4
OPERATION
Before using
Remove all securing tapes. Wash inside the
appliance with lukewarm water and bicarbonate of
soda (5 ml to 0.5 litre of water).
Do not use soap or detergent as the smell may
linger. Dry thoroughly.
Control panel
A - Pilot light - Green
B - Thermostat control knob
C - Fast freeze light - Amber
D - Fast freeze switch
Control Panel
A. Pilot light
The operation light is illuminated continuously, to
show that the appliance is on.
B. Thermostat control knob
Turn the thermostat control knob clockwise to
required setting.
C. Fast freeze light
The fast freeze light is illuminated, to show that the
fast freeze function is working.
D. Fast freeze control switch
When you place fresh food in the appliance, press
the fast freeze control switch.
Start your appliance
Allow the appliance to stand for 2 hours after
installation.
Insert the plug into the wall socket. The pilot light (A)
will illuminate to show that the appliance is on.
Turn the thermostat control (B) to a midway setting.
Leave the appliance for approximately 4 hours for
the correct temperature to be reached before placing
food inside.
To switch off the appliance turn the thermostat
control to position “O” .
5
6
2
1
3
4
B
A
C
D
Temperature control
The temperature within the freezer is controlled by
the thermostat situated in the middle of the
appliance.
To operate the freezer proceed as follows:
Position 1 = minimum coldness
Position 6 = maximum coldness
Turn the thermostat control knob beyond the «O»
position.
When you first start the freezer, we suggest that you
turn the thermostat control to a medium setting. For
easier turning of this control, use a small coin.The
internal temperature of the freezer is automatically
adjusted by the thermostat to ensure safe food
storage.
However, if the appliance is working in unfavourable
room conditions such as
- poor ventilation,
- high temperature,
- frequent door openings,
it may be necessary to select a more suitable
setting.
17
Push appliance into housing until stop strip (A)
touches the kitchen unit.
For a correct alignment make sure that the distance
between the appliance and the cabinet is 44 mm.
Open the door and push the appliance against the
side of the kitchen unit opposite to that of appliance
hinges.
Fasten the appliance with 4 screws provided in the
kit included with the appliance.
Snap ventgrille (C) and hinge cover (D) into position .
Press in the joint covers between the appliance and
the kitchen unit.
A
D023
D
C
D723
D724
D726
B
Apply covers (B) on joint cover lugs and into hinge
holes.
44 mm
