Manual Sierra Designs Antares Tent

Manual

SIERRA DESIGNS 2011 Cherry Street, Unit 202 Louisville, CO 80027 Phone: 303-262-3050 Fax: 303-262-3051 Toll Free: 800-635-0461

A

F

C

D

E

B

G

H

insert

correct

Figure 1: Correct Pole Assembly

S I E R R A D E S I G N S





























ANTARES

Your Sierra Designs

ANTARES tent is very

easy to pitch and maintain.

Follow these instructions to

pitch your tent quickly, safely

and easily.

Figure 3: Clip-Loc

ANTARES TENT CONTENTS

Tent Body & Rainfly: 1 Portable Attic: 1

Tent Poles: 3 Footprint: 1

Tent Stakes: 8* Coffee Sling: 2

Guy Cords: 4 Pitching Instructions: 1

* Sierra Designs tent s include stakes for pitching the body and fly under normal conditions.

Additional stakes may be required in severe conditions.

Figure 4: Tent Fly (top view)

Figure 5: Fly Clip

Figure 2: Tent Body (top view)

First Pitch

In order to familiarize yourself with your new tent, we

suggest that you “test pitch” it before embarking on a

wilderness trip.

Select a Site

Look for a level spot that is protected from the wind in

order to ensure sleeping comfort. Clear the area of debris

such as sharp stones and sticks which might abrade or

puncture the tent floor. Choose an area that will drain well

when it rains.

Unfurl the Tent and Assemble the Poles

Unfurl the tent and lay the tent floor flat on the ground

with the doors unzipped. Carefully unfold the shock corded

pole sections and allow them to slide together. Do not

allow the poles to snap together: This can lead to serious

pole damage. Make certain that the insert of each pole sec

-

tion is fully inserted into the next pole section (Figure 1).

You will have two straight poles of equal length and

one shorter pole.

Stake Out the Tent Floor

Although the Antares is a completely freestanding tent,

we suggest that you always stake out the floor for greater

safety and stability, especially in high winds. First stake

the webbing loops at corners A and B (Figure 2). Then

move to the opposite end of the tent, pulling the webbing

loops at corners C and D until the tent is squarely and

tautly positioned, and stake down. Staking points E and F

is optional.

Erect the Tent

Insert the metal tips of one of the two long poles into the

grommets at points A and D, and the tips of the other into

the grommets at points B and C. Pull the two poles up so

they intersect at the center of the tent. Next, position your

-

self in the open doorway and hook the Clip-Loc

™

(Figure 3)

over the widest angle of this intersection (do not attach the

bungee cord yet). Following the tent seams between points

A and D, and B and C attach all of the Swift Clips

™

to their

corresponding tent poles. Now attach the bungee cord on

the Clip-Loc a at the apex of the tent by wrapping the bun

-

gee in the direction crossing the open gate of the clip. Wrap

the cord around the pole intersection two to four times,

depending on desired firmness, then slide the cord into the

groove on the backside of the clip to hold it taut (Figure 3).

Now take the remaining shorter pole and thread it through

the webbing loop attaching the Clip-Loc

to the apex of the

tent. Slide each of the pole ends into the pole buckets at

points G and H.

Fly Sheet

Making sure that the zippers are in front of the doors, drape

the fly over the tent. At the corners of the fly, points A, B,

C & D, are

3

/4” side-release “Fly Clip” buckles (Figure 4).

Clip these buckles (Figure 5) into their corresponding mates

at points A, B, C & D on the tent floor (Figure 2). By first

clipping the blue webbing strap on the rainfly to a blue

webbing strap on the body, you are guaranteed a fast, proper

rainfly set-up every time. Adjust the buckles to the desired

fit (Figure 4). Stake out the adjustable loops at points I, J,

K, & L. For increased stability and strength in high winds,

points M, N, O & P can be guyed out.
