Manual

Cleaning the interior

Before using the appliance for the first time, wash

the interior and all internal accessories with luke-

warm water and some neutral soap so as to remove

the typical smell of a brand-new product, then dry

thoroughly.

Do not use detergents or abrasive

powders, as these will damage the finish.

Operation

Insert the plug into the wall socket.

Open the refrigerator door and turn the thermostat

knob, clockwise, beyond the «O» (STOP) position.

The appliance will start to operate.

To stop operation, simply turn the thermostat knob to

position «O»

Temperature regulation

The temperature is automatically regulated and can

be increased to achieve a higher temperature

(warmer) by rotating the thermostat knob toward

lower settings or reduced (colder) rotating the knob

towards higher settings.

However, the exact setting should be chosen

keeping in mind that the temperature inside the

refrigerator depends on:

• room temperature;

• how often the door is opened;

• the quantity of food stored;

• location of appliance.

A medium setting is generally the most suitable.

Important

If the ambient temperature is high or the

appliance is fully loaded, and the appliance is

set to the lowest temperatures, it may run

continuously causing frost to form on the rear

wall. In this case the dial must be set to a higher

temperature to allow automatic defrosting and

therefore reduced energy consumption.

Fresh food refrigeration

To obtain the best performance:

• do not store warm food or evaporating liquids in

the refrigerator;

• do cover or wrap the food, particularly if it has a

strong flavour.

• Position food so that air can circulate freely round

it.

USE

Door reversibility

Before carrying out any operations, remove the plug

from the power socket.

To change the opening direction of the door,

proceed as follows:

1. pull off the ventilation grille (D) which is clipped

into place;

2. remove the hole cover (G) and the bottom hinge

(E) by unscrewing its three fixing screws;

3. remove the lower door, sliding it out of the middle

hinge;

4. unscrew the middle hinge (H);

5. Remove the fridge door by releasing it from the

top hinge pin (G).

6. Remove the pin (G) then mount it on the opposite

side, after having removed the plugs which must

be refitted on the other side.

7. remove the two plugs of the door (where

available), discovering the holes for the hinge

pins, assemble them on the opposite side and

refit the upper door;

8. reassemble the middle hinge on the opposite

side;

9. using a 10 mm spanner, unscrew the hinge pin

(E) and reassemble it on the opposite side of the

hinge;

10. reassemble the lower door;

11. reassemble the lower hinge (E) on the opposite

side, using the screws previously removed; insert

the hole cover (G) on the lower hinge. Slide the

hole cover (F) out of the ventilation grille (D) by

pushing it in the direction of the arrow and

reassemble it on the opposite side;

12. refit the ventilation grille (D), clipping it into

place.

13.Dismantle the handles and reassemble them on

the opposite side. Cover the holes left open with

the plugs contained in the documentation pack.

The doors can be aligned by adjusting the middle

hinge.

The middle hinge can be adjusted horizontally, with

the help of a tool, after having slackened the two

screws.

Warning:

After having reversed the opening direction of

the doors check that all the screws are properly

tightened and that the magnetic seal adheres to

the cabinet. If the ambient temperature is cold (i.e.

in Winter), the gasket may not fit perfectly to the

cabinet. In that case, wait for the natural fitting of the

gasket or accelerate this process by heating up the

part involved with a normal hairdrier.
