Manual

Making Longitudinal Cuts / Ripping

Pressoneedgeoftheworkpieceagainsttheripfencewhiletheat

side lies on the saw table. The blade guard must always be lowered

over the workpiece.

When you make a longitudinal cut, never adopt a working position that

is in line with the cutting direction.

1 Set the rip fence in accordance with the workpiece height and the

desired width. (See Stop Height, Cutting Width).

2 Switch on the saw by pressing the ON button "I".

3 Place your hands (with

ngersclosedensuringthey

willbeclearoftheblade)at

on the workpiece and push

the workpiece along the rip

fence and into the blade.

4 Guide at the side with your

left or right hand (depending

on the position of the rip

fence) only as far as the front

edge of the blade guard.

5 Always push the workpiece

through to the end of the

riving knife.

6 The off cut piece remains on

the saw table until the blade

is back in its position of rest.

7 Secure long work pieces

against falling off at the end

of the cut (e.g. with a roller

stand etc.) .

5. MAKING A CUT

TSF-1211

0º 5º

10º

15º

20º

25º

22.5º

30º

45º

0º 5º

10º

15º

20º

25º

22.5º

30º

45º

Cutting Narrow Work Pieces

Making Bevel Cuts

Making Cross Cuts

Bevel cuts must always be done

using the rip fence.

1 Set the blade to the desired

angle. (See Setting the Bevel

Angle)

2 Set the rip fence in accordance

with the workpiece width and

height (see Stop Height)

3 Carry out the cut in accordance

with the workpiece width.

1 Slide the sliding mitre gauge into one of the grooves in the table and

adjust to the required angle (see Sliding Mitre Gauge).

2 Presstheworkpiecermlyagainst

the sliding mitre gauge.

3 Switch on the saw by pressing the

ON button "I".

4 Push the sliding mitre gauge and

the workpiece toward the blade

in order to make the cut.

5 Push the sliding mitre gauge

forward until the workpiece is cut

all the way through.

6 Switch off the saw again. Do not remove the off-cut until the blade

has stopped rotating.

IMPORTANT! BE SURE TO USE A PUSH STICK WHEN

MAKING LONGITUDINAL CUTS.

Be sure to use a push stick

when making longitudinal cuts

in work pieces smaller than

120mm in width. A push stick

is supplied with the saw.

Replace a worn or damaged

push stick immediately.

IMPORTANT! DO NOT PUSH THE MITRE GAUGE STOP

RAIL TOO FAR TOWARD THE BLADE. THE DISTANCE

BETWEEN THE STOP RAIL AND THE BLADE SHOULD BE

APPROX. 20MM.
