Need a manual for your Indesit IWC 71051 C ECO EU Washing Machine? Below you can view and download the PDF manual for free in English. This product currently has 12 frequently asked questions, 19 comments and has 21 votes with an average product rating of 52/100. If this is not the manual you want, please contact us.

Is your product defective and the manual offers no solution? Go to a Repair Café for free repair services.

Manual

65 - 100 cm

Connecting the drain hose

Connect the drain

hose, without bending

it, to a drainage duct or

a wall drain located at a

height between 65 and

100 cm from the floor;

alternatively, rest it on

the side of a washba-

sin or bathtub, faste-

ning the duct supplied

to the tap (see figure).

The free end of the

hose should not be

underwater.

! We advise against the use of hose extensions;

if it is absolutely necessary, the extension must

have the same diameter as the original hose and

must not exceed 150 cm in length.

Electrical connections

Before plugging the appliance into the electricity

socket, make sure that:

• the socket is earthed and complies with all

applicable laws;

• the socket is able to withstand the maximum

power load of the appliance as indicated in the

Technical data table (see opposite);

• the power supply voltage falls within the values

indicated in the Technical data table (see opposite);

• the socket is compatible with the plug of the

washing machine. If this is not the case, repla-

ce the socket or the plug.

! The washing machine must not be installed

outdoors, even in covered areas. It is extremely

dangerous to leave the appliance exposed to

rain, storms and other weather conditions.

! When the washing machine has been installed,

the electricity socket must be within easy reach.

! Do not use extension cords or multiple sockets.

! The cable should not be bent or compressed.

! The power supply cable must only be replaced

by authorised technicians.

Warning! The company shall not be held responsible

in the event that these regulations are not respected.

The first wash cycle

Once the appliance has been installed, and

before you use it for the first time, run a wash

cycle with detergent and no laundry, using the

wash cycle 2.

Technical data

Model

IWC 71051

Dimensions

width 59.5 cm

height 85 cm

depth 53,5 cm

Capacity

from 1 to 7 kg

Electrical

connections

please refer to the technical

data plate fixed to the machine

Water

connection

maximum pressure

1 MPa (10 bar)

minimum pressure

0.05 MPa (0.5 bar)

drum capacity 52 litres

Spin speed

up to 1000 rotations per minute

Test wash

cycles in

accordan-

ce with

directives

1061/2010

and

1015/2010

Programme 2:

Cotton standard 60°C.

Programme 3:

Cotton standard 40°C.

This appliance conforms to

the following EC Directives:

- 2004/108/EC dated

03/05/89 (Electromagnetic

Compatibility)

- 2012/19/EU

- 2006/95/EC Low Voltage)

Download manual in English (PDF, 1.84 MB)

(Consider the environment and only print this manual if it is really necessary)

Rating

Let us know what you think about the Indesit IWC 71051 C ECO EU Washing Machine by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.

Are you satisfied with the Indesit IWC 71051 C ECO EU Washing Machine?
Yes No

52%

48%

21 votes

Join the conversation about this product

Here you can share what you think about the Indesit IWC 71051 C ECO EU Washing Machine. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.

Michele 03-04-2021
Hi good evening I bought an Indesit IWC71051 washing machine, can you explain to me for a quick wash what number should I put it on?

reply | This was helpful (40) Read more (Translated by Google)

Lucia Zappala 31-03-2022
Boh

This was helpful (2) (Translated by Google)

Salvatore 23-10-2019
My washing machine after loading the water does not start the program what could have happened ???

reply | This was helpful (27) (Translated by Google)

Chiara 21-10-2019
My washing machine has always turned on the red lock light and once the wash is finished, it starts washing again

reply | This was helpful (24) (Translated by Google)

Guillermo Teper 13-05-2020
The washing machine runs for 90 minutes, how can I reduce this time?

reply | This was helpful (9) Read more (Translated by Google)

fermus vasile 05-12-2022
how do I shorten the washing time?

This was helpful (15) (Translated by Google)

Manola Peciccia 31-01-2020
My washing machine does not take fabric softener

reply | This was helpful (8) Read more (Translated by Google)

Mariam 28-03-2022
Machine does not pull fabric softener

This was helpful (0) (Translated by Google)

Franca cataldo 16-09-2020
My washing machine on program 1 which is the only one that does the prewash does not spin

reply | This was helpful (6) Read more (Translated by Google)

Paulo 28-12-2021
Good night, I have an Indesit iwc 71051, it puts water on it but the drum does not turn, which can be done

This was helpful (12) (Translated by Google)

João Gomes 05-12-2019
My machine takes hours to make a program

reply | This was helpful (3) (Translated by Google)

Guido 09-02-2020
When I do the wool (10) or ecotime (8) program, in my laundry, there are some soft gray pieces that are difficult to remove with my hands. I have to postpone the normal and long program. that the cause was that. But all useless. It always continues with that defect.

reply | This was helpful (3) (Translated by Google)

Cinzia 04-03-2022
I would like the instructions in Italian

reply | This was helpful (2) (Translated by Google)

Michaela 19-06-2019
Hi, my indesit iwc 71051 disconnects from the electric source after it ends washing. I have to unplug and plug it after 2 minutes for it to work again. Otherwise it works well.

reply | This was helpful (1)

Niculae Dumitru 05-12-2022
My resistance is burnt where can I buy it is the same for all types of Indesit

reply | This was helpful (1) (Translated by Google)

Celia 06-03-2024
How to save the program time

reply | This was helpful (1) (Translated by Google)

Giorgio 02-05-2022
New washing machine I can't open the door as I should ...

reply | This was helpful (0) (Translated by Google)

maurizio belluomini 13-09-2022
Hello I have an Indesit iwc 71253 washing machine I would like to know exactly the reset procedure of the programming card I remembered that you have to hold down the START / PAUSE button for about ten seconds but I do not remember the exact procedure I would be grateful for you to indicate the exact procedure Thank you Greetings

reply | This was helpful (0) (Translated by Google)

Daniela 29-11-2024
The washing machine draws water and the water flows directly down, not into the tub

reply | This was helpful (0) (Translated by Google)
