

Finally, do not open the door frequently or leave it

open longer than is absolutely necessary.

Important

Do not put carbonated liquids, (fizzy drinks etc.), in

the freezer compartment.

Ice Iollies, if consumed immediately after removal

from the freezer, can cause low temperature skin

burns.

Do not remove items from the freezer if your hands

are damp/wet, as this could cause skin abrasions or

“frost/freezer burns”.

Instructions for totally built-in

appliances

Door reversal

Recess dimensions

Height (1) 1780 mm

Depth (2) 550 mm

Width (3) 560 mm

To ensure adequate ventilation, allow the clearances

shown in figure.

50 mm

min.

200 cm

min.

D567

The appliance is supplied with the right

or left door opening. To change the opening

direction of the door proceed as in the

following instructions before installing it.

1. Unscrew the upper pin and remove the spacer

2. Remove the upper door

3. Unscrew the middle hinge and the brackets and

refit them on the opposite side

4. Refit the upper door, the upper pin and the

spacer on the opposite side

5. Unscrew the lower pin and remove the spacer

and refit them on the opposite side

Furthermore, it is necessary that the cabinet has a

ventilation recess with the following dimensions:

depth 50 mm

width 540 mm

PR01

540
