Manual Electrolux ERA3366X Fridge-Freezer

Need a manual for your Electrolux ERA3366X Fridge-Freezer? Below you can view and download the PDF manual for free in English. This product currently has 17 frequently asked questions, 0 comments and has 0 votes. If this is not the manual you want, please contact us.

Is your product defective and the manual offers no solution? Go to a Repair Café for free repair services.

Manual

CONTENTS

Warnings 14

Use 16

Cleaning the interior 16

Operation 16

Temperature regulation 16

Fresh food refrigeration 16

Movable shelves 17

Bottle rack 17

Positioning the door shelves 17

Cold Store Compartment 17

Air recycling 18

Freezing calendar 18

Freezing fresh food 19

Storage of frozen food 19

Thawing 19

Ice-cube production 19

Hints 20

Hints for refrigeration 20

Hints for freezing 20

Hints for storage of frozen food 20

Maintenance 21

Periodic cleaning 21

Periods of no operation 21

Interior light 21

Defrosting 21

Customer service and spare parts 22

Technical information 23

Installation 23

Location 23

Shelf holders 24

Electrical connection 24

Rear spacers 24

Changing the opening direction of the doors 25

Installation

• During normal operation, the condenser and

compressor at the back of the appliance heat up

considerably. For safety reasons, minimum

ventilation must be as shown in the instructions.

Attention: keep ventilation openings clear of

obstruction.

• Care must be taken to ensure that the appliance

does not stand on the electrical supply cable.

Important: if the supply cord is damaged, it must

be replaced by a special cord or assembly availa-

ble from the manufacturer or its service agent.

• If the appliance is transported horizontally, it is

possible that the oil contained in the compressor

flows in the refrigerant circuit. It is advisable to

wait at least two hours before connecting the

appliance to allow the oil to flow back in the

compressor.

• There are working parts in this product which

heat up. Always ensure that there is adequate

ventilation as a failure to do this will result in

component failure and possible food loss. See

installation instructions.

• Parts which heat up should not be exposed.

Wherever possible the back of the product should

be against a wall.

Environment Protection

This appliance does not contain gasses which

could damage the ozone layer, in either its

refrigerant circuit or insulation materials.The

appliance shall not be discarded together with

the urban refuse and rubbish. Avoid damaging

the cooling unit, especially at the rear near the

heat exchanger. Information on your local

disposal sites may be obtained from municipal

authorities.The materials used on this appliance

marked by the symbol are recyclable.

Disposal of old Appliances

The symbol on the product or on its packaging

indicates that this product may not be treated as

household waste. Instead it shall be handed over to

the applicable collection point for the recycling of

electrical and electronic equipment. By ensuring this

product is disposed of correctly, you will help prevent

potential negative consequences for the

environment and human health, which could

otherwise be caused by inappropriate waste

handling of this product. For more detailed

information about recycling of this product, please

contact your local city office, your household waste

disposal service or the shop where you purchased

the product.

ADVERTÊNCIAS E CONSELHOS IMPORTANTES

É muito importante que este manual de utilização acompanhe o aparelho para garantir uma futura utilização

correcta. Se o aparelho for vendido ou emprestado a uma outra pessoa, o manual de utilização deve, como

acima se faz notar, acompanhá-lo, de maneira que o utilizador possa ser informado do seu funcionamento,

das advertências e conselhos. Se este aparelho, munido de fecho magnético, veio substituir um outro que

tinha portas com fecho de mola, aconselhamos a inutilizar este fecho, antes do aparelho ser posto

definitivamente de lado. Esta precaução procura evitar que crianças, brincando, se possam fechar no

aparelho o que seria altamente perigoso.

Essas advertências têm por fim garantir a segurança dos utilizadores. Agradecemos, portanto, que leia o

manual atentamente, antes de instalar e utilizar o aparelho.

Segurança

• Este aparelho foi concebido para ser utilizado por

adultos. Deve, por isso, pô-lo ao abrigo das crianças

não consentindo que dele se sirvam como brinquedo.

• É perigoso modificar ou tentar modificar as

características deste aparelho.

• Este aparelho é pesado. Tenha o maior cuidado

quando o deslocar

• Não consuma certos produtos, tais como

gelados, imediatamente após terem saído do

aparelho; a temperatura muito baixa a que se

encontram pode provocar queimaduras.

• Este aparelho contém hidrocarbonetos no

circuito refrigerante; portanto, a manutenção

e a recarga devem ser efectuadas

exclusivamente por pessoal autorizado pelo

produtor.

• Preste a máxima atenção ao deslocar o

aparelho, para não danificar as partes do

circuito refrigerante, evitando assim possíveis

saídas de fluido.

• O aparelho não deve ser instalado perto de

elementos de aquecimento ou fogões de gás.

• Evite a exposição prolongada do aparelho aos

raios do sol.

• A parte de trás do aparelho deve receber uma

suficiente ventilação e deve ser evitado

qualquer dano ao circuito refrigerante.

• Somente para os congeladores (excepto os

de encaixe): a melhor colocação é na cave.

Assistência

• Se uma eventual modificação da instalação

eléctrica, na casa do utilizador, tiver de ser feita para

tornar possível a instalação do aparelho, deve, esta,

ser efectuada por pessoal qualificado.

• Este aparelho deve ser assistido por um Centro

de Assistência autorizado, sendo apenas

aplicadas peças de origem.

• Em caso de avaria, não tente você mesmo, reparar

o aparelho. As reparações executadas por pessoas

inexperientes, podem causar danos físicos e mate-

riais (aumentando as avarias a serem reparadas).

Faça apelo ao seu Centro de Assistência mais

próximo e insista em peças genuínas.

Utilização

• Os frigoríficos e/ou congeladores domésticos

destinam-se, unicamente, à conservação e/ou

congelação de alimentos.

• Os melhores rendimentos são conseguidos com

temperaturas ambiente incluídas entre +18°C e

+43°C (Classe T); +18°C e +38°C (Classe ST);

+16°C e +32°C (Classe N); +10°C e +32°C

(Classe SN); a classe a que pertence o aparelho

é indicada na placa de matrícula (posta na cela

ao lado do compartimento dos legumes).

Atenção: com temperaturas ambiente não

incluídas nas indicadas para a classe climática a

que pertence o produto, é preciso cumprir as

indicações seguintes: quando a temperatura

ambiente descer abaixo do valor mínimo, pode

não ser garantida a temperatura de conservação

no compartimento congelador; portanto,

aconselha-se a consumar rapidamente os

alimentos nele contidos.

• Um produto descongelado não deve, em nenhum

caso, voltar a ser congelado.

• Siga as indicações do fabricante para a

conservação e/ou congelação dos alimentos.

• O revestimento interior do aparelho em composto

de pequenos tubos por onde passa o refrigerante.

Se estes tubos forem danificados o aparelho ficará

irremediavelmente avariado, provocando a perda

dos alimentos no seu interior. NÃO UTILIZE

OBJECTOS PONTEAGUDOS para raspar o gelo

acumulado. Esse gelo pode ser raspado utilizando a

espátula que é fornecida com o aparelho. Para

eliminar grandes quantidades de gelo acumulado, é

aconselhável deixá-lo derreter. Veja as instruções

para a descongelação.

• Não coloque no compartimento/congelador a baixa

temperatura, garrafas ou latas com bebidas

gaseificadas dado que se cria uma pressão elevada

no interior da garrafa e/ou lata havendo o perigo de

este explodir. Desta explosão resultariam danos

graves para o aparelho.
