Manual

Press the button again to go back to the “Normal rinse” rinse type.

Delay Timer

To set the selected programme to start at a later time , press the button

to set the desired delay time. “Waiting” or “Starts in” is indicated on the

display when this option is enabled. To cancel the delayed start, press the

button again until the value ‚‘‘--:--‘‘ is shown on the display.

This option enhances washing performance by generating steam to inhibit

the proliferation of the main bad odour sources inside the machine. After

steam phase, the washing machine will perform gentle tumbling through

slow rotations of the drum. option starts after the cycle ends for a

maximum duration of 6h and you can interrupt at any time by pressing any

button on control panel or turning the knob.

(*) Wait around 5’ before open the door.

Steam Hygiene

This option enhances washing performance by generating steam during

the wash cycle that eliminates any bacteria from bres while treating them

at the same time. Place the laundry in the drum, choose a compatible

programme and select option “ “.

! The steam generated during washing machine operation may cause the

porthole door to become hazy.

Easy Iron

By selecting this function, the wash and the spin cycles will be modied in

order to reduce the formation of creases.

Temperature

Every programme has a predened temperature. If you want to change the

temperature, press the “Temperature” button. The value appears on the

display.

Spin

Every programme has a predened spin speed. If you want to change the

spin speed, press the “Spin” button. The value appears on the display.

Demo mode

To deactivate this function, switch the washing machine OFF. Than press

and hold “Start/Pause” button, within 5 seconds press also

“ON/OFF” button and hold both buttons for 2 seconds.

KEY LOCK

To lock the control panel, press and hold the “KEY LOCK” button for

approximately 3 seconds. When the display visualises “KEY LOCK ON” the

control panel is locked (with the exception of the ON/OFF button). This

prevents unintentional changes to programmes, especially with children

near the machine. To unlock the control panel, press and hold the “KEY LOCK”

button for approximately 3 seconds.

BLEACHING

If you wish to bleach the laundry, load the washing machine and set the

“Rinse+Spin” programme.

Start the machine and wait for it to complete the rst water lling cycle

(roughly 2 minutes). Put the machine in pause mode by pressing the

“Start/Pause” button , open the detergent drawer and pour the bleach

(observe the recommended doses indicated on the package) into the

main wash compartment where the partition was previously mounted.

Restart the cycle by pressing the “Start/Pause” button .

If desired, it is possible to add fabric softener into the appropriate

compartment of the detergent drawer.

HINTS AND TIPS

Sort your laundry according to

Type of fabric/care label (cotton, mixed bres, synthetics, wool, handwash

items). Colour (separate coloured and white items, wash new coloured

items separately). Delicates (wash small items – like nylon stockings – and

items with hooks – like bras – in a cloth bag or pillow case with zip).

Empty all pockets

Objects like coins or lighters can damage your laundry as well as the drum.

Follow the dosage recommendation / additives

It optimizes the cleaning result, it avoids irritating residues of surplus

detergent in your laundry and it saves money by avoiding waste of surplus

detergent

Use low temperature and longer duration

The most ecient programmes in terms of energy consumption are

generally those that perform at lower temperatures and longer duration.

Observe the load sizes

Load your washing machine up to the capacity indicated in the

“PROGRAMME CHART” table to save water and energy.

Noise and remaining moisture content

They are inuenced by the spinning speed: the higher the spinning speed

in the spinning phase, the higher the noise and the lower the remaining

moisture content.

DESCALE AND CLEAN PROCEDURE

A message on the display will regularly (roughly every 50 cycles) advise the

user to run an automatic cleaning cycle to clean the washing machine and

combat limescale build-up and bad odours.

For optimal maintenance we suggest using WPRO Limescale and grease

remover, according to the instructions shown on the package. The product

can be purchased by contacting the technical assistance service or through

the website www.whirlpool.eu.

Whirlpool declines all liability for any damages to the appliance caused by the

use of other cleaning products for washing machines available on the market.

CLEANING & MAINTENANCE

For any cleaning and maintenance, switch o and unplug the washing

machine. Do not use ammable uids to clean the washing machine.

Clean and maintain your washing machine periodically (at least 4 times per

year).

Cleaning the outside of the washing machine

Use a soft damp cloth to clean the outer parts of the washing machine. Do

not use glass or general purpose cleaners, scouring powder or similar to

clean the control panel – these substances might damage the printing

Checking the water supply hose

Check the inlet hose regularly for brittleness and cracks. If damaged, replace

it by a new hose available through our After-Sales Service or your specialist

dealer. Depending on the hose type:

If the inlet hose has a transparent coating, periodically check if the colour

intensies locally. If yes, the hose may have a leak and should be replaced.

Cleaning the water lter / draining residual water

If you used a hot wash programme, wait until the water has cooled down before

draining any water. Clean the water lter regularly, to avoid that the water

cannot drain after the wash due to obstruction of the lter. If the water cannot

drain, the display indicates that the water lter may be clogged.

Remove the plinth by using the removable plastic partition of the detergent

dispenser: push downwards one side of the plinth with your hand, then

push the removable plastic partition into the gap between plinth and front

panel and pry open the plinth. Place a broad, at container beneath the

water lter, to collect the drain water. Slowly turn the lter counterclockwise

until water ows out. Let the water ow out, without removing the lter.

When the container is full, close the water lter by turning it in clockwise.

Empty the container. Repeat this procedure until all the water has drained.

Lay a cotton cloth beneath the water lter, which can absorb a small

amount of rest water. Then remove the water lter by turning it out anti

clockwise. Clean the water lter: remove residues in the lter and clean it

under running water. Insert the water lter and reinstall the plinth: Reinsert

the water lter again by turning it in clockwise direction. Make sure to turn

it in as far as it goes; the lter handle must be in vertical position. To test

water tightness of the water lter, you can pour about 1 liter of water into

the detergent dispenser. Then reinstall the plinth.

Cleaning the detergent dispenser

Remove the detergent dispenser by pressing on the release button and at

the same time pulling out the detergent dispenser. Remove the insert from

the detergent dispenser, as well as the insert of the softener compartment.

Clean all parts under running water, removing all detergent or softener

residues. Wipe the parts dry with a soft cloth. Reinstall the detergent

dispenser and push it back into the detergent compartment.

ACCESSORIES

Contact our After-Sales Service to check if the following accessories are

available for your washing machine model.

Stacking kit shelf

By which your dryer can be xed on top of your washing machine to save

space and to facilitate loading and unloading your washing machine in the

higher position.

TRANSPORT AND HANDLING

Never lift the washing machine by holding it at the worktop.

Pull out the mains plug, and close the water tap. Make sure that door and

detergent dispenser are properly closed. Disconnect the inlet hose from the

water tap, and remove the drain hose from your draining point. Remove all

rest water from the hoses, and x them so that they cannot get damaged

during transport. Ret the transport bolts. Follow the instructions for

removing the transport bolts in the INSTALLATION GUIDE in reverse order.
