COOKTOP USE

IMPORTANT: When cooktop is in use, the Self-Cleaning cycle

will be disabled. When the Self-Cleaning cycle is in use, the

cooktop will be locked.

Ceramic Glass (on some models)

The surface cooking area will glow red when an element is ON.

Some parts of the surface cooking area may not glow red when

an element is ON. This is normal operation. It will also randomly

cycle off and back on again, even while on High, to keep the

cooktop from extreme temperatures.

It is normal for the surface of light-colored ceramic glass to

appear to change color when surface cooking areas are hot.

As the glass cools, it will return to its original color.

Clean the cooktop after each use to help avoid scratches,

pitting, abrasions, and to condition the glass surface. Ceramic

Glass Cooktop cleaner and a Cooktop Scraper are also

recommended for stubborn soils. Do not use abrasive cleaners,

cleaning pads, or harsh chemicals for cleaning. The Cooktop

Care Kit Part Number 31605 contains all of the items needed to

clean and condition your ceramic glass cooktop. Refer to the

“Range Care” section for additional information.

IMPORTANT: To avoid permanent damage to the cooktop

surface and to make soils easier to remove, clean the cooktop

after each use to remove all soils.

■ Avoid storing jars or cans above the cooktop. Dropping

a heavy or hard object onto the cooktop could crack the

cooktop.

■ To avoid damage to the cooktop, do not leave a hot lid on

the cooktop. As the cooktop cools, air can become trapped

between the lid and the cooktop, and the ceramic glass

could break when the lid is removed.

■ For foods containing sugar in any form, clean up all spills

and soils as soon as possible. Allow the cooktop to cool

down slightly. Then, while wearing oven mitts, remove the

spills using a scraper while the surface is still warm. If sugary

spills are allowed to cool down, they can adhere to the

cooktop and can cause pitting and permanent marks.

■ To avoid scratches, do not slide cookware or bakeware

across the cooktop. Aluminum or copper bottoms and rough

ﬁnishes on cookware or bakeware could leave scratches or

marks on the cooktop.

■ Do not cook popcorn in prepackaged aluminum containers

on the cooktop. They could leave aluminum marks that

cannot be removed completely.

■ To avoid damage to the cooktop, do not allow objects that

could melt, such as plastic or aluminum foil, to touch any

part of the entire cooktop.

■ To avoid damage to the cooktop, do not use the cooktop as

a cutting board.

■ Use cookware about the same size as the surface cooking

area. Cookware should not extend more than

" (1.3 cm)

outside the area.

■ Use ﬂat-bottomed cookware for best heat conduction and

energy efﬁciency. Cookware with rounded, warped, ribbed,

or dented bottoms could cause uneven heating and poor

cooking results.

■ Determine ﬂatness by placing the straight edge of a ruler

across the bottom of the cookware. While you rotate the

ruler, no space or light should be visible between it and the

cookware.

■ Cookware designed with slightly indented bottoms or small

expansion channels can be used.

■ Make sure the bottoms of pots and pans are clean and dry

before using them. Residue and water can leave deposits

when heated.

■ To avoid damage to the cooktop, do not cook foods directly

on the cooktop.

Ceramic Glass Cooktop Cleaning (on some models)

Clean the cooktop after each use to help avoid scratches,

pitting, abrasions and to condition the glass surface. Ceramic

Glass Cooktop cleaner and a Cooktop Scraper are also

recommended for stubborn soils. Do not use abrasive cleaners,

cleaning pads, or harsh chemicals for cleaning. The Cooktop

Care Kit Part Number 31605 contains all of the items needed to

clean and condition your ceramic glass cooktop. Refer to the

“Range Care” section for additional information.

IMPORTANT: To avoid permanent damage to the cooktop

surface and to make soils easier to remove, clean the cooktop

after each use to remove all soils.

WARNING

Fire Hazard

Turn off all controls when done cooking.

Failure to do so can result in death or fire.

REMEMBER: When range is in use or (on some models)

during the Self-Cleaning cycle, the entire cooktop area may

become hot.

A. Surface cooking area

B. Cookware/canner

" (1.3 cm) maximum overhang
