WASH CYCLES

Follow the instructions on the symbols of the garment’s wash

care label. The value indicated in the symbol is the maximum

recommended temperature for washing the garment.

Daily Mix Wash & Dry

use programme 1 to wash and dry mixed garments (cotton and

synthetics). This cycle may be used to wash and dry loads of up to 3,5 kg;

we recommend the use of liquid detergent.

The use of the steam in this programme is optimised to reduce the

formation of creases on garments, making them easier to iron.

Shirts Wash & Dry

Use programme 2 to wash and dry shirts and T-shirts in dierent fabrics

and colours to ensure maximum care. This cycle may be used to wash and

dry loads of up to 3 kg. To achieve optimum results, use liquid detergent

and pre-treat cus, collars and stains. The use of the steam in this

programme is optimised to reduce the formation of creases on garments,

making them easier to iron.

Pre Iron

Use this programme immediately before ironing; max. 2 kg load. The use

of the steam in this programme is optimised to reduce the formation of

creases on garments, making them easier to iron.

Steam Refresh

For refreshing garments, neutralised unpleasant odours and relaxing the

bres by delivering steam into the drum. The garments will be damp at

the end of the cycle.

Anti Stain Turbo 45’

This cycle ensures excellent stain removal capacity even at 20°C in just 45

minutes. The temperature of this cycle can be increased up to 40°C.

Anti Stain Power 20°C

This programme ensures maximum stain removal capacity with no need

for pre-treatment at low temperatures, preserving fabrics and colours.

Cotton

Suitable for washing towels, underwear, table cloths, etc. made of

resistant linen and cotton that are moderately to heavily soiled.

Eco Cotton

Suitable for washing moderately soiled cotton garments. At 40°C and

60°C it is the standard cycle for washing cotton garments, and is the most

ecient in terms of combined water and electricity consumption.

Synthetics

Suitable for washing moderately soiled garments made of synthetic bres

(e.g. polyester, polyacrylic, viscose, etc.) or mixed synthetic-cotton bres.

Multi Colour

for washing coloured cotton garments. This programme is optimised to

keep colours bright even after repeated washing.

Ultra Delicates

For washing very delicate garments. It is advisable to turn the garments

inside out before washing them. For best results, use liquid detergent on

delicate garments.

We recommend turning the garments inside out before washing and

placing small items into the special bag for washing delicates. Use liquid

detergent on delicate garments for best results.

When selecting an exclusively time-based drying function, a drying cycle

is performed at the end of the wash cycle that is particularly delicate,

thanks to light handling and appropriate temperature control of the

water jet.

The recommended durations are:

1 kg of synthetic garments --> 165 min

1 kg of synthetic and cotton garments --> 180 min

1 kg of cotton garments --> 180 min

The degree of dryness depends on the load and fabric composition.

Wool - Woolmark Apparel Care - Green:

the wool wash cycle of this machine has been approved

by The Woolmark Company for the washing of wool

garments labelled as “hand wash” provided that the

products are washed according to the instructions on the

garment label and those issued by the manufacturer of

this washer-dryer. (M1135)

Sport

for washing lightly soiled sports clothing (tracksuits, shorts, towels, etc.);

for best results, we recommend not exceeding the maximum load

indicated in the “Wash cycles Table”. We recommend using liquid

detergent, and adding the amount suitable for a half-load.

Fast 30’

For washing lightly soiled garments in a short time. Not suitable for wool,

silk and garments to be washed by hand.

Rinse

Designed for rinsing and spinning.

Spin + Pump out

Designed for spinning and draining the water.

DISPLAY

The display is useful when programming the machine and provides a

great deal of information.

The following will appear in area A: the icon and programme selected, the

washing and drying phases and time remaining to the end of the cycle.

Area B will include the two intensity levels relative to the DIRECT

INJECTION option. The indicator lights relative to the available functions

appear in area C. Area D will display the time remaining to the start of the

selected cycle if the DELAY TIMER function was set.

Area E will display the maximum available spin speed on the basis of the

set cycle; if the cycle does not include the spin cycle setting, the dimly lit

“--” symbol will appear in the area.

Area F will show the temperature value that can be selected on the basis

of the set cycle.

If the cycle does not include setting of the temperature, the dimly lit “--”

symbol will appear in the area.

! The rst time the machine is switched on, you will be asked to select the

language and the display will automatically show the language selection

menu.

To select the desired language press the X and Y buttons; to conrm the

selection press the Z button.

To change the language switch o the machine and press buttons G, H, I

simultaneously until an alarm is heard: the language-selection menu will

be displayed again.

! To change the display luminosity, which by default is set to the highest

value, switch the machine o then simultaneously press buttons G, L and

M until the buzzer sounds.

Press buttons X and Y to choose the desired level of luminosity then

conrm by pressing button Z.

! During the wash cycle or when the DELAY TIMER function has been

enabled, if the user does not interact with the display for 1 minute the

SCREEN SAVER activates. To return to the previous window, simply press

any button.

Locked door indicator

When lit, the symbol indicates that the door is locked. To prevent any

damage, wait until the symbol turns o before opening the door.

To open the door while a cycle is in progress, press the START/PAUSE

button ; if the symbol is o, the door can be opened.

FIRSTTIME USE

Once the appliance has been installed, and before it is used for the rst

time, run a wash cycle with detergent and no laundry, by setting the “Auto

Clean” cycle.

DAILY USE

Prepare the laundry by following the suggestions appearing under the

“TIPS AND SUGGESTIONS” section.

- Press the ON/OFF button ; “HOTPOINT” will appear on the display; the

indicator light relative to the START/PAUSE button will ash slowly

green.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the wash cycle table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments, as described in the “DETERGENT DISPENSER

DRAWER” section.

- Close the door.

- Use the WASH CYCLE selector knob to select the desired wash cycle: the

cycle’s name will appear on the display; the cycle will be associated with a

specic temperature and spin speed which can be modied. The duration

of the cycle will appear on the display.

- Modify the temperature and/or spin speed: the machine automatically

selects the maximum temperature and spin speed set for the selected

wash cycle; these values cannot therefore be increased. Pressing the

button gradually reduces the temperature down to the cold wash setting

(the “--” symbol will appear on the display). Pressing the button

gradually reduces the spin speed until it is completely excluded (the “--”

symbol will appear on the display). Pressing the buttons further restores

the maximum allowed values for the selected cycle.

- Select the desired options.

- Press the START/PAUSE button to start the wash cycle; the relative

indicator light will light up steady green and the door will lock (

symbol on).

PAUSING A CYCLE

To pause the wash cycle, press the START/PAUSE button again; the

indicator light will ash amber. To start the wash cycle from the point at

which it was interrupted, press the START/PAUSE button again.

2:55

90°

1200

-- h

--

COTONE

H

G

Y

X Z

I

L M

A

B

C

C

D

E

C

F
