Manual

4. USING THE TABLE SAW

3. SETTING THE MITRE GAUGE

OPERATION

CAUTION! TO REDUCE THE RISK OF ELECTRICAL

SHOCK, THE USE OF A RESIDUAL CURRENT DEVICE

(RATED 30mA OR LESS) IS RECOMMENDED.

Using the Sliding Mitre Gauge

Theslidingmitregaugecanbettedinto1ofthe2groovesinthetable

and can be used to easily perform mitre angle cuts.

2. Loosen the knurled screw to

adjust the mitre angle.

4. Lock the mitre angle by

tightening the knurled screw.

1. Slide the rail of the

mitre gauge into 1 of

the grooves of the

table.

3. Rotate the mitre

gauge to the desired

angle using the mitre

scale.

20mm

IMPORTANT! DO NOT PUSH THE MITRE GAUGE STOP

RAIL TOO FAR TOWARD THE BLADE. THE DISTANCE

BETWEEN THE STOP RAIL AND THE BLADE SHOULD BE

APPROX. 20MM.

IMPORTANT! THE BLADE GUARD MUST ALWAYS BE

LOWERED OVER THE WORK PIECE AND MOUNTED

SECURELY BEFORE YOU BEGIN TO CUT.

IMPORTANT! AFTER EVERY NEW ADJUSTMENT WE

RECOMMEND YOU TO MAKE A TRIAL CUT IN ORDER TO

CHECK THE NEW SETTINGS.

On / Off Switch

1. To turn the saw ON, press

the green button "I".

Note: Wait for the blade to

reach its maximum speed

before commencing with the

cut.

2. To turn the saw OFF,

press the red button "0".

Blade Guard

1. The blade guard must be

able to move freely, adjust

if necessary (refer to

Assembly Manual).

Download manual in English (PDF, 3.97 MB)

(Consider the environment and only print this manual if it is really necessary)
