Manual

Freezer Shelf (number varies by

model)

To Remove and Replace the Bottom Shelf:

1. Lift up the front and back of the shelf, and remove from the

cabinet. Be sure not to remove the retaining rods.

2. Replace the shelf, aligning the rods with the cabinet ribs.

Apply a little pressure on the shelf to attach the rods to the ribs

of the cabinet.

To Remove and Replace the Mid and Top Shelf:

1. With your hand, push the shelf from bottom to top until it is

released from the holding rod. Pull the shelf until it is released

from the rear rod. Remove from the cabinet.

2. To replace the shelf:

� Replace rods into the support holes. Push the rods down

so they click into the holes.

� Identify the front and rear trim of the shelf.

� Place the rear trim on the rear rod and push the shelf so it

clicks the rod into the rear trim. (Keep the front raised while

pushing.)

� Lower the front of the shelf until the front trim is on the rod

and push the shelf down so it clicks the rod into the front

trim.

NOTE: Be sure that both sides of the shelf are positioned evenly

in the shelf support holes and the shelf is secure.

Vacation and Moving Care

Vacations

If You Choose to Leave Refrigerator On While You Are Away:

1. Use up any perishables and freeze other items.

2. If your refrigerator has an automatic ice maker and is

connected to the household water supply, turn off the water

supply to the refrigerator. Property damage can occur if the

water supply is not turned off.

3. If you have an automatic ice maker, turn off the ice maker.

NOTE: Depending on your model, raise the wire shut-off arm

to Off (up) position or press the switch to Off.

4. Empty the ice bin.

If You Choose to Turn Refrigerator Off Before You Leave:

1. Remove all food from the refrigerator.

2. If your refrigerator has an automatic ice maker:

� Turn off the water supply to the ice maker at least one day

ahead of time.

� When the last load of ice drops, raise the wire shut-off arm

to the Off (up) position or move the switch to the Off

setting.

3. Depending on the model, turn the refrigerator control to Off or

turn cooling off. See “Control Descriptions” in the Quick Start

Guide.

4. Unplug refrigerator or disconnect power.

5. Clean, wipe, and dry thoroughly.

6. Tape rubber or wood blocks to the tops of both doors to prop

them open far enough for air to get in. This stops odor and

mold from building up.

Moving

When you are moving your refrigerator to a new home, follow

these steps to prepare it for the move.

1. If your refrigerator has an automatic ice maker:

� Turn off the water supply to the ice maker at least one day

ahead of time.

� Disconnect the water line from the back of the refrigerator.

� When the last load of ice drops, raise the wire shut-off arm

to the Off (up) position or move the switch to the Off

setting.

2. Remove all food from the refrigerator and pack all frozen food

in dry ice.

3. Empty the ice bin.

4. Depending on the model, turn the refrigerator control to Off or

turn cooling off. See “Control Descriptions” in the Quick Start

Guide.

5. Unplug refrigerator or disconnect power.

6. Clean, wipe, and dry thoroughly.

7. Take out all removable parts, wrap them well, and tape them

together so they don’t shift and rattle during the move.

8. Depending on the model, raise the front of the refrigerator so it

rolls more easily, or screw in the leveling legs so they don't

scrape the floor. See “Adjust the Doors” or “Door Removal,

Leveling and Alignment” in the online Feature Guide.

9. Tape the doors closed and tape the power cord to the back of

the refrigerator.

When you get to your new home, put everything back and refer to

the Installation Instructions for preparation instructions. Also, if

your refrigerator has an automatic ice maker, remember to

reconnect the water supply to the refrigerator.

INSTALLATION INSTRUCTIONS

Unpack the Refrigerator

WARNING

Excessive Weight Hazard

Use two or more people to move and install or uninstall

appliance.

Failure to do so can result in back or other injury.

Remove the Packaging

Dispose of/recycle all packaging materials. Do not use sharp

instruments, rubbing alcohol, flammable fluids, or abrasive

cleaners to remove tape or glue. These products can damage the

surface of your refrigerator. For more information, see

“Refrigerator Safety.”

When Moving Your Refrigerator:

Your refrigerator is heavy. When moving the refrigerator for

cleaning or service, be sure to cover the floor with cardboard or

hardboard to avoid floor damage. Always pull the refrigerator

straight out when moving it. Do not wiggle or “walk” the

refrigerator when trying to move it, as floor damage could occur.
