Manual Privileg P0I ECO D541 S Dishwasher

Manual

4

OPTIONS AND FUNCTIONS

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL).

If an option is not compatible with the selected program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3

times and beeps will sound. The option will not be enabled.

TABLET (Tab)

This setting allows you to optimize the performance of the

program according to the type of detergent used.

Press the START/Pause button for 3 seconds (the correspond-

ing symbol will light up) if you use combined detergents in

tablet form (rinse aid, salt and detergent in 1 dose).

If you use powder or liquid detergent, this option should

be o.

DELAY

The start time of the program may be delayed for a period of

time between 1 and 12 hours.

1. Press the DELAY button: the corresponding «h» symbol

appears on the display; each time you press the button, the

time (1h, 2h, etc. up to max. 12h) from the start of the selected

wash cycle will be increased.

2. Select the wash program, press the START/PAUSE button

and within 4 seconds close the door: the timer will begin

counting down.

3. Once this time has elapsed, the indicator light «h» switches

o and the wash cycle begins.

To adjust the delay time and select a shorter period of time,

press the DELAY button. To cancel it, press the button repeatedly

until the selected delayed start indicator light «h» switches o.

The DELAY function cannot be set once a wash cycle has

been started.

PUSH & GO

Push&GO button is an easily distinguishable button that allows

you direct access to the Push&GO program, a wash and dry cycle

that ensures great cleaning performance in a short time. You

don’t have to worry which program to choose, Push&GO cycle

will do the work for you.

To select Push&GO program, switch on appliance, press only

Push&GO button for 3 seconds and close the door within

4 seconds.

OPERATION INDICATOR

A LED light projected on the oor indicates that the dishwash-

er is working. One of the following operating modes can be

selected:

a) Disabled function.

b) When the cycle starts the light goes on for few seconds,

stays o during the cycle and ashes at the end of the cycle.

c) The light stays on during the cycle and ashes at the end of

the cycle (default mode).

If the delayed start was set, the light goes on either for the rst

few seconds or the entire duration of the countdown, based on

whether mode b) or c) was set.

The light goes o every time the door is opened. To select the

mode you prefer, switch on the machine, hold down button P

until one of the three letters appears on the display, press but-

ton P until you reach the desired letter (or mode), hold down

button P to conrm the selection.

Note: If Auto Door is active and it opens the door, then

Operation Indicator will not ash at the end of cycle.

Auto Door

Auto Door is a convection drying system which automatically

opens the door during/after drying phase to ensure excep-

tional drying performance every day. Door opens at the tem-

perature that is safe to your kitchen furniture.

As additional steam protection, special designed protection foil is add-

ed together with the dishwasher. To see how to mount protection foil

please refer to (INSTALLATION GUIDE).

Auto Door functionality could be disabled by the user as follows:

1. Go to the Dishwasher software menu pressing and holding P

button (6 sec).

2. You are currently in Light Control Menu (please refer to OPERA-

TION INDICATOR description), if you don’t want to change anything

please press and hold P button (until one of the two letters appears

on the display).

3. You switched to Auto Door Control Menu, you could change status

of Auto Door functionality by pressing P button:

E – enabled d – disabled

To conrm the change and exit from the Control Menu please press and

hold P button (3 sec).
