Manual

1.Open the detergent box by pulling in the

direction of the arrow as shown in the

figure and then put the powder detergent

in the detergent box.

2.Put in one-time amount

of detergent evenly

so the detergent may

not brim over the box.

When a proper amount(one time does) of fiber softener

is stored in the softener inlet, it is automatically put in

at the last rinsing course.*In case the hot water only is

connected, this operation may not be made.

base line

*When too much softner is stored above the base line,

it may flow down at any time.

Place a rag under the washer filter

not to wet the floor.

Rotate the filter counterclockwise and

pull out the filter.

3.Remove dirts and rotate the filter

clockwise until it locks in position.

HOW TO CLEAN THE FILTER

TROUBLESHOOTING

Washing machine won't work

Is the water tap opened?

Is the washer plugged in?

Is the power cut off?

Is there enough water?

Is the water tap opened?

Is the water cut off?

Is the water supply hose or hose

connection clogged?

Is the water tap frozen?

If water is not supplied in 1 hour,

a buzzer will sound, and the remaining

time indicator will show "7E".

Water is not supplied

Spinning does not work

Is the laundry spread out evenly

in the washer?

Is the washer set on a sturdy

flat surface?

This sign means power is not cut

off automatically.

Make sure there is lighting

on the lamp whenever press the

power button.

Power won't cut off

Water is overflowed

Restart after spinning.

If the error sign still indicates,

call agency.

Water dose not drain

Is the drain hose down?(No pump)

Is the drain hose frozen?

Is the drain hose clogged?

If the water dose not drain in 6

minutes, a buzzer will sound,and the

remaining time indicator will show "E".

If the filter net is clogged after washing, push up and pull out two nets .Wash the filter net in the water.

CLEANING THE FILTER NET

Disassemble the D-Fall

guide with the (-)driver,

and make clean.

After making clean,

reassemble the D-Fall

guide.

1.Remove the adaptor

from the water

supply hose.

2.First,using a "+" type

screw driver, loosen the

four screws on the adaptor.

Next,take the adaptor and

turn part(b) following the

arrow for gap about 5mm

between them.

3. Connect adaptor to the

water tap by tightening

the screws firmly.

Then,turn part (b)

following the arrow and

put (a) and (b)together.

5. Connect the other end of

the water supply hose to

the inlet water valve at the

back of the washer.

Screw the hose clockwise

all the way in.

If the water tap is a screw

type,assemble a water

supply hose that fits to the

tap as shown.

NOTICE After completing connection,if water leaks from the hose,then repeat the same setps.

Use the most conventional type of faucet for water supply.

In case the faucet is square or too big,remove the spacing ring before inserting the faucet into the adaptor.

INSTALLATION

Leave some space

Maintain at least 10cm between the washer and the wall.

Place the washer on a sturdy flat surface.

If the washer is placed on an uneven or weak surface,

noise or vibration occurs. (Allowable is 2˚)

Adjust the legs for even placement.

Never install the washer near water.

Do not place the washer in steamy rooms or where

the washer is directly exposed to rain.Moisture may

destroy the electrical insulation causing an electrical

shock hazard.

Avoid direct sunlight or heaters.

As plastic and electrical components are affected

by direct heat,never place the washer near furnaces,

boliers,etc.Do not place under direct sunlight.

After pressing the joint ring(a), insert the drain hose(b)

to drain direction.

Rear-side

CONNECTING THE WATER SUPPLY HOSE

LEVELLING

ENVIRONMENT

ASSEMBLING THE SOUND ABSORBING

PANEL

CONNECTING THE DRAIN HOSE

(a)

(b)

LockLoosen

1.Adjust the side horizontality

➀

first and

the front horizontatily

②

next.

2.If the thread is not within the limit,

adjust the height of the legs.

4.Connect the water supply

hose to the adaptor. Pull down

the part (c) of the water supply

hose .When the part (c)is released,

the hose is automatically

connected to the adaptor

making a 'click' sound.

70~80cm

Be sure to join tightly

the drain hose into the

drain-outlet on the

back of the machine.

Install the drain hose

in the position of about

70~80cm above

the ground.

IN CASE OF PUMP-DRAINED WASHER

CLEANING THE DOUBLE FALL OUTLET

HOW TO PUT THE DETERGENT IN

HOW TO PUT IN RINSE

Tilt the washer a little and lift up the panel

until it clicks as shown in the figure

3.Adjust the legs on feet

for levelling .

Filter

RAG

OPEN
