Manual Hotpoint NT M11 82XB UK Dryer

Name: Hotpoint NT M11 82XB UK Dryer
Brand: Hotpoint
SKU: NT M11 82XB UK
Rating: 0 (5 reviews)

Need a manual for your Hotpoint NT M11 82XB UK Dryer? Below you can view and download the PDF manual for free in English. This product currently has 5 frequently asked questions, 13 comments and has 5 votes with an average product rating of 0/100. If this is not the manual you want, please contact us.

Is your product defective and the manual offers no solution? Go to a Repair Café for free repair services.

Manual

You can download the Safety Instructions, User Manual, Product Fiche and Energy data by:

• Visiting our website - docs.hotpoint.eu

• Using QR Code

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When

contacting our After-sales Service, please state the codes provided on your product’s identi cation plate.

THANK YOU FOR BUYING A HOTPOINT PRODUCT.

In order to receive a more complete assistance,

please register your product on

www.hotpoint.eu/register

Quick guide

Before using the appliance carefully read the Safety Instructions.

xxxxxxxxxxxx

xxxx

CARE AND MANTENANCE

Unplug the dryer during the cleaning and maintenance

procedures.

Emptying the water tank after each cycle (see Fig. A).

Pull the container out of the dryer and and empty it into a sink

or other suitable drain, then place it back. Do not use the dryer

without having inserted the container back in place.

Cleaning the door lter after each cycle (see Fig. B).

Pull the lter out and clean it by removing the lint from the lter

surface under running water or using a vacuum cleaner. Do not

use the dryer without having reinserted the lter in place.

Remove the door lter as described below:

1. Open the door and pull upwards.

2. Open the lter and remove lint from all its parts. Replace it

correctly.

Ensure it is completely inserted ush with the dryer seal.

Cleaning the bottom lter when the relevant indicator

turns on (see Fig. C).

Pull the lter out and remove the lint from its surface by washing

it under runing water or by using a vacuum cleaner. However,

it is advisable to clean this lter after each cycle to optimise

drying performance. Do not use the dryer without having

inserted the lter in place rst.

Remove the bottom lter as described below:

1. Open the lower door.

2. Take the handle and pull the lower lter out.

3. Open the rear side of the lter and remove the lint from the

inner surface of the mesh.

4. Clean the bottom lter chamber avoiding the direct contact

with the leaves.

5. Close the rear side of the lower lter and place it back by

checking it is perfectly integrated in place.

6. Lower the lter handle and close the bottom door.

7.Make sure the air intake is free.

The lters are essential parts for drying. They are intended

to collect the lint formed during drying process. In case

of clogged lters, the air ow inside the dryer would be

seriously aected: the drying times would be longer, the

energy consumption would increase and the dryer could be

damaged. If these procedures are not carried out properly,

the dryer may not start.

PRODUCT DESCRIPTION

1. Water bottle

2. Air Intake

3. Bottom lter

4. Door lter

TRANSPORT AND HANDLING

Never lift the dryer by holding it at the worktop.

1. Unplug the dryer.

2. Make sure that door and water tank are properly closed. 3. If the

drain hose is connected to your sewage system, x the drain hose

on the rear of the dryer again (see Installation Guide).

Power consumption

o-mode (Po) - Watts 0.50

left-on mode (Pl) - Watts 1.00

Programs Kg kWh Minutes

Eco Cotton *

8 1.78 194

Eco Cotton

4 1.15 135

Synthetics 4 0.73 95

*This is the reference programme for the energy label and suitable to

dry normal wet cotton laundry. This is the most ecient programme

in terms of energy consumption for drying wet cotton laundry.

(Standard/Default starting conguration)

Heat Pump System

The heat pump contains uorinated greenhouse gases,

contained in a hermetically sealed unit. This sealed unit contains

0.18 kg of the F gas R134a. GWP = 1430 (1 t CO2).

Download manual in English (PDF, 2.81 MB)

(Consider the environment and only print this manual if it is really necessary)

Rating

Let us know what you think about the Hotpoint NT M11 82XB UK Dryer by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.

Are you satisfied with the Hotpoint NT M11 82XB UK Dryer?
Yes No

100%

5 votes

Join the conversation about this product

Here you can share what you think about the Hotpoint NT M11 82XB UK Dryer. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.

David Aynsley 27-07-2020
Great product and works well. However, I need to reverse the door and Hotpoint want £70 to do it. It is not a straight forward DIY job like most tumble driers. Specs do not mention it is not reversible. Very disappointing.

reply | This was helpful (10)

A C 19-08-2022
The red light indicating that the bottom filter needs cleaning is on all the time, even though I have cleaned it. Hotpoint call centre says this is normal, but the Quick Guide says to clean the bottom filter "when the indicator turns on". Anyone else had this experience?

reply | This was helpful (5) Read more

Alicia 14-11-2022
Yes, despite following all the instructions and cleaning the filter carefully, the warning light persists! Machine=3mths old has never attained acceptably dried clothes 8 (

This was helpful (0)

Fee 06-06-2021
Why don’t my tumble dryer seem like it is not getting hot

reply | This was helpful (4)

Magda Hughes 19-04-2021
Hi. I have a question about the programmes. With for example Eco Cotton program. Do I have to put 8kg load or can I put 6kg, 4kg etc?

reply | This was helpful (0)

Carmen 21-03-2022
Brought the hot point dryer 7months ago. It’s now not working, the screen show ‘demo’ at the top corner, wonder if this made the dryer not to work?

reply | This was helpful (0)

Chantelle 26-03-2022
Can this tumble dryer door be reversed

reply | This was helpful (0) Read more

Ricky 30-07-2022
Yes, I dud it in 10mins. Screws out, move the microswitch point on the door to align with hole in dryer...job done

This was helpful (0)

S B 30-07-2022
I recently bought this dryer and I am not impressed with it. It takes FOREVER to dry and I can't work out if it's a fault with the machine OR if it's just a VERY SLOW dryer. What has your experience been?

reply | This was helpful (0) Read more

Ann C 19-08-2022
I have had exactly the same experience, though only had the machine for 2 weeks. I'm thinking maybe its the programme combination I am setting, so I am experimenting with other settings.

This was helpful (3)

M S 02-11-2022
Any body know how to access the condensing unit/area. Dryer to blowing smelly air around therefore tainting the clothes

reply | This was helpful (0)

Underhill 12-01-2024
Has anyone swap the door opening?

reply | This was helpful (0)
