Manual

TH232-AF-230 400-232-003-B 2010-05-26 3/4

NOTE: Early Start can be used in Automatic mode only. When this

function is set to On, the thermostat calculates the optimal time to

start heating in order to obtain the desired temperature by the set

time. The thermostat re-assesses the start time daily based on the

previous day’s results.

 Press the Hour button to set the hour.

 Set the Min button to set the minutes.

 Set the Day button to set the day.

 Press Mode/Return to exit and save the changes.

Daylight Savings (DLS) Time

When the DLS function is set to US, the thermostat switches to Day-

light Savings Time on the second Sunday of March and to normal

time on the first Sunday of November.

When the DLS function is set to Eu, the thermostat switches to Day-

light Savings Time on the last Sunday of March and to normal time

on the last Sunday of October.

NOTE: The DLS function is OFF (default setting) when the clock

loses its setting.

 Press the Day button (3 seconds) until DLS appears

on the screen.

 Press the to toggle between US, Eu and OFF.

 Press the Day button briefly. The year setting is dis-

played.

 Press the to set the current year.

 Press the Day button briefly. The month setting is dis-

played.

 Press the to set the current month.

 Press the Day button briefly. The date setting is dis-

played.

 Press the to set the current date.

 Press Mode/Return to exit and save the changes.

6.1 Setpoint Temperature

The thermostat normally displays the actual (measured) temperature.

To view the setpoint, press one of the buttons once. The setpoint

will appear for the next 5 seconds.

To change the setpoint, press one of the buttons until the desired

temperature is displayed. To scroll faster, press and hold the button.

Backlight

The screen is lit for 12 seconds when any button is pressed.

6.2 Preset Temperatures

The thermostat has 2 preset temperatures:

 Comfort temperature

 Economy temperature

To use a preset temperature, press the corresponding button. The

corresponding icon will be displayed.

The following table shows the intended use and the default value of

each of the preset temperatures.

To store a preset temperature:

 Set the desired temperature using the buttons.

 Press and hold the corresponding temperature preset button

until the corresponding icon is displayed.

The thermostat has 2 modes of operation: automatic mode and man-

ual mode.

7.1 Automatic Mode

Use automatic mode if you want the thermostat to fol-

low the programmed schedule. The schedule has 4

time periods and uses the 2 preset temperatures. The

thermostat switches to Comfort temperature in periods

1 and 3 and to Economy temperature in periods 2 and

4. The following table shows the intended use of each

time period.

To use the automatic mode, press the Mode button to display on

the screen. The current period number will also appear.

Preprogrammed schedule

The thermostat has been programmed with the following schedule.

Temporary bypass

You can override the temperature of the current period by pressing

the , or buttons. The new setpoint will be used until the begin-

ning of the next period. The clock icon flashes during the bypass.

To cancel the bypass, press the Mode button.



Clock and Day Setting



Temperature Adjustment

Icon Intended use A/AF modes F mode

Comfort

(when at home)

21 °C (70 °F) 28 °C (82 °F)

Economy (when asleep

or away from home)

16.5 °C (62 °F) 20 °C (68 °F)



Modes of Operation

Period Temperature setting Typical use

Comfort

Wake-up

Economy

At work

Comfort

At home

Economy

Sleep

Period

Temperature

setting

Period start time

MO TU WE TH FR SA SU

Comfort

6:00

Economy

8:30

--:-- --:--

Comfort

4:00

--:-- --:--

Economy

11:00

400-232-003-B (Aube TH232-AF-230-OEM) ENG.fm Page 3 Wednesday, May 26, 2010 1:51 PM
