Manual

OPERATION

Before using

Remove all securing tapes. Wash inside the

appliance with lukewarm water and bicarbonate of

soda (5 ml to 0.5 litre of water).

Do not use soap or detergent as the smell may

linger. Dry thoroughly.

Setting the temperature

The temperature inside the refrigerator and the

freezer is regulated by a single thermostat with 6

temperature positions and an “OFF” (O) position.

Position 1 = minimum coldness

Position 6 = maximum coldness

Turn the thermostat dial to the required position.

The intermediate position is usually the most

suitable (3-4).

The thermostat setting can vary as the temperature

inside the refrigeration compartment depends on the

following factors:

– room temperature

– how often the door is opened

– how much food is stored

– position of the appliance

Important

During prolonged periods of abnormally hot weather,

if the thermostat is set on too high a number, the

cooling system may operate continuously and the

fridge cooling plate may not defrost. Turning the knob

to a lower number will cause the automatic

defrosting to resume.

Low Room Temperature Switch

To ensure that the appliance is working efficiently

when the room temperature drops below 16°C, the

switch mounted next to the thermostat control should

be switched on.

No damage can be caused by leaving the switch in

this position for any period of time (see page 10 Low

room temperature operation). However should the

temperature rise above 16°C remember to turn the

switch off again.

The freezer compartment

The four-star freezer compartment is suitable for

storage of commercially frozen food and for freezing

fresh foods.

Freezing fresh food

It is not necessary to adjust the thermostat setting

when freezing fresh food. Depress the ambient

switch at least 12 hours before loading food to be

frozen.

In any 24 hours you can freeze up to 10 kg. of fresh

food.

Place food to be frozen in the upper drawer of the

freezer as this is the coldest part.

If large quantities of food are to be stored , remove

all drawers and baskets from the appliance and

place food on cooling shelves. Pay careful attention

not to exceed load limit

stated on the side of the upper section (where

applicable).

Caution

In the event of a power cut the food in the freezer will

not be affected if the power cut is short and if the

freezer is full. Do not open the door. Should the food

begin to thaw, it must be consumed quickly and must

not be re-frozen.

DEFROSTED COOKED FOOD MUST NOT BE

REFROZEN.

A - Low Room Temperature Switch

D710

D726

Apply covers (B) on joint cover lugs and into hinge

holes.

Push appliance into housing until stop strip (A)

touches the kitchen unit.

For a correct alignment make sure that the distance

between the appliance and the cabinet is of 44 mm.

Open the door and push the appliance against the

side of the kitchen unit opposite to that of appliance

hinges.

Fasten the appliance with 4 screws provided in the

kit included with the appliance.

Snap ventgrille (C) and hinge cover (D) into position

Press in the joint covers between the appliance and

the kitchen unit.

D023

D723

D724

44 mm

Download manual in English (PDF, 0.36 MB)
