Manual
Loading…
1
4
2
5
3
6
PACKAGE CONTENTS
FRONT BACK
Control Panel
Front Panel
Air Outlet
Vent
Handle
Power Plug
(1) Pre-Filter
(1) Washable AOC™ Carbon Filter
(1) True HEPA Filter
Unit User Manual
AM80
The product warranty is printed on the back of this guide.
This product is manufactured for use only in USA / CA.
This product is suitable for 120 V only.
WHERE TO USE
MODEL PART DIAGRAM
12~18 in
12~18 in
Allow 12 ~ 18 in. of space between TVs, radios, and other electronics
Electromagnetic interference from certain electronics may cause
product malfunction.
Place indoors away from direct sunlight
Direct exposure may cause product malfunction or failure.
Only place on hard, flat surfaces
Flimsy or slanted surfaces may result in abnormal noise and vibrations.
Allow 12 ~ 18 in. from walls for maximum air flow
01. Auto Mode Indicator
The LED "Auto" light will indicate when Auto Mode is
activated.
02. Air Quality Indicator
Color coded LED light indicates one of three levels of
Air Quality: Red (poor), Amber (fair), and Blue (good).
03. Fan Speed Indicator
Indicates the current fan speed.
Auto Mode Low Medium
High Turbo
04. PlasmaWave
®
Indicator
Indicates whether PlasmaWave
®
is enabled or
disabled.
05. Sleep Mode Indicator
When Sleep Mode is activated, the Air Quality
Indicator LED light is disabled.
Fan speed will automatically set to minimum speed
(lower than 'Low') which will be nearly silent.
When Sleep Mode is active, PlasmaWave
®
will be
disabled, but it can be turned back on.
06. Filter Replacement Indicator
LED light indicates when it is time to change the filter.
CONTROL PANEL
07. Filter Reset Button
After replacing the True HEPA Filter, use a small object
such as a paper clip, to press and hold the Filter
Reset Button for at least 5 seconds until the Filter
Replacement Indicator turns off.
08. Odor Sensor
Detects the amount of odorous gas in the
environment. When in Auto mode, the fan speed
adjusts according to the detected amount of gas.
09. Power Button
Turns the unit on or off. During the first 30 seconds
of powering up, the Air Quality Indicator will cycle
through Blue, Amber and Red colors.
•
Odor Sensor takes approximately 4minutes to
detect the air quality in the environment before
normal operation begins.
10. Mode Button
Press to cycle through to set the mode of operation
(Auto, Sleep). The unit will default to Auto with
PlasmaWave
®
enabled when first powered on.
Auto Mode:
•
Auto Mode automatically adjusts fan speeds
according to your indoor air quality. The fan speed
will adjust to low when air quality is good, medium
when fair, and to high when poor.
Sleep Mode:
When Sleep Mode is activated, the Air Quality
Indicator LED light is disabled.
•
Fan speed will automatically set to minimum speed
(lower than 'Low') which will be nearly silent.
•
When Sleep Mode is active, PlasmaWave
®
will be
disabled, but it can be turned back on.
11. PlasmaWave
®
Button
Press the Plasmawave
®
button when the unit is on to
enable or disable this feature. By default,
PlasmaWave
®
is enabled whenever the unit is
powered on.
"When the unit is running, you may hear a chirping
or buzzing sound. The sound is from large particles
passing through PlasmaWave
®
, it is normal and does
not signify product failure."
12. Light Sensor
Detects the amount of ambient light in the
environment. When in Auto Mode, the Light Sensor
detects when to put the unit into Sleep Mode.
When to Replace Filters
Filter Indicator Light When to Service When to Replace
Pre-Filter
none Clean once every 14 days Permanent
Washable AOC™
Carbon Filter
none Clean once every 3 months
Lasts Approx. 12 months
True HEPA Filter
Can NOT be WASHED
•
When the Check Filter Indicator LED is on, it is time to replace the True HEPA Filter and Washable AOC™ Carbon Filter.
•
Intervals between filter replacement may vary depending on environment.
MAINTENANCE
3
True HEPA Filter
2
Washable AOC™
Carbon Filter
4
PlasmaWave
®
Pre-Filter
1
4-STAGE AIR PURIFICATION
01. Pre-Filter
Designed to catch larger airborne particles found
indoors.
03. True HEPA Filter
Captures 99.97%* of airborne allergens including; pollen,
mold spores, dust, pet dander, microbes, and smoke
(*Particles as small as 0.3 microns in size.)
02. Washable AOC™ Carbon Filter
Reduces VOCs and household odors from cooking,
pets, and smoke.
04. PlasmaWave
®
PlamaWave
®
creates Hydroxyls which can help to
reduce the presence of airborne Bacteria, Viruses*
(*Based on independent
laboratory test conducted on
Influenza A Virus H3N2, E. coli, Pseudomonas aeruginosa,
Staphylococcus aureus, Salmonella typhimurium.)
INITIAL OPERATION
Latch
1.
Remove the front panel by grasping its upper
edge and gently pulling forward.
2.
Remove the Pre-Filter, then the bag of filters
behind it.
3.
Remove filters from protective plastic bag.
4.
Install the filters until they fit securely in place.
03. True HEPA Filter (back)
02. Washable AOC™ Carbon Filter (middle)
01. Pre-Filter (front)
Latch
5.
After filters are installed, close the front panel.
6.
Insert the power cord into an electrical outlet.
After replacing a filter,
press the Filter Reset Button
for at least 5 seconds.
REPLACING FILTERS
CLEANING CARE
Cleaning the Filters:
Use a vacuum cleaner or soft brush to clean the
Pre-Filter
•
If it is excessively soiled, rinse in room temperature water.
•
Do not use detergent or soap.
•
Allow the filter to dry for 24 hours or more before
using.
•
Intervals between filter cleaning may vary
depending on the air quality in the environment.
•
Do not use hot water over 104
o
F.
•
Do not use detergent or soap.
•
Allow the filter to dry for 24 hours or more before
using.
NOTICE
Do not use benzene, alcohol, or other volatile fluids,
which may cause damage or discoloration.
Cleaning the Exterior & Interior:
Wipe with a soft damp cloth using room temperature
water.
•
Afterwards, wipe it down with a clean, dry cloth.
Open the front panel and clean the interior with a
vacuum cleaner.
•
For optimal performance, clean every 1-2 months.
NOTICE
•
When cleaning the unit, always unplug the power cord
first and then wait until the unit has cooled down.
•
Never disassemble, repair, or modify this unit yourself.
•
Do not use flammable sprays or liquid detergents.
•
Do not allow children to clean or maintain the unit.
•
Before cleaning or maintaining, ensure unit is unplugged.
