Manual

Operations

■ Connecting the power cord

Insert the power cord connector into the

AC IN socket of the projector.

Insert the power cord plug into a wall or

other power outlet.

■ Turning the power on

Turn on the main power switch

The ON indicator will change to

orange, indicating standby mode.

Press the ON/STANDBY

button.

The power turns on, and the following

3 green indicators light: ON, LAMP,

and FAN. After a moment, the start-up

screen appears.

Start-up screen

Control panel

Remote

Control

Notes

• The start-up screen will disappear after a moment. You can dismiss the start-up screen

before this by performing any operation. You can also configure the start-up screen not to

appear via the Display setting menu

p.31

• The first time you use the projector after purchase, after the start-up screen disappears,

the Language menu is displayed

p.24

■ Turning the power off

Press the ON/STANDBY button.

A message appears on the screen, confirming that you wish to shut off the power. This

message will disappear after a moment. (This operation is no longer valid after the

message disappears.)

Press the ON/STANDBY button again.

The screen turns off, but the internal cooling fan continues to operate for a short while.

Then, the projector goes into standby mode.

When cooling lamp During internal cooling After cooling complete

(Orange) (Orange)

(Green)

(Off)

(Orange)

B C

Flashing

(Green)

(Off)

LAMP

TEMP

FAN

LAMP

TEMP

FAN

LAMP

TEMP

FAN

During cooling, the LAMP indicator flashes. In this state, the power cannot be

turned back on.

After the LAMP indicator goes off, the cooling fan continues to operate for a

short while, in order to expel excess internal heat. If you are in a hurry, there is

no problem with unplugging the power cord or turning off the main power switch

in this state.

In standby mode

Note

• The projector consumes about 6W of power in standby. We recommend that you unplug

the power cord or turn off the main power switch if you will not be using the projector for

an extended period.

PRECAUTION

• If the power cord is unplugged before cooling is complete, give the lamp time (about 5

minutes) to cool before plugging it back in. If the lamp overheats, it may fail to light, and

its lifetime will be shortened.

(Orange)

LAMP

TEMP

FAN

(Supplied) Power cord connector

CAUTION

• Do not look into the lens while the lamp is on. The strong light from the lamp may cause

damage to your eyes or sight.

• Do not block the air intake or exhaust. Doing so could cause a fire due to internal overheating.

• Do not place your hands, face, or other objects near the air exhaust. Doing so could cause

burns, deform/break the object.

■ Removing the lens cover

Be sure to remove the lens cover when the power is

turned on. If it is left on, it could become deformed due

to heat.

Turning the power on and off

Operations
