Manual Hitachi BW-S70G Washing Machine

Need a manual for your Hitachi BW-S70G Washing Machine? Below you can view and download the PDF manual for free in English. This product currently has 12 frequently asked questions, 0 comments and has 0 votes. If this is not the manual you want, please contact us.

Is your product defective and the manual offers no solution? Go to a Repair Café for free repair services.

Manual

Loading…

2
Air-jet drying 空氣噴射乾燥
By inhaling clean air, instead of using any heater, the laundry is dehydrated with the wind dehydra-
tion and high speed spinning function, providing drying effect.
不使用加熱器,通過吸入清洁的空气,用強風和高速脫水功能甩掉衣物中的水分,達到乾燥的目的。
May be used to air-dry the heat-irresistible swimsuit or the underwear containing the heat-insulation materials.
可風乾不耐熱的泳衣或含隔熱材料的內衣。
Keep room free of mugginess for causing no temperature rise.
由於溫度不上升,房間不會悶熱。
Control the black mildew in washing spinning basket.
抑制洗衣·脫水筒中的黑色黴菌。
The drying capacity: The blending chemical fiber is below 3.0kg, chemical fiber is below 4.0kg
(Provide the same drying effect as the airing in the room)
乾燥量:化纖混紡衣物為 3.0kg 以下,化纖為 4.0kg 以下。
(可以達到和室內晾乾同等的風乾效果)
The duration is irrelevant to the dryness level for applying the timer mode of drying.
採用定時器式乾燥方式,結束時間與乾燥程度無關。
Go on with the air-jet process in case of insufficient drying.
風乾程序不足時,請再運行一次風乾。
Please read "USER MANUAL" carefully for proper operation.
請仔細閱讀「使用說明書」,以便您能正確使用。
Equivalent to 3 times power of
dust collector.
相當於吸塵器的 3 倍的風力
Preface
前言
The number next to the sign is the page number for detailed description.
後面的數字表示具體說明的頁數。
Stirring agitator 新式攪拌翼
Powerful washing effect
without damage to laundry
洗滌力強而不傷衣物
Stirring the laundry up and down
can achieve the same effect as
pressing, flapping, rubbing by
hands. This will control the dam-
age to laundry under the minimum
level, gently and quickly removing
the dirt.
在讓衣物上下移動的過程中,可獲
得手洗的壓、拍、搓的效果,將對
衣物的損傷控制在最低程度,可輕
柔、迅速地去除污漬。
Blades at the rear of
stirring agitator
背面葉片
攪拌翼
pressing 壓洗
Pushing action from
bottom to top
從下向上推壓的動作
flapping 拍洗
Dropping action from
top to bottom
從上向下摔落的動作
rubbing 搓洗
Action forcing laundry
to move up and down
讓衣物上下移動的動作
Water-saving circulating water flow 節水型循環水流
With little water in high efficiency
高效使用少量的水
The circulating water flow will come into being when
stirring the water with the blades at the rear of stirring
agitator and combining sprinklers in three directions.
Only small quantity of water will be sufficient to
remove the dirt efficiently.
用攪拌翼的背面葉片攪動水流,通過上下 3 個方向的
噴頭形成循環水,只需少量用水即可高效去污。
1
1
2
2
3
3
Upper circle
sprinkler
上部循環噴頭
Lower circle sprinkler
下部循環噴頭
side view
〔側視圖〕
Blades at rear
背面葉片
top view
〔俯視圖〕
Download manual in English (PDF, 15.21 MB)
(Consider the environment and only print this manual if it is really necessary)

Loading…

Rating

Let us know what you think about the Hitachi BW-S70G Washing Machine by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.
Are you satisfied with the Hitachi BW-S70G Washing Machine?
Yes No
Be the first to rate this product
0 votes

Join the conversation about this product

Here you can share what you think about the Hitachi BW-S70G Washing Machine. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.

More about this manual

We understand that it’s nice to have a paper manual for your Hitachi BW-S70G Washing Machine. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Hitachi. They might be able to provide an original manual. Are you looking for the manual of your Hitachi BW-S70G Washing Machine in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

Brand Hitachi
Model BW-S70G
Category Washing Machines
File type PDF
File size 15.21 MB

All manuals for Hitachi Washing Machines
More manuals of Washing Machines

Frequently Asked Questions about Hitachi BW-S70G Washing Machine

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

My washing machine won't start when I press the start-button, what can I do? Verified

In many cases the door of the washing machine hasn't closed properly. Open and close the door and try again.

This was helpful (25268) Read more

My washing machine won’t drain, what can I do? Verified

The main reason a washing machine won’t drain is because of blockage in either the pump or the drain hose. If your washing machine has access to these parts, try to remove any blockage. If this does not solve the problem or if you don’t have access to these parts you should contact a mechanic or the manufacturer.

This was helpful (24035) Read more

There is no water coming into my washing machine, what can I do? Verified

Check if the water inlet is open and if there aren't any kinks in the hose of the water inlet. If this doesn't solve the problem you should contact the manufacturer.

This was helpful (9755) Read more

The door of my washing machine won't open, what can I do? Verified

There can be several causes. The most common cause is the filter being clogged. Unplug the appliance and check the filter. Remove any blockage if necessary. The location of the filter is different depening on the model. It is also possible that there is a special lever to open the door. If these options don't help, the last option is unplug the appliance for a period of 30-60 minutes and try to open the door after that. If this doesn't work, contact the manufacturer or a mechanic.

This was helpful (8324) Read more

My washing machine makes a lot of noice and/or vibrates loudly, what can I do about that? Verified

It's possible that the washing machine has not been leveled. You can do this by adjusting the feet to make it perfectly level. The problem can also be caused by inserting to much clothes in the machine. If these are not the cause of your problem you should contact the manufacturer.

This was helpful (6942) Read more

In which compartment should the detergent go? Verified

Most washing machines have 3 compartments for detergent. These compartments are often marked with I, II and * to show where the detergent goes. Compartment I is used for a pre-wash cycle, II is for the main wash cycle and * is for fabric softener. Compartment II is used most often.

This was helpful (5101) Read more

My washing machine smells, what can I do about it? Verified

There are washing machines with self-cleaning features. If these features are not available it's possible to add 100ml of white vinegar or 100gr of soda crystals and have the washing machine run a 90 ℃ program.

This was helpful (4255) Read more

Can I connect my washing machine to a warm water outlet? Verified

Although washing machines can probably handle water intake up to 65°C, this is not recommended by most manufacturers. There are wash cycles that specifically make use of cold water. In those cases warm water can harm the results of your wash cycle. Also, many washing machines are designed to be connected to a cold water outlet.

This was helpful (3043) Read more

What should I pay attention to when moving a washing machine? Verified

When moving a washing machine, you should secure the drum. You can use the transit bolt which come with every washing machine and will prevent the drum from moving around inside the machine. You also need to drain all the water.

This was helpful (1599) Read more

Can I stack my dryer and washing machine? Verified

In general it is possible to directly stack a dryer and washing machine directly on top of each other. This only works with front loading models. However, it is advisable to use a fitting accessory to do so. This will prevent the machines from vibrating and falling off and also prevents damage to the bottom machine.

This was helpful (1355) Read more

What is the difference in usage between a washer-dryer and a separate washing machine and dryer? Verified

The biggest advantage of a washer-dryer is that it takes less space. However, a separate dryer will be able to dry more than a washer-dryer. A washer-dryer also uses relatively more energy and requires more time.

This was helpful (1315) Read more

Can I connect a washing machine to an extension cord? Verified

Appliances that require large amounts of power, like a washing machine, can not be connected to all extension cords. See what the power usage of the washing machine is, which is indicated in Watt, and check if the extension cord can handle this. There are extension cords with thicker cables that are made to handle larger appliances.

This was helpful (1314) Read more
