Manual

* Not Included

Attach the VESA plate to the monitor

Bevestig de VESA plaat op de monitor

VESA Platte am Monitor ﬁxieren

Fixation de la plaque VESA sur le moniteur

Collegamento del piatto VESA al monitor

Colocación de la Placa VESA en el monitor

Colocar a placa VESA no monitor

Montaż płytki VESA do monitora

STEP 2

STEP 3

Attach the screens onto the bracket and secure it

Hang de schermen aan de bureausteun en zet vast

Montage und Sicherung des Bildschirm an die

Halterung

Accrochez l'écran sur le support et ﬁxez-le

Appendere gli schermi sulla staffa e ﬁssargli

Cuelgue la pantalla en el soporte y asegúrela

Pendure a tela no suporte e prenda-a

Zawieś ekran na wsporniku i zabezpiecz go

Too Long Too Short

M-A

M-B

M-C

Adjust the gas spring

Stel de gasveer af

Gasfeder-Höhenverstellung einstellen

Ajustez la dureté de l'articulation en serrant ou

desserant le ressort à gaz

Regolare la forza della molla

Ajustar la fuerza de resorte a gas

Ajuste a força da mola a gás

Ustawić naprężenie sprężyny

STEP 4

STEP 5

Install the cable clips

Bevestig de kabelclips

Montage der Kabel-Clips

Installez les clips pour les câbles

Fissa la clip del cavo

Instale el clip del cable

Instale o clip do cabo

Przymocuj klipsy kablowe

Unlock

Lock

Download manual in English (PDF, 11.25 MB)
