Manual

2. SETTING THE RIP FENCE

Rip Fence Stop Height

Thin Material Thick Material

The rip fence supplied with the table saw has two different guide faces.

1 for thick material and 1 for thin material.

2. Slide the stop rail off and

re-insert the desired rail.

1. To change the stop

rail, loosen the 2

wing nuts.

3. Tighten the 2 wing nuts to lock in place.

Note: Rule of thumb: The rear end of the stop comes up against an

imaginary line that begins roughly at the centre of the blade and runs

at an angle of 45° to the rear.

1. Set the required cutting

width.

2. Loosen the wing nuts and

push the stop rail forward

until it touches the imaginary

45° line.

3. Retighten the wing nuts.

Rip Fence Cutting Width

2. Slide the rip fence

to the desired

dimension using the

scale of the guide

rail.

0º 5º

10º

15º

20º

25º

22.5º

30º

45º

The rip fence has to be used

when making longitudinal cuts in

wooden work pieces.

The rip fence can be mounted on

either side of the saw table.

1. Loosen the rip fence lever and

insert the fence into the table

guide rail.

3. Tighten the rip fence lever to

lock the rip fence in position.

Setting the Stop Length

The stop rail can be moved in a longitudinal direction in order to

prevent the workpiece from becoming jammed.
