Manual Amana BRF20VCPER Fridge-Freezer

Need a manual for your Amana BRF20VCPER Fridge-Freezer? Below you can view and download the PDF manual for free in English. This product currently has 16 frequently asked questions, 0 comments and has 0 votes. If this is not the manual you want, please contact us.

Is your product defective and the manual offers no solution? Go to a Repair Café for free repair services.

Manual

Loading…

6
Some models have an internal support rod
(see
below)
installed in the hinge socket of door. If
present, remove and retain for later replacement.
A
A Support rod (some models)
3. Reverse center hinge:
Remove center hinge bracket and shims by
removing screws using a Phillips screwdriver.
Remove 3 screws opposite of center hinge and
transfer to opposite side of cabinet.
Install bracket on opposite side of cabinet with
shims.
A
B
C
A Phillips screws C Center hinge shim
B Center hinge
4. Reverse bottom hinge pin:
Remove toe grille by grasping both ends and pulling
straight out from unit. Grille snaps free.
A
A Toe grille
Exchange hinge pin from bottom hinge assembly
with outward hinge plug from opposite bottom hinge
assembly.
A
B
A Hinge pin B Hinge plug
5. Remove door stops and reverse door extensions:
Locate door stop and bottom of refrigerator door and
freezer door. Remove with Phillips screwdriver.
C
B
A
A Bottom door cap C Door stop
B Screws
Unscrew door extension on top of door with Phillips
screw driver. Flip door extension so notched corner
turns in toward interior of door. Reinstall with screws.
A
B
C
A Before B After
C Door extension
6. Reverse handles and trim:
Remove screws from bottom door cap of refrigerator
and freezer door with screwdriver.
Using a soft rubber mallet, tap bottom of handle
upward toward top of door. Handle will slide up
approximately ¾" and release from door.
Using a soft rubber mallet, tap bottom of door hinge
trim upward toward top of door. Trim will slide up
approximately ¾" and release from door.
Remove plastic tab on top of trim*. Return tab to
literature assembly. Locate alternate tab piece in
literature assembly and place this in notch at
opposite end of trim.
* In stainless steel models plastic tab is not
required. Replace trim with alternate trim shipped
with unit.
Right
mounted
handle
Left
mounted
handle
Replace bottom door cap.
Attach door stop under the hinge side of the door
using Phillips screws.
Install hinge trim by locating notches on the inside of
trim(make sure plastic tab insert is facing bottom of
door). Align notches of trim with metal mounting tabs
on opposite side of door. Slide trim down until piece
locks into place. Tap top of trim with rubber mallet to
insure snug fit.
Download manual in English (PDF, 8.17 MB)
(Consider the environment and only print this manual if it is really necessary)

Loading…

Rating

Let us know what you think about the Amana BRF20VCPER Fridge-Freezer by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.
Are you satisfied with the Amana BRF20VCPER Fridge-Freezer?
Yes No
Be the first to rate this product
0 votes

Join the conversation about this product

Here you can share what you think about the Amana BRF20VCPER Fridge-Freezer. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.

More about this manual

We understand that it’s nice to have a paper manual for your Amana BRF20VCPER Fridge-Freezer. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Amana. They might be able to provide an original manual. Are you looking for the manual of your Amana BRF20VCPER Fridge-Freezer in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

Brand Amana
Model BRF20VCPER
Category Fridge-Freezers
File type PDF
File size 8.17 MB

All manuals for Amana Fridge-Freezers
More manuals of Fridge-Freezers

Frequently Asked Questions about Amana BRF20VCPER Fridge-Freezer

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

If I want my fridge-freezer to be colder, should I choose for a higher or lower setting? Verified

With most fridge-freezers a higher setting means the machine will cool harder. With a lower setting, the machine will cool less hard and the temperature in the fridge-freezer will be higher.

This was helpful (8501) Read more

Can I change the opening direction of the door of my fridge-freezer? Verified

Yes, nearly all standing fridge-freezers offer the option to place the door on the other side. How to do this can generally be found in the manual.

This was helpful (4689) Read more

What is the best temperature setting for a refrigerator? Verified

From a health perspective temperatures between 3℃ and 4℃ are the best. At these temperatures the growth of bacteria and mold is limited.

This was helpful (3860) Read more

The drain hole in my fridge-freezer is dirty/clogged, how do I clean it? Verified

There are special cleaning devices to do this, but it is also possible to remove blockage or dirt with a cotton swab. To keep the drain hole clean and prevent smells it is advisable to put a drop of chlorine bleach in the drain 4 times a year.

This was helpful (3627) Read more

How often should I defrost my freezer? Verified

For optimal use of the freezer it is best to defrost it once every 3-6 months. Ice on the inside of the freezer reduces the available space and increases the use of energy. The thawing process can be accelerated by placing hot water in the drawer or placing bowls of hot water in the freezer.

This was helpful (2686) Read more

My fridge-freezer makes a bubbling sound, is that normal? Verified

Modern fridge-freezers make use of an environmentally friendly cooling agent. During the cooling process this substance turns into a gas, which can cause a bubbling and/or hissing sound. This is perfectly normal.

This was helpful (2298) Read more

I bought a new fridge-freezer, can I turn it on immediately? Verified

No, the fridge-freezer needs to stand in an upright position for at least 4 hours before it can be turned on. This is because the coolant liquid needs to settle.

This was helpful (1628) Read more

Is it normal that water or ice drops are forming on the back wall of my fridge-freezer? Verified

Yes, this a completely normal phenomenom. The moisture that enters the fridge-freezer with warm air or products will settle on the coldest part, being the back wall. Because the back wall can reach temperatures below freezing, the drops will freeze from time to time. When the fridge-freezer is idle the drops will thaw and flow to the drain of the fridge-freezer.

This was helpful (1322) Read more

De door of my fridge-freezer will not close properly, why is that? Verified

The two most common causes are that the fridge-freezer is not level and that the door seal is damaged or has food remains on it. Make sure the fridge-freezer is level and check the door seal. Replace the seal if neccesary.

This was helpful (1143) Read more

How much space should I leave betwee my fridge-freezer and the wall? Verified

To ensure a good ventilation it's best to leave at least 5cm of free space on both sides and the back of the fridge-freezer.

This was helpful (1056) Read more

What do the stars on the freezer mean? Verified

The stars indicate the freezing capacity. 1 star indicates a freezing capacity down to -6ºC. This makes the freezer suitable for making ice cubes or storing previously frozen goods for up to two weeks. Fresh food cannot be frozen. 2 stars indicates a freezing capacity down to -12ºC. This makes the freezer suitable for storing previously frozen goods for up to two months. Fresh food cannot be frozen. 3 stars indicates a freezing capacity down to -18ºC. This makes the freezer suitable

This was helpful (847) Read more

How long does it take for my refrigerator to reach the set temperature after I turn it on? Verified

This depends on the size, age and model of the refrigerator. It may take several hours to 24 hours for the refrigerator to reach the set temperature. The process can be accelerated by placing non-perishable goods in the refrigerator. The temperature in the refrigerator cannot be measured properly by feeling the air inside. The best way to tell if the refrigerator has reached the set temperature is to place a glass of water in the refrigerator with a thermometer in it.

This was helpful (723) Read more

There is condensation in my refrigerator, why is that? Verified

There can be several causes. The door gasket can be defective, allowing outside air into the refrigerator. It's also possible that the refrigerator is not level, preventing the door from closing correctly. Another cause is a large difference between the temperature inside the refrigerator and outside while the door is being opened frequently.

This was helpful (613) Read more

Can I put warm food or drinks in my fridge-freezer? Verified

Preferably not. The temperature in your fridge-freezer will rise, which negatively impacts the other items that are stored inside.

This was helpful (551) Read more

There is mold on the rubber seals of my fridge-freezer, what should I do? Verified

The rubber seals are not actually inside the fridge-freezer and are therefore warmer. This allows bacteria to grow and mold to form. Clean the rubbers regularly to prevent this.

This was helpful (549) Read more

What is R-410A? Verified

R-410A is a cooling agent that is used in appliances that cool up to 0°C, like refrigerators and air conditioners. It is the replacement of older cooling agents and does not damage the ozon layer.

This was helpful (549) Read more
