1 2 3 4 5 6
:c- 90 °C °C (Temp.) Select the temperature (:= cold)
c- 1600* (rpm) Select the spin speed (* depending on the model) or (Rinse hold = no final spin,
laundry remains in the water after the final rinse,--- appears in the display panel).
1 - 24 h (Finished in) Programme end after
Status indicators Programme status indicators:
tüümüücü- ¯- Wash, rinse, spin, programme duration or end (- ¯-)
sChildlock apage 5
rOpen the washing machine door, add laundry apage 4, 5
Programme selector Display panel /
Options buttons
Start/Add
laundry
Additional
functions
Sorting and loading the laundry
Follow the manufacturer's care information.
According to the information on the care labels.
According to type, colour, soiling and temperature.
Do not exceed the maximum load apage 7.
Observe the important information apage 9.
Insert items of laundry of varying sizes.
Close the washing machine door. Take care not to trap items of laundry between the washing
machine door and the rubber seal.
Adding detergent and care products
Measure accordingly:
The amount of laundry, level of soiling, water hardness (ask your water supply company) and
manufacturer's instructions.
On models without an insert for liquid detergent:
Pour liquid detergent into the appropriate dispenser and place in the drum.
During operation: open the detergent drawer with care.
Individual settings
ʑ
Signal
ʑ
(Start/Add laundry)
To start the programme or to subsequently load additional laundry, and to activate/deactivate the childlock.
2. Set the volume
for ...
Set to
1 step, the
display panel
lights up
Press and
hold
+
1 step, release
Set to
skip
Button signals
Information signals
Set the
volume*
1 step Set the
volume*
* you may need to select
the function several
times.
1. Activating the
mode for setting the
signal volume
¢
¢
Insert for liquid detergent (depending on model), page 10
Compartment II: detergent for main wash,
water softener, bleach, stain remover
Your washing machine
Intended use
Contents Page
ʔIntended use .......................................................................................................................... 1
ʔProgrammes .......................................................................................................................... 1
ʔSetting and adjusting the programme ............................................................................. 3
ʔWashing ..............................................................................................................................3/4
ʔAfter washing ........................................................................................................................ 4
ʔIndividual settings ............................................................................................................5/6
ʔOverview of programmes ................................................................................................... 7
ʔSafety instructions ................................................................................................................ 8
ʔConsumption values ............................................................................................................8
ʔImportant information .........................................................................................................9
ʔInsert for liquid detergent ................................................................................................ 10
ʔCare ...................................................................................................................................... 10
ʔInformation on the display panel ................................................................................... 10
ʔInstructions for blockages ............................................................................................... 11
ʔWhat to do if.................................................................................................................. 12/13
ʔEmergency release ............................................................................................................ 13
ʔAfter-sales service.............................................................................................................. 13
Protection of the environment/Conservation tips
– Always fill the washing machine with a maximum amount of laundry for the relevant
programme.
– Wash normally soiled laundry without a prewash.
– The selectable temperatures apply to the care labels on the textiles. The
temperatures in the machine may deviate from this so that you get the optimum mix
of energy-saving and washing results.
– Measure the detergent according to the manufacturer's instructions and water
hardness.
– If you want to dry the laundry in the tumble dryer afterwards, select a spin speed
suggested by the dryer manufacturer.
Preparation
Before washing for the first time
Run a wash cycle without any laundry apage 9
Set** and adjust the programme
1
2
Washing
Compartment ~: fabric softener, starch
Compartment I: detergent for prewash
ʔFor domestic use only
ʔFor washing machine-washable fabrics and hand-washable wool in
detergent solution
ʔTo be operated with cold drinking water and commercially available
detergents and care products which are suitable for use in washing
machines.
– Do not leave children unattended near the washing machine.
– The washing machine is not to be used by children or persons
not familiar with the operating instructions.
– Keep pets away from the washing machine.
Dilute thick fabric softener and conditioner with water.
This prevents blockages.
Detergent drawer
with compartments I, II, ~
Control panel
Washing machine
door handle
Service flap
Washing machine door
Install correctly, according to the separate
installation instructions.
Check the machine
– Never use a damaged machine.
– Inform the after-sales service.
Connect the mains plug
– Make sure your hands are dry.
– Take hold of the plug only.
Turn the tap on
**If the s symbol is lit in the display
panel, Childlock active aDeactivate it,
page 5.
Additional functions and options buttons
aIndividual settings, page 5
Washing
End of programme when ...
... the (Start/Add laundry) button is off and - ¯- appears in the
display panel.
If the display panel lighting is off, press any button
a Energy-saving mode, page 5.
Cancel the programme
Programmes at high temperatures:
– To cool the laundry: select mRinse.
– Press (Start/Add laundry).
Programmes at low temperatures:
– Select Spin or lEmpty.
– Press (Start/Add laundry).
Change the programme if...
... you have selected the wrong programme by mistake:
– Reselect the programme.
– Press (Start/Add laundry). The new programme starts from the
beginning.
Top up laundry, if ... a page 5
... (Start/Add laundry) is pressed and then both of the §+ r
symbols are lit in the display panel. If ǯ is lit, the washing machine
door cannot be opened.
Press the (Start/Add laundry) button.
Individual settings
ʑ
Options buttons
The spin speed and temperature can be changed before and during the selected programme. The effects depend on
the programme progress.
ʑ
°C (Temperature)
You can change the displayed washing temperature. The maximum washing temperature that can be selected
depends on the programme that has been set.
ʑ
(Spin speed rpm) / c(Rinse hold = no final spin)
You can change the spin speed shown or select c(Rinse hold = no final spin, laundry remains in the water after the
last rinse, --- appears in the display panel). You can change the spin speed shown. The maximum selectable spin
speed depends on the model and on which programme is currently selected.
ʑ
(Finished in)
When you select the programme, the relevant progr. duration is displayed. You can delay the start of the programme be-
fore it begins. The "Finished in" time can be set in increments of one hour up to a max. of 24 hours. Press the (Fi-
nished in) button repeatedly until the desired number of hours is displayed (h = hour). Press (Start/Add laundry).
ʑ
Additional functions a overview of programmes, page 7
i speed Perfect For washing in a shorter time with a washing result comparable to that of the standard
programme. Maximum load aOverview of programmes, page 7.
¢üeco Perfect For saving energy with a washing performance comparable to that of the standard programme.
â (Easy-Iron)
Special spin sequence with subsequent fluffing. Gentle final spin at reduced speed. Residual
moisture in the laundry is increased slightly.
v (Water Plus)
Increased water level. Gentler treatment of the laundry.
ʑ
Childlock
s
in the display panel
You can lock the washing machine to prevent the functions you have set from being changed
inadvertently.
ON/OFF: after the start/end of the programme, press and hold (Start/Add laundry) for
approx. 5 seconds.
Note: The childlock can remain activated until you wish to start the next programme, even after
switching off the machine.
Then you can deactivate the childlock before starting the programme and activate it again as
necessary once the programme has started.
Note:
– The s symbolis lit: Childlock active.
– The s symbolflashes: Childlock active and then the programme selector is altered.
To prevent the programme from stopping, move the programme selector back to the
original programme, the s symbol is lit again.
ʑ
Add laundry
§+ orü
in the display panel
If you want to add additional items of laundry after the programme has started, press the
(Start/Add laundry) button. The machine checks whether adding laundry is possible.
§+ r are lit: Adding laundry is possible.
ǯflashing: Wait until §+ r are lit.
Note: Only open the washing machine door when both the §+ r symbols are lit.
ǯ: It is not possible to add laundry.
Note: for safety reasons, the washing machine door remains locked when the water level and/
or temperature is high, or during spinning.
To continue the programme, press the (Start/Add laundry) button.
ʑ
Energy saving mode
If the washing machine is switched on and is not operated for several minutes before the programme starts or at the
end of the programme, the display panel light goes out and the (Start/Add laundry) button flashes.
Press any button to turn the light back on.
All buttons are sensitive and need only
to be touched lightly. If you press and
hold the (Finished in) option button,
the appliance automatically runs
through the settings options.
3
Programmes
Detailed overview of programmes apage 7.
Temperature and spin speed can be selected individually,
depending on the selected programme and programme progress.
ÊCottons Hard-wearing fabrics
+ Prewash Hard-wearing fabrics, prewash at 30 °C
Ï Easy-Care Easy-care fabrics
+ Prewash Easy-care fabrics, pre-wash at 30 °C
Í Mix Different types of laundry
5 Delicates/Silk Delicate washable fabrics
dWool ÉHand/machine-washable wool
m Rinse Power rinse + with spin
Spin Extra spin with selectable spin speed
l Empty Empty the rinsing water when c
(Rinse hold = no final spin) is activated
Gentle spin Extra spin with reduced spin speed
6 Super Quick 15' Super Quick programme
c Outdoor Wear All-weather, sportswear and outdoor wear
apage 9
g Shirts/Business Non-iron shirts
Î Easy-Care Special Dark-coloured fabrics
Switch off
Turn the programme selector to Off.
Turn off the tap
Not required for AquaStop models aRefer to Installation
instructions.
Remove the washing
Open the washing machine door and remove the washing.
If (Rinse hold = no final spin) active: turn the programme selector to
l Empty or Spin. Select the spin speed if necessary.
Press (Start/Add laundry).
– Remove any foreign objects - risk of rusting.
– Leave the washing machine door and detergent drawer open
so that any residual water can dry away.
Congratulations äyou have chosen a modern, high-quality domestic appliance
manufactured by Siemens. This washing machine is distinguished by its economical
water and energy consumption.
Each machine that leaves our factory has been inspected thoroughly to ensure that it
functions properly and is in perfect condition.
For more information on our products, accessories,
replacement parts and services, see our website www.siemens-home.com
or contact our after-sales service centres.
Programme selector for switching
the machine on and off and for
selecting the programme. Can be
turned in either direction.
Drum interior light
(depending on model) comes on
when the door is opened or
closed, or when a programme is
started; goes out automatically.
Press
(Start/Add laundry)
7
Overview of programmes aCheck the consumption values table on page 8 and the instructions on page 9.
* reduced load when using the additional i speed Perfect function.
As a short programme, Mix 40 °C is ideal, when maximum spin speed is selected.
Programmes without prewash - add detergent to compartment II, programmes with prewash - distribute the detergent between compartments I and II.
Programmes °C max.
Type of laundry
Additional functions; options; information
ÊCottons
: - 90 °C
8 kg/
5 kg*
Hard-wearing fabrics, heat-resistant fabrics made of
cotton or linen
i speed Perfect*, ¢üeco Perfect, â (Easy-Iron), v (Water Plus),
c(Rinse hold = no final spin)
+ Prewash
Ï Easy-Care
: - 60 °C
3,5 kg
Easy-care fabrics made of cotton, linen, synthetic fibres
or blended fabrics
i speed Perfect, ¢üeco Perfect, â (Easy-Iron), v (Water Plus),
c(Rinse hold = no final spin)
+ Prewash
Í Mix :c- 40 °C Fabrics made of cotton or easy-care fabrics
i speed Perfect, ¢üeco Perfect, â (Easy-Iron), v (Water Plus),
c(Rinse hold = no final spin) ;
different types of laundry can be washed together
Î Easy-Care Special :c- 40 °C
Dark-coloured fabrics made of cotton and dark easy-
care fabrics
i speed Perfect,
¢üeco Perfect, â (Easy-Iron), v (Water Plus),
c(Rinse hold = no final spin) ; reduced rinse and final spin
5 Delicates/Silk :c- 40 °C
2 kg
For delicate, washable fabrics, e.g. made of silk, satin,
synthetic fibres or blended fabrics (e.g. curtains)
i speed Perfect,
¢üeco Perfect, â (Easy-Iron), v (Water Plus),
c(Rinse hold = no final spin) ; no spin between the rinse cycles
d Wool É:c- 40 °C
Hand or machine-washable fabrics made of wool or
containing wool
c(Rinse hold = no final spin);
Particularly gentle wash programme to prevent shrinkage of laundry.
Longer programme breaks (fabrics rest in the detergent solution)
6 Super Quick 15' :c- 40 °C
Easy-care fabrics made of cotton, linen, synthetic fibres
or blended fabrics
c(Rinse hold = no final spin); Short programme, approx. 15 minutes,
suitable for lightly soiled laundry
g Shirts/Business :c- 40 °C
Non-iron shirts made of cotton, linen, synthetic fibres or
blended fabrics
i speed Perfect, ¢üeco Perfect, â (Easy-Iron), v (Water Plus),
c(Rinse hold = no final spin) ;
spin only briefly, then hang up to drip dry
cüOutdoor Wear :c- 40 °C
Washing with subsequent waterproofing of all-weather,
sportswear and outdoor clothing, and clothing with a
weatherproof membrane, waterproof fabrics
i speed Perfect, ¢üeco Perfect, v (Water Plus);
More information about the textile guard function apage 9,
reduced final spin at intervals
Additional programmes m Rinse, Spin, l Empty, Gentle spin
9404 / 9000984851
*984851*
WM16S465DN
Siemens Electrogeräte GmbH
Carl-Wery-Str. 34
81739 München / Deutschland
Join the conversation about this product
Here you can share what you think about the Siemens WM16S465DN Washing Machine. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.
