wwwBA_EBCSL90_0806_EN 31.5.2008 11:21 Uhr Seite 2

Probedruck

C M Y CM MY CY CMY K

Watt

min gr

EBC SL9

(55 cm)

EBC SL90

(60 cm)

Cleaning movements

1 2

1 2 3

Start-up

Set current time

Demo Mode

315 9100 03_06/2008

Clean with hot detergent lye (not suitable for dishwashers)

When will the meal be ready?

END

Is the time faded out:

- Display is illuminated when

switched on

- Display goes out when switched off

(first select oven function)

DURATION

0 to 99 minutes

Short time

change (e.g. Summer-/ Wintertime)

Time

set

DURATION / END can be used simultaneously, if:

- the oven shall be switched on and off automatically at the later time

- a programme is selected.

- After setting a time, symbol flashes for 5 sec., afterwards the time, short time or duration is illuminated, and the time starts.

- While the corresponding symbol flashes (5 sec.): Set/change times

- By repeated touch the current time can be prompted

Clock functions

Time can only be faded out, if no other display is active!

fading in/out

Switching off Press off button at the same

time for about 2 seconds until

display goes out/lights up

Automatic switch off

Clean accessory

Wash with a soft brush in hot detergent lye.

Assembly:

In reverse order.

Remove griddle guides

Fit and unhinge griddle guides

While cleaning griddle guides, lamp glass and oven door, ensure no heating elements are switched on.

The oven has to be cooled down so as to be able to touch the central panels safely. Only the oven light must be switched on.

NEVER use high pressure cleaning devices for the oven!

Clean the appliance thoroughly and frequently! Avoid repeated burning of residue.

Cleanemail oven

- Do not use fine steel wool, scratching and scrubbing cleaning agents!

- You can use commercially available oven spray. Observe the manufacturer’s instructions

-> Wash the inside of the oven with warm detergent lye or vinegar cleaner and a sponge/cloth

TIP: Clean the chrome parts in the oven interior with a non-scratch / non-abrasive cleaning sponge (obtainable from large distributors).

No steel wool or stainless steel scourers.

- Always keep the door seal, door seal surface and the inside clean. Lack of appliance cleanliness can lead to hazardous situations.

- no aggressive/acidic or

glass-ceramics cleaning agent

- no steel wool / pot cleaner

- Only wash inside panel with hot detergent

- Soak severe residue

- Keep rubber seals clean and do not damage!

Do not graze glass interior with a knife, scotch brite etc

Control panel + oven door

Cleaning and care

No rotating movements

when cleaning, as surfaces

will be damaged!

Preheating

Initial cleaning

Remove objects from the oven!

Not the type plate

Take out accessories and rinse

(p. cleaning + service p. 6)

Initial heating

Air the area well during initial

heating phase.

Select «hot air» set 230° C

Operate closed 60 mins,

switch off again

Open window!

Because set temperatures are reached very quickly,

preheating is unnecessary for most programmes...

Recommendation preheating at:

- Meat dishes / short slices of meat (fillet, sirloin, cutlet, chops)

-> Meat pores close faster and roast meat remains juicy

- Cookies diverging slightly, bread roll, pastries, biscuit rolls

- Use in combination with microwave

Clean with water + detergent

–> see Cleaning + service p. 6)

Built-in Compact Oven

Hot air, microwave, grill

The documentation for the compact oven is 3-part: Instructions for use, baking / roasting chart

and supplementary technical sheet. The safety instructions in the supplementary technical sheet

are an integral part of this documentation.

Do not operate the appliance until you have read all documents and safety instructions.

In order to guarantee that you have taken note of the content of these instructions, we request

that you send the complete warranty card to Customer Service in Mägenwil. Please hand

these instructions to anyone who may use this appliance.

INSTRUCTIONS FOR USE

End

Time

Short time

Duration

0 to 23 hrs 59 min.

No impact on

microwave / oven operation

Press the off switch at the same

time for about 2 seconds, until

the display goes out/lights up

Buttons-signal

Press simultaneously for about 2

seconds until the signal is audible

Press the same button again for

about 2 seconds in order to switch on

the signal again!

Switching on/off

Switching off

TIP: Clean with a soft, clean, moist micro-fibre cloth!!

Clean bottom glass after each use with a soft brush in hot detergent or in dishwater.

For stubborn dirt soak in hot lye, possibly use glass scraper

- If necessary a commercially available

chromium steel cleaner can be used ->

Observe manufacturer’s instructions in

using these cleaning agents!

Alulook outside surfaces:Outside surfaces chromium steel smoothed:

The oven only works

with the time set!

Close oven door

and start

Subject to technical modifications

set time

set duration

No microwave operation on bottom glass!

1 2

Press simultaneously for about 2

seconds until the signal is audible!

Switch off appliance

Press the same button again

for about 2 seconds to turn off

Demo mode!

Switch on the

Demo Mode

After electrical connection/

power breakdown the time

symbol flashes

After 5 seconds the flashing stops

And time shows the time

To test or carry out all

operating modes.

The oven does not heat.

If the function and temperature is set WITHOUT time

restriction,the oven switches off automatically as follows:

at 30 - 120 °C

at 120 - 200 °C

at 200 - 230 °C

after 12,5 h

after 8,5 h

after 5,5 h

Start-up after automatic switch off:

Switch off oven completely, it can

be restarted afterwards.

Accessories (standard equipment)

Griddle guide*

Baking/Roast/Grill

*Not for microwave operation

Glass baking tray for

microwave operation

Glass bottom plate Glass stirrer

Optional accessories

Pastry/baked goods

professional plate

Drying/Baking (non-stick)

PB 426 S

Crostino plate

(non-scratch / firm,

non-stick)

CP 28

For further instructions see «Suitable dishware / material», p. 4

Set time

set duration

Duration MICROWAVE

«OFF» appears in the display

P a g e

Child lock

Button locking mechanism

No function

can be

selected!

Press the same button again

for about 2 seconds in order to

switch off child lock!

Switching off

Child lock on
