Manual

STEP 7

Adjust the torque

Stel het koppel in

Einstellen des Drehmoments

Réglage de la force de l'articulation du support

Regolazione della coppia

Ajuste el tornillo

Ajuste os parafusos

Dostsosuj siłę docisku regulacji obrotu monitora

Run the cable(s) through the cable cover

Leid de kabel(s) door de kabelgoot

Kabel durch die Kabelabdeckung führen

Positionnez vos câbles dans les goulettes prévues à

cet effet et reclipsez les caches câbles

Far passare il cavo attraverso la copertura del cavo

Pase el (los) cable(s) a través de la bandeja para cables

Passe o cabo pela tampa do cabo

Przeprowadź kabel przez osłonę kabla

STEP 6

Adjust the mount to your desired position

Stel de steun in op de gewenste positie

Positionieren die Halterung in die gewünschte Position

Ajustez le support à la position souhaitée

Regolare il supporto nella posizione desiderata

Ajuste el soporte a la posición deseada

Ajuste o suporte na posição desejada

Dostosuj pozycję uchwytu do twoich wymagań

STEP 8

Tighten the limiting screw

(do not over tighten).

Remove or loosen the

limiting screw.

Arm can rotate 180°.

Arm can rotate without stopping.

±90°

±180°

Download manual in English (PDF, 11.25 MB)

(Consider the environment and only print this manual if it is really necessary)
