Manual Toshiba TLP-T501 Projector

Manual

27

Operations

26

INPUT

R-CLICK

PJ MODE LASER

VOL.

+

VOL.

-

MENU / ENTER

Preparations

• Place the projector, and correctly connect all devices.

• To operate via the remote control, [PJ MODE]

p.20

must be

selected.

Press the PJ MODE button. The button lights up. This light

will go out 30 seconds after operations are complete. If

necessary, press the button again.

1

Turn on the power.

Turn on the power, following the instructions in “Turning on the power”

p.25

.

2

Select language (When using for first time).

When the projector is used for the first time after purchase, a message is displayed on

the screen, and the language menu appears. The default language is English.

(If the screen focus is not on the menu, adjust according to step

6

.)

q Use the buttons to select the desired

language, and press the button.

A message displays the selected language.

w Press the button to apply.

Notes

• After the first time the projector is turned on, the Language menu does not appear

upon startup. However, from the Reset menu

p.55

select “Reset all” to display the

Language menu the next time the projector is turned on.

• The language can also be set via the Display setting menu

p.54

.

• This owner’s manual assumes that English has been selected.

3

Place connected device(s) in operating status.

Turn on and boot up connected computers and other devices.

4

Select input.

q Press the INPUT button.

A list of inputs appears on the screen.

w Use the buttons to select the desired

input, and press the button.

The picture for the selected input is projected.

Basic operations

Remote Control

[PJ MODE]

Lights up

English

Français

Português

Deutsch

Italiano

Español

................

..............

..............

................

...............

..........

...................

.......

.......

...................

English

French

German

Italian

Spanish

Portuguese

Japanese

Chinese (simplified)

Chinese (traditional)

Korean

Computer (1)

Y/P

B/PR(1)

Computer (2)

Y/P

B/PR(2)

Video

S-video

PC Card

Camera

Turning the power on and off (Continued)

Turning the power off

1

Press the ON/STANDBY button.

A message appears on the screen, confirming that you wish to shut off the power. This

message will disappear after a moment. (This operation is no longer valid after the

message disappears.)

2

Press the ON/STANDBY button again.

The screen turns off, but the internal cooling fan continues to operate for a short while.

Then, the projector goes into standby mode.

When cooling lamp During internal cooling After cooling complete

FAN TEMP LAMP ONFAN TEMP LAMP ON

A

FAN TEMP LAMP ON

B C

(Green) (Green) (Orange)

Flashing

(Green) (Off) (Orange)

(Off) (Off) (Orange)

A

During cooling, the LAMP indicator flashes. In this state, the power cannot be

turned back on. In addition, unplugging the power cord in this state will shorten

the life of the lamp.

B

After the LAMP indicator goes off, the cooling fan continues to operate for a

short while, in order to expel excess internal heat. If you are in a hurry, there is

no problem with unplugging the power cord in this state.

C

In standby

Note

• The projector consumes about 6W of power in standby (models equipped with PC card

slot consume about 18W). We recommend that you unplug the power cord if you will not

be using the projector for an extended period.

PRECAUTIONS

• Before unplugging the power cord, make sure that the LAMP indicator is off. Unplugging

the power cord and cutting off the power while the projector is running or being cooled

will shorten the life of the lamp. However, please unplug the power cord if the

projector locks up or acts abnormally.

• If the power cord was unplugged before cooling was complete, give the lamp sufficient

time to cool before plugging it back in. If the lamp overheats it may fail to light, and its

lifetime will be shortened.

LCD Panels

LCD panels wear out. In order to prolong the lifetime of your LCD panel, take the

following precautions.

• In order to extend the lifetime of the LCD panel, always turn off the power when not in

use, and make sure that the lamp is off. Keeping the lamp off is also very effective at

saving electricity.

• If the air filter becomes dirty and clogged, the projector’s internal temperature will rise,

shortening the lifetime of the LCD panel and causing malfunctions. Clean the air filter

from time to time

p.56

, and replace it periodically. Contact the store where you

purchased your projector, or your local Service Station for replacement air filters.
