Manual

Quick Guide

CONTROL PANEL

1. ON/OFF button

2. DRYING button

3. DRYING ONLY button

4. MULTI RINSE button

5. OPTION button

6. DIRECT INJECTION button

7. START/PAUSE button and indicator light

8. KEY LOCK button

9. DELAY TIMER button

10. SPIN button

11. TEMPERATURE button

12. AUTO CLEAN button

13. WASH CYCLE SELECTOR KNOB

WASH CYCLE TABLE

For all testing institutes:

2) Long cotton cycle: set programme 8 at temperature 40°C and press the DIRECT INJECTION

button under “Power” mode.

3) Long synthetics cycle: set cycle 9 at a temperature of 40°C.

* By selecting the cycle and excluding the spin cycle, the washer-dryer will drain only.

** If a drying cycle is also programmed, the machine will run a “wash+dry” programme lasting

45’ and a 1kg laundry load.

The cycle duration indicated on the display or instruction manual is an estimate based on

standard conditions. The actual duration may vary in relation to several factors, such as

the temperature and pressure of the incoming water, ambient temperature, amount of

detergent, load quantity and type, load balancing and any additional options selected.

1) Test programme in compliance with standard EN 50229 (Wash):

This cycle is designed for normally soiled cotton loads and is the most ecient in terms of

both electricity and water consumption; it should be used for garments washable at 60°C or

at 40°C. The actual washing temperature may dier from the indicated value.

Test programme in compliance with standard EN 50229 (Drying): select the 8 wash

programme and set the drying level to “EXTRA”, for both loads. The rst drying cycle must be

carried out with the nominal load.

PRODUCT DESCRIPTION

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

THANK YOU FOR PURCHASING A WHIRLPOOL PRODUCT.

To receive more comprehensive assistance, register the

appliance on

www.whirlpool.eu/register

Before using the appliance carefully read the Health and Safety guide.

Before using the machine, it is imperative that the transport bolts are removed. For more

detailed instructions on how to remove them, see the Installation Guide.

Maximum load 11 kg

Power input in o mode 0.5 W / in left-on mode 8 W

Detergents and

Additives

Recommended

detergent

Wash cycle

Temperature

Maximum

spin

(r.p.m.)

Max. load

for Wash

(kg)

Max. load

for Drying

(kg)

Duration

(Minutes)

Drying

Wash

Fabric

softener

Powder Liquid

Default Range

1 2

1 Daily Mix Wash & Dry 40 °C

- 40 °C 800 3,5 3,0

The duration of the wash cycles can be checked on the display.

  

–



2 Shirts Wash & Dry 40 °C

- 40 °C 1000 3,0 2,0

  

–



3 Pre Iron – – – 2,0 – – – – – –

4 Steam Refresh – – – 2,0 – – – – – –

5 Anti-Stain Turbo 45’ 20 °C

- 40 °C 1200 5,5 5,0

  

–



6 Anti-Stain Power 20°C) 20 °C

- 20 °C 1600 11,0 7,0

  

–



7 Cotton 40 °C

- 90 °C 1600 11,0 7,0

    

Eco Cotton

60°/40°

(1-2)

60 °C

- 60 °C 1600 11,0 7,0

    

9 Synthetics (3) 40 °C

- 60 °C 1000 5,0 4,5

    

10 Multi Colour 40 °C

- 40 °C 1600 11,0 7,0

  

–



11 Ultra Delicates 30 °C

- 30 °C -- 1,0 1,0

  

–



12 Wool 40 °C

- 40 °C 800 2,5 2,5

  

–



13 Sport 40 °C

- 40 °C 600 4,5 4,5

  

–



14 Fast 30‘ ** 30 °C

- 30 °C 800 4,0 4,0 **

 

–



Rinse – – 1600 11,0 7,0



–



– –

Spin + Pump out * – – 1600 11,0 7,0



– – – –



Required dosage  Optional dosage

DETERGENT DISPENSER DRAWER

Compartment *:

Do not insert detergent in this compartment.

Compartment 1: Washing detergent (powder

or liquid)

If liquid detergent is used, the removable plastic

partition A (supplied) should be used for proper

dosage.

If powder detergent is used, place the partition

into slot B.

Compartment 2: Additives (fabric softeners, etc.)

The fabric softener must not exceed the “MAX” level.

! Use powder detergent for white cotton garments, for pre-washing, and

for washing at temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

1 2

DISPLAY

5 6
