Manual

20 21

Operations

p.41

Before connection

• Read the owner’s manual of the device you are connecting to the projector.

• Some types of computer cannot be used or connected to this projector.

Check for an RGB output terminal, supported signal

p.39

, etc.

•Turn off the power of both devices before connecting.

• The figure below is a sample connection. This does not mean that all of these devices

can or must be connected simultaneously. (Dotted lines mean items can be exchanged.)

Notes

• COMPUTER terminals 1 and 2 function identically.

• The AUDIO IN terminal doubles for devices connected to COMPUTER terminals 1 and 2.

Connection

Computer (for control)

VCR

Video recorder,

DVD player, etc.

Audio amplifier, etc.

To RS-232C

terminal

Control cable

To audio output

White (L)/Red (R)

To video

output

AV cable

(not supplied)

Video cable (not supplied)

To S-Video

output

To audio output

White (L)/Red (R)

S-Video cable

(not supplied)

Audio cable

(not supplied)

To audio input

White (L)/Red (R)

To RGB

output

RGB cable

(not supplied)

Audio cable

(not supplied)

To audio

output

To Y/CB/CR output

Green (Y)/Blue (C

B)/Red (CR)

Conversion adapter BNC-pin

(not supplied)

Monitor cable Mini

D-sub 15P-BNC

(not supplied)

To audio output

Audio cable

(not supplied)

RGB cable

(supplied)

To RGB output

ComputerComputer DVD video recorder, etc.

Turning the power on and off

Operations

■ Connecting the power cord

Insert the power cord connector into the

AC IN socket of the projector.

Insert the power cord plug into a wall or

other power outlet.

■ Turning the power on

Turn on the main power switch

The ON indicator will change to

orange, indicating standby mode.

Press the ON/STANDBY

button.

The power turns on, and the following

3 green indicators light: ON, LAMP,

and FAN. After a moment, the start-up

screen appears.

Start-up screen

Control panel

Remote

Control

Power cord connector

(Supplied)

CAUTION

• Do not look into the lens while the lamp is on. The strong light from the lamp may cause

damage to your eyes or sight.

• Do not block the air intake or exhaust. Doing so could cause a fire due to internal overheating.

• Do not place your hands, face, or other objects near the air exhaust. Doing so could cause

burns, deform/break the object.

■ Removing the lens cover

Be sure to remove the lens cover when the power is

turned on. If it is left on, it could become deformed due

to heat.

(Orange)
