Manual

TH232-AF-230 400-232-003-B 2010-05-26 2/4

This thermostat provides the following temperature control modes:

Display

Apply power to the thermostat at the main electrical panel. At

power-up, the thermostat is in manual mode and displays the

actual (measured) temperature. The setpoint temperature is 28 °C

(82 °F).

LO The actual temperature is below 0 °C (32 °F).

HI The actual temperature is above 70 °C (158 °F).

Er The thermostat built-in sensor is defective. Replace the

thermostat.

E1 The floor sensor circuit is opened. Check the sensor

connections.

E2 The floor sensor circuit is shorted. Replace the sensor.

4.1 Control Mode Selection



Press and hold the Clear button for 3 seconds. The current con-

trol mode is displayed

(ctl).

 Press the to select between A, AF and F.

NOTE

: If you have chosen the A or F mode, go to step 7. If you have

chosen the AF mode, the thermostat will control the ambient tempera-

ture while keeping the floor temperature within desired limits. If the

floor temperature is too low or too high, the thermostat will turn heating

on or off to maintain the floor temperature within the limits regardless

of the ambient temperature. The minimum and maximum floor temper-

ature limits are factory-set at 5 °C (41 °F) and 28 °C (82 °F) respec-

tively. To modify the limits, continue with the next step:



Press the

Clear

button briefly. The minimum limit is displayed (

FL:LO

 Press the button to set the minimum limit.



Press the

Clear

button briefly. The maximum limit is displayed (

FL:HI

 Press the buttons to set the maximum limit.

 Press the Mode/Return button to exit and save the changes.

NOTE: If no button is pressed for 60 seconds, the thermostat will

save the changes and return to normal display.

4.2 Other Configurations

This procedure allows you to choose the following configurations:

 Press and hold the Pgm button for 3 seconds. The current tem-

perature unit is displayed (unit).

 Press the to toggle between °C and °F.

 Press the Pgm button briefly. The current time format is dis-

played (Hr).

 Press the to toggle between 24H and 12H.

 Press the Pgm button briefly. The current Early Start setting is

displayed (ES).

 Press the to toggle between OFF and On.

 Press the Mode/Return button to exit and save the changes.



Description

A mode:  controls and displays the ambient air temperature

F mode:  controls and displays the floor temperature using

an external temperature sensor (default mode)

AF mode:  controls and displays the ambient air temperature

 maintains the floor temperature within desired

limits using an external temperature sensor



Power Up



Error Messages

Day and

time setting

Schedule

programming

Mode selection /

Exit

Clear

Temperature

adjustment

Temperature

presets

On/Off button *

* Use this button to disable heating (e.g. in the summer). The

thermostat remains powered and continues to display the time

and temperature.

Time

Day

Temperature

Periods

Heating intensity

indicator

Automatic mode

Appears when the

setpoint temperature

is displayed

Appears when

heating is disabled

Mode indicator (A, F or AF)

Preset temperature

indicators

Manual mode



Configuration

Parameters Default settings

Temperature format °C

Time format 24H

Early Start setting (see the note below) On

TH232-AF-230

Operating Instructions

Programmable Thermostat

400-232-003-B (Aube TH232-AF-230-OEM) ENG.fm Page 2 Wednesday, May 26, 2010 1:51 PM
