Calculating Vent System Length

To calculate the length of the system you need, add the

equivalent feet (meters) for each vent piece used in the system.

7" (17.8 cm) Round Vent System

Vent Piece Round

45° elbow 2.5 ft

(0.8 m)

90° elbow 5.0 ft

(1.5 m)

7" (17.8 cm) wall cap 0.0 ft

(0.0 m)

3¹⁄

" x 10" (8.3 cm x 25.4 cm)

to 7" (17.8 cm)

4.5 ft

(1.4 m)

3¹⁄

" x 10" (8.3 cm x 25.4 cm)

to 7" (17.8 cm) 90° elbow

5.0 ft

(1.5 m)

Example vent system

Maximum Recommended Length = 50 ft (15.2 m)

1 - 90° elbow = 5.0 ft (1.5 m)

1 - wall cap = 0.0 ft (0.0 m)

8 ft (2.4 m) straight = 8.0 ft (2.4 m)

Length of 7" (17.8 cm) system = 13.0 ft (3.9 m)

3¹⁄

" x 10" (8.3 cm x 25.4 cm) Vent System

Vent Piece

3¹⁄

" x 10" (8.3 cm x 25.4 cm)

90° elbow

5.0 ft

(1.5 m)

3¹⁄

" x 10" (8.3 cm x 25.4 cm)

ﬂat elbow

12.0 ft

(3.7 m)

3¹⁄

" x 10" (8.3 cm x 25.4 cm)

wall cap

0.0 ft

(0.0 m)

Example vent system

Maximum Recommended Length = 35 ft (10.7 m)

1 - 90° elbow = 5.0 ft (1.5 m)

8 ft (2.4 m) straight = 8.0 ft (2.4 m)

1 - wall cap = 0.0 ft (0.0 m)

Length of 3¹⁄

" x 10" (8.3 cm x 25.4 cm)

system

= 13.0 ft (3.9 m)

Electrical Requirements

Observe all governing codes and ordinances.

Ensure that the electrical installation is adequate and in

conformance with National Electrical Code, ANSI/NFPA 70

(latest edition), or CSA Standards C22.1-94, Canadian Electrical

Code, Part 1 and C22.2 No. 0-M91 (latest edition) and all local

codes and ordinances.

If codes permit and a separate ground wire is used, it is

recommended that a qualiﬁed electrician determine that the

ground path is adequate.

A copy of the above code standards can be obtained from:

National Fire Protection Association

1 Batterymarch Park

Quincy, MA 02169-7471

CSA International

8501 East Pleasant Valley Road

Cleveland, OH 44131-5575

all cap

7" (17.8 cm) round

90˚ elbow

2 ft (0.6 m)

6 ft (1.8 m)

Wall cap

" x 10"

(8.3 x 25.4 cm)

elbow

2 ft

(0.6 m)

6 ft (1.8 m)
