Manual Samsung GT-C3330 Mobile Phone

Manual

Declaration of Conformity (R&TTE)

We, Samsung Electronics

declare under our sole responsibility that the product

GSM Mobile Phone : GT-C3330

to which this declaration relates, is in conformity with the following standards and/or

other normative documents.

SAFETY EN 60950-1 : 2006 + A11 : 2009

SAR EN 50360 : 2001/AC2006

EN 62209-1 : 2006

EMC EN 301 489-01 V1.8.1 (04-2008)

EN 301 489-07 V1.3.1 (11-2005)

EN 301 489-17 V2.1.1 (05-2009)

RADIO EN 301 511 V9.0.2 (03-2003)

EN 300 328 V1.7.1 (10-2006)

We hereby declare that [all essential radio test suites have been carried out and that]

the above named product is in conformity to all the essential requirements of Directive

1999/5/EC.

The conformity assessment procedure referred to in Article 10 and detailed in Annex[IV]

ofDirective1999/5/EChasbeenfollowedwiththeinvolvementofthefollowingNotied

Body(ies):

BABT, Forsyth House,

ChurcheldRoad,

Walton-on-Thames,

Surrey, KT12 2TD, UK*

Identicationmark:0168

The technical documentation kept at :

Samsung Electronics QA Lab.

which will be made available upon request.

(Representative in the EU)

Samsung Electronics Euro QA Lab.

Blackbushe Business Park, Saxony Way,

Yateley, Hampshire, GU46 6GG, UK*

2011.08.30 Joong-Hoon Choi / Lab Manager

(place and date of issue) (name and signature of authorised person)

* It is not the address of Samsung Service Centre. For the address or the phone

number of Samsung Service Centre, see the warranty card or contact the retailer

where you purchased your product.

Set and use alarms

To set a new alarm

1. In Menu mode, select Alarms.

2. Select Create.

3. Set alarm details.

4. Select Save.

Thesnoozefeaturesetsthephonetorepeatthealarm

afteraspeciedlengthoftime.Tosetthelengthoftime

forthesnoozefeature,selectSettings→Snooze.

To stop an alarm

When the alarm sounds,

Tap and hold • Stop to stop the alarm.

Tap and hold • Snoozetosilencethealarmforthesnooze

period.

To deactivate an alarm

1. In Menu mode, select Alarms.

2. Select the dot next to the alarm you want to deactivate.

Enter text

To change the text input mode

Select • EN to change the input language.

Select • T9 to switch between T9 and ABC modes. The dot

turns green in T9 mode.

Select • 123 or sym to switch to Number or Symbol mode.

T9 mode

1. Press appropriate virtual keys to enter an entire word.

2. When the word displays correctly, select

to insert a

space. If the correct word does not display, select

to

select an alternate word.

ABC mode

Press an appropriate virtual key until the character you want

appears on the display.

Number mode

Press an appropriate virtual key to enter a number.

Symbol mode

Press an appropriate virtual key to enter a symbol.

3. Lock the memory card in place.

Memory card

4. Replace the battery and the back cover.

Instructional icons

Caution: situations that could cause damage to your

phone or other equipment

Note: notes, usage tips, or additional information

→

Followed by: the order of options or menus you

must select to perform a step; for example: In

Menu mode, select Messages→Create message

(represents Messages, followed by Create

message)

[ ]

Square brackets: phone keys; for example: [

]

(represents the Power/End key)

Use a stylus and the touch screen

Learn basic actions to use the stylus and touch screen.

To avoid scratching the touch screen, do not use sharp

tools.

To use other features for text input

To move the cursor, select • and then the virtual

navigation key.

To delete characters one by one, select •

. To delete

words quickly, tap and hold

.

To enter punctuation marks, select • 1 repeatedly.

Select •

to change case.

Add a new contact

The memory location to save new contacts may be

preset depending on your service provider. To change

the memory location, in Menu mode, select Contacts

→Settings→Save new contact to→amemory

location.

1. In Idle mode, select Keypad and enter a phone number.

2. Select

.

3. Select Create contact→amemorylocation(if

necessary).

4. Select a number type (if necessary).

5. Enter contact information.

6. Select Save to add the contact to memory.

For the optimal use of the touch screen, remove the

protectionlmbeforeusingyourphone.

Tap: Touch once with the stylus to select or launch a •

menu, option, or application.

Tap and hold: Tap an item and hold it for more than 2 •

seconds.

Drag: Tap and drag the stylus up, down, left, or right to •

move to items on lists.

A special slot for storing the stylus is included on the back

of your phone.

Turn your phone on or off

To turn your phone on,

1. Press and hold [

].

2. Enter your PIN and select OK (if necessary).

3.Whenthesetupwizardopens,customiseyourphoneas

desired by following the screen.

If the battery remains fully discharged or removed from

the device, the date and time will be reset.

To turn your phone off, repeat step 1 above.

Access menus

To access your phone’s menus,

1. In Idle mode, select Menu to access Menu mode.

2. Scroll left or right to a main menu screen.

Use the camera

To capture photos

1. In Idle mode, press and hold the Camera key to turn on

the camera.

2. Rotate the phone anti-clockwise to landscape view.

3. Aim the lens at the subject and make any adjustments.

4. Press the Camera key or

to take a photo. The photo is

saved automatically.

To view photos

In Menu mode, select My les→Images→aphotole.

To record videos

1. In Idle mode, press and hold the Camera key to turn on

the camera.

2. Rotate the phone anti-clockwise to landscape view.

3. Select

to switch to Recording mode.

4. Aim the lens at the subject and make any adjustments.

5. Press the Camera key or

to start recording.

6. Press the Camera key or

to stop recording. The video

is saved automatically.

To view videos

In Menu mode, select My les→Videos→avideole.

Call a recently dialled number

1. In Idle mode, press [ ] to display a list of recent

numbers.

2. Select

◄or ►to a call type.

3. Scroll up or down to a number or name.

4. Select the number or name to view details of the call or

press [

] to dial the number.

Use widgets

Learn to use widgets on the idle screen.

Some of your widgets connect to web services.•

Selecting a web-based widget may incur additional

charges.

Available widgets may vary depending on your region •

or service provider.

To open a widget

1. In Idle mode, scroll left or right to a panel of the idle

screen.

2. Select a widget to activate on the idle screen.

To organise your widget

You can organise each panel of the idle screen with your

favourite widgets.

1. In Menu mode, select Settings→Display→Widgets.

2. Select a widget for each panel.

Do not remove the battery before removing the travel •

adapter. Doing this may cause damage to the phone.

To save energy, unplug the travel adapter when not in •

use. The travel adapter does not have a power switch,

so you must unplug the travel adapter from the outlet

to interrupt the power supply. The travel adapter should

remain close to the socket when in use.

Insert a memory card (optional)

Your phone accepts microSD™ or microSDHC™ memory

cards up to 16 GB (depending on memory card manufacturer

and type).

Formatting the memory card on a PC may cause •

incompatibility with your phone. Format the memory

card only on the phone.

Frequent writing and erasing of data will shorten the •

lifespan of memory cards.

1. Remove the back cover and the battery.

2. Insert a memory card with the gold-coloured contacts

facing down.

Memory card

Activate and send an SOS message

In an emergency, you can send SOS messages to your

family or friends for help.

To activate the SOS message

1. In Menu mode, select Messages→Settings→SOS

messages→Sending options.

2. Select Sending SOS to activate the SOS message

feature.

3. Select Recipients→Add recipients→Contacts.

You can also enter phone numbers in the recipient list.

Skip to step 7.

4. Select Multiple.

5.Selectcontacts→Add.

6. Select a number (if necessary).

7.Whenyouarenishedsettingtherecipients,selectSave

to save the recipients.

8. Select Repeat, set the number of times to repeat the

SOS message, and select Save.

9.PresstheBackkey→Yes.

To send an SOS message

1. With the touch screen and the keys locked, press the

Volume key four times to send an SOS message to

preset numbers.

2. To exit SOS mode, press [

].

3. Select Volume → Call alert.

4. Drag the slider to adjust the volume level and select

Save.

To adjust the volume of the touch tone

In Idle mode, press the Volume key to adjust the volume.

To adjust the volume of voice during a call

While a call is in progress, press the Volume key to adjust

the volume.

Innoisyenvironments,youmayhavedifcultyhearing

the calls while using the speakerphone feature. For better

audio performance, use the normal phone mode.

Change your ringtone

1. In Menu mode, select Settings→Sound proles.

2.Selecttheproleyouareusing.

Ifyouareusingthesilentprole,youarenotallowedto

change the ringtone.

3. Select Voice call ringtone.

4. Select a memory location (if necessary).

5. Select a ringtone and select Set.

Toswitchtoanotherprole,selectitfromthelist.

Install the SIM card and battery

1. Remove the back cover and insert the SIM cards.

Back cover SIM cards

2. Insert the battery and replace the back cover.

Battery

Charge the battery

1. Plug the supplied travel adapter.

To AC power outlet

2. When charging is

nished,unplugthe

travel adapter.

Send and view messages

To send a text or multimedia message

1. In Menu mode, select Messages→Create message.

2.Selecttherecipienteld→Enter manually.

3. Enter a recipient number and select Done.

4.Selectthetextinputeld.

5. Enter your message text and select Done.

See “Enter text.”

For sending as a text message, skip to step 7.

For attaching multimedia, continue with step 6.

6. Select Add media and add an item.

7. Select Send to send the message.

To view text or multimedia messages

1. In Menu mode, select Messages→Inbox.

2. Select a text or multimedia message.

Make fake calls

You can simulate an incoming call when you want to get out

of meetings or unwanted conversations.

To activate the fake call feature

In Menu mode, select Settings→Call→Fake call→

Fake call hot key.

To make a fake call

In Idle mode, press and hold the Volume key down.

3. Select a menu or application.

4. Press the Back key to move up one level; Press [

] to

return to Idle mode.

When you access a menu requiring the PIN2, you •

must enter the PIN2 supplied with the SIM card. For

details, contact your service provider.

Samsung is not responsible for any loss of passwords •

or private information or other damages caused by

illegal software.

Make a call

1. In Idle mode, select Keypad and enter an area code

and a phone number.

2. Press [

] to dial the number.

3. To end the call, press [

].

Answer a call

1. When a call comes in, press [ ].

2. To end the call, press [

].

Adjust the volume

To adjust the volume of the ringtone

1. In Menu mode, select Settings→Sound proles.

2.Selecttheproleyouareusing.

Ifyouareusingthesilentprole,youarenotallowedto

adjust the volume of the ringtone.

Icon Description

Signal strength

GPRS network

connected

EDGE network

connected

Call in progress

Call diverting

activated

SOS message

feature activated

Alarm activated

Connecting to

secured web page

Connected to PC

FM radio on

FM radio paused

Music playback in

progress

Music playback

paused

Icon Description

Roaming (outside of

normal service area)

Bluetooth activated

New text message

(SMS)

New multimedia

message (MMS)

New email message

New voice mail

message

Memory card

inserted

Normalprole

activated

Silentprole

activated

Battery power level

Current time

Your phone displays the following status indicators on the

top of the screen:

Rating

More about this manual

We understand that it’s nice to have a paper manual for your Samsung GT-C3330 Mobile Phone. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Samsung. They might be able to provide an original manual. Are you looking for the manual of your Samsung GT-C3330 Mobile Phone in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

All manuals for Samsung Mobile Phones
More manuals of Mobile Phones

Frequently Asked Questions about Samsung GT-C3330 Mobile Phone

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

Related products

Manual

Samsung SM-A320FL Galaxy A3 Mobile Phone

Manual

Samsung SM-C115W Mobile Phone

Manual

Samsung SM-A165F/DSB Galaxy A Mobile Phone

Manual

Samsung SGH-T456 Mobile Phone

Manual

Samsung SM-A226B/DSN Galaxy A22 Mobile Phone

Manual

Samsung SPH-M360 Mobile Phone

Manual

Samsung SM-A256B/DSN Galaxy A25 Mobile Phone

Manual

Samsung SM-A307GN/DS Galaxy A30s Mobile Phone

Related categories
