motorola W230

Getting started guide

accessories

www.motorola.com

m

ore in

f

ormatio

n

accessories:

user guide:

www.motorola.com/support

GO TO

@6803630S07@

6803630S07

congratulations! your phone shortcuts calls music menu map

let’s go basics customise FM radio status indicators messages contacts USB drag & drop

congratulations!

Congratulations on your purchase of the cool

Motorola W230 mobile phone.

Whether you’re a talker, a texter or just love listening

to music on the move, the W230 does it all.

We’ve crammed all the main features of your phone

into this handy guide - you can even take the guide

with you.

If you’d like even more information about how to use

your new W230, visit www.motorola.com/support/W230.

So, let’s go.

your phone

right soft key

power/end key

navigation key

left soft key

send/answer key

centre key

Performs the function shown on

the display above the key.

Make and answer calls. Press from

the home screen to see list of

recently dialled calls.

Select a highlighted option or

open a menu when you see å in

the display.

Performs the function

shown on the display

above the key.

Press and hold to turn

the phone on/off. Press

and release to end phone

calls. Exit menu system.

Scroll through lists

and menus. Press left

to access QuickTEXT.

shortcuts

A few shortcuts we think you’ll find really useful:

voicemail

Press and hold 1. If your voicemail number is pre-

set, you will connect. If not, press

1 then Store. Give

your operator a call if you don’t know the number.

recent calls

Quickly view your call history by pressing s

> Recent calls. You can then choose to access your

Received calls, Dialled calls or Call times.

lock/unlock keys

Prevent accidental calls by pressing s followed

by

*. Your screen will go black and your keys

are locked. Repeat to unlock.

music player

Press Music (left soft key) from the home screen.

quick text

To set quick text on your home screen press

s > l Personalise > Home screen > Home keys > Up/Down/Left /Right

> Quick Txt.

calls

Yes, your phone makes calls too! And it’s very

good at it.

make a call

Enter a number and press N.

answer a call

When your phone rings or

vibrates, press

N.

end a call

Press P.

emergency calls

To call an emergency number,

enter the emergency number and

press

N.

Your service provider programs emergency phone

numbers, (such as 999), that you can call under any

circumstances, even when your phone is locked.

Emergency numbers vary by country. Your phone’s

pre-programmed emergency number(s) may not work

in all locations, and sometimes an emergency call

cannot be placed due to network, environmental or

interference issues.

redial a number

1 From the home screen, press N to view a list of

recently dialled calls.

2 Scroll to the entry you want to call and press N.

music

You love your new phone. You love your music.

Imagine combining these two passions...imagine

no longer:

what you need

To use the music player, insert a microSD memory

card, which is an optional accessory.

The music player supports MP3, MIDI, iMelody and

AMR music file formats. You can copy music from a

computer to your phone, where the music is stored

on the memory card (see “USB drag & drop” later in

this guide).

TIP: To access music stored on your microSD

memory card, press

s > h Multimedia > Music library >

s > Switch storage devices.

play music

Press s > h Multimedia > Music library

Scroll to a song, playlist or album, and press Play.

TIP: From the home screen, press your phone’s left

soft key to access the music player faster.

music player controls

Note: Please use only Motorola approved accessories

with this product.

For further support: www.motorola.com

function

scroll up/down

through list

Before music playback,

press

S up or down.

play/pause Press

s.

fast forward Press & hold

S right

(for at least two seconds).

skip to next song Press

S right.

rewind Press & hold

S left

(for at least two seconds).

return to start of

song

After first two seconds

of song, press

S left.

return to last

song

Within first two seconds

of song, press

S left.

n Contacts

sRecent calls

• Received calls

• Dialled calls

• NotePad

• Call times

• Call cost *

• Data times

• Data volumes

e Messages

• Create

•Inbox

•Draft

• Outbox

• Quick notes

•Voicemail

•Browser msgs

• MMS templates

ÉExtras

• Calculator

• MyMenu

•Alarm clock

•Stop watch

•Chat *

• Dialling services *

•STK *

• Calendar

This is a standard main menu layout.

Your phone’s menu may be a little

different.

Q Games

á WebAccess

hMultimedia

•Pictures

• Music library

•FM radio

l Personalise

•Home screen

•Main menu

• Colour setting

•Greeting

• Wallpaper

• Screensaver

• Speed dial

w Settings

• Ring style

•Call divert

• In-call setup

• Initial setup

• Phone status

• Headset

•Network

•Security

• Easy prefix

* Network dependent

let’s go

4

H

1

2

3

4

5 6

SIM

microSD

basics

You may have mastered these already, but here

are a few essential basics:

turn it on & off

Press and hold P for a few

seconds to turn the phone on/off.

menu navigation

Press the centre key s to open

the Main menu.

Press the navigation key

S up,

down, right or left to highlight a

menu option.

Press

s or Select (left soft key) to

select the highlighted option.

Press

s when you see M in

the display to show menu

options.

customise

Here’s your chance to make your phone easier and

more enjoyable to use. So go on, add your

personal touch.

create shortcuts

Choose the features you want to access with a single

key press from the home screen - really useful stuff:

Press

s > l Personalise > Home screen > Home keys

set your screensaver and wallpaper

Change the wallpaper and screensaver images

to ones that make you smile.

Press

s > l Personalise > Screensaver or Wallpaper

set ringtone and volume

There are times when you want to hear your ringtone

in all it’s glory, and there are times when you don’t.

Press

s > w Settings > Ring style

Choose from the pre-programmed styles, including

Vibrate and Silent.

change front cover

Remove the battery cover. From the top of the device,

wedge a thin object (eg.: your fingernails) between

the cover and the main housing of the device until the

two parts detach. Then, working down the phone,

release the cover and slide off.

To replace the cover, first clip into the bottom of the

phone and then work up the body, locking the tabs at

the top. Finally, refit your battery cover.

Warning: Do not charge the battery with the phone or

battery cover removed.

Caution: The front cover is made of plastic, so take

care when handling. Also, when removing the cover

take extra care not to expose it to dirt, dust, liquids,

condensation or static electricity.

12

Made a new friend? Urgently need to contact

someone? No problem, saving and calling your

contacts is effortless.

save contact

1 Enter the number on the home screen and press

Store.

2 Enter the contact details.

3 Press Done when you’re finished.

call a contact

1 Press s > Contacts.

2 Scroll through the list to highlight the contact’s

number.

3 Press N.

messages

Messaging is great, everyone thinks so. Here are a

few basics to get you going:

send a message

1 Press s > Messages > Create.

2 Select the message type.

3 Enter your message.

Tip: In a text entry screen, press

# to switch

entry modes.

4 Press OK and scroll to a contact.

5 Press Send and scroll to any other contact/s you

wish to add.

6 Once you have added the contact/s, press Done.

7 Press Send to send the message.

read a message

When you receive a message you will see New message

on your screen. Press Read to open the message. You

can reply to the message by pressing Reply.

Send messages in only 5 clicks! In the home

screen, press the left arrow of the navigation

key to enter directly into the text message

editor. Type the text and press

Send to

. In the

Send

screen, select or enter the number you

want to send your message to. Then click

Send

. It's that easy!

TIP

FM radio

Listen to your favourite music or news

programme.

1 Plug a 2.5 mm headset into your phone.

Note: The FM radio works only when the headset

is plugged in.

2 Press s > h Multimedia > FM radio

To t u n e in a station, press

S left or right.

To s can available stations, press and hold

S left or

right. Repeat to go to more stations.

To adjust volume, press

S up or down.

To t u rn o ff t h e r adio, press

s > FM radio off.

store favourite stations

When listening to a station, press and hold a number

key

1 through 9 to store the station as a preset

for that number key. To select a preset station, press

the number key for the station you want.

TIP: To share your favourite radio station press

s > h Multimedia > FM radio > Options > Send station info.

USB Drag & Drop

Use the USB cable to connect your phone and PC,

then simply drag & drop.

1 Insert one end of the USB cable into your phone

and the other into your PC.

2 Press Yes to connect your phone as a storage

device.

3 Use the My Computer window to find

Removable Device.

4 Drag and drop your music, photos and other stuff

that you want to copy.

Two folders are available Music and Picture.

Copy music files into the Music folder and

images into the Picture folder.

5 When you’re done, use the Safely Remove

Hardware feature to finish.

Note: This product is compatible with

Microsoft® Windows®, but may not work correctly

with Mac® and Linux® OS.

For further support: http://www.motorola.com/support/

W230

status indicators

The home screen displays when you turn on the

phone. Status indicators can appear across the top of

the home screen:

Note: Your phone’s home screen may be different

than the one shown.

Music Contacts

WED 10/10/07

10:51am

5

É

ì

S

h

õ

W

Signal

Signal

Strength

Strength

Indicator

Indicator

Roaming

Roaming

Active

Active

Active

Active

Call

Call

Alert type

Alert type

New

New

Message

Message

Headset

Headset

Battery

Battery

Level

Level

Rating
