INSTALLATION & ADJUSTMENT

It is important to install and adjust the machine according to the instructions in this

manual for your safety and proper operation.

UNPACKING

• Unpack the carton and take out the bottom panel.

• Open the top lid of the washing machine and remove all the accessories. Remove all wrappers,

including the polystyrene base.

• You are advised to keep all the packaging for reuse in case the machine is to be transported again.

INSTALLING THE BOTTOM COVER

• Lean the machine forward gently and insert the bottom cover (the side

with instructions) into the notch along arrowhead direction.

• Attach the bottom cover onto the washing machine base with two

tapping screws in the accessories by using cross screwdriver.

POSITIONING

The distance between the washing machine and the wall should be

more than 50mm, and the maximum allowed angle of the shank base of the machine is 1 . Slanting or

unstable ground may affect proper operation. To rectify this, adjust it with the following methods:

Make it horizontal

Use a tied thread with plumb to check if it is horizontal.

Adjust the adjustable feet

1. Lift up the adjustable foot gently, loosen the

adjustable nut and twist it.

2. Fasten the nut after adjustment.

INSTALLING THE DRAIN HOSE

• Set the drain hose clip into the drain hose 2-3cm from the drainpipe end and install the drain hose

into the drain hose connector.

Install the drain hose and drain hose connector with the clip onto the drain hose clip on the cabinet.

Notch

Bottom panel

The baffleplate

(

CHANGING THE DIRECTION OF THE DRAIN HOSE

1. Detach the drain hose and drain hose clip from the drain hose connector. Lay a soft mat on the

floor and place the washing machine front side down onto the mat.

2. Unmount the screws on the back cover using a screwdriver and detach the back cover.

3. Unmount one screw fixing the drain hose

connector (on right of the washing machine)

and loosen the drainpipe connector.

(Section sketch map for washing machine

right side)

4. Extrude the drainpipe with proper force and remove the drain hose

hoop (on right of the washing machine) & loosen the inner drain hose.

(Section sketch for inside washing machine)

5. With proper force, detach the drain hose gate stopper on left side

of the washing machine. The drain hose gate stopper is fixed on

the washing machine base with two clips.

(Section sketch map for washing machine left side)

6. Pull the inner drainpipe to another side, taking care not to

distort or damage the inner drain hose.

Attach the inner drain hose with the drain hose hoop using one

screw to secure the drain hose connector. Install the drain hose

gate stopper to another side, place the washing machine standing upright and reattach the cover

using the screws. Install the drain hose with drain hose clip into the drain hose connector.

WATER DRAINAGE

1. The height of the drain hose should be less

than 10cm, otherwise the drainage will not

be smooth and need a long time to drain,

the machine may stop during working.

2. Do not step on or press the drainpipe.

3. Cut the drainpipe if it is too long. Cut the front

end of the drainpipe slantingly to make

drainage smoothly.

4. Purchase a proper hose if you need additional drainpipe.

Its diameter should not less than 30 mm and length

should not exceed 1.5m.

5. If the additional drainpipe is too long,

cut some at A or B point.

Drainpipe connector

rainpipe

Drainpipe clip

Drainpipe hoop

Drainpipe gate stopper

<10cm

≤1.5m

≥ø30mm

The baffleplate

(

Loosen

Fasten

Adjustable

nut

Adjustable

foot

High Low

The baffleplate

(

INSTALLATION & ADJUSTMENT

MWM-Rena7FA(IM)011118.qxp_Layout 1 11/8/18 10:32 AM Page 4
