Manual

DEFROSTING THE APPLIANCE CLEANING AND MAINTENANCE TROUBLESHOOTING

1. Getting the air into the appliance may form a layer of frost inside. It will

weaken the refrigeration when the frost is thick. When it is more than 5mm

thick, you should defrost the appliance.

2. Wrap the food and keep them in a cool place.

3. Turn off the power and unplug the switch from the electrical mains.

4. Place a tray under and near the drain plug. Pull out the drain dial.

5. Rotate the drain dial 180 degree. This will let the water flow out into the

tray. When done, push the drain dial in.

6. The defrosting process usually takes few hours to complete. To speed up

the defrosting process, try putting bowls of hot (not boiling) water in the

freezer compartment. Keep the door open.

7. Replug the drain plug into the freezer compartment.

8.Wipe the interior of the freezer with soft cloth and plug the plug in the

electrical outlet.

9. Reset the temperature control to the desired setting when required.

10. The appliance should be defrosted once every one month depending on

the usage.

11. If the appliance door was opened frequently or using the appliance in high

humidity area, we advise the user to defrost once every two weeks.

8. This appliance should not be left unused for a long period. To stop using

the appliance, disconnect the main power. Clean the interior and dry it

completely. Open the door for 2-3 days to ensure it is dry completely.

MAIN SPECIFICATIONS

Model No

Gross Capacity

Climatic Type

Insulation Class

Total Input Power

Rated Voltage

Refrigerant

Product Dimension (mm)

Product Internal Dimension (mm)

Model No

Gross Capacity

Climatic Type

Insulation Class

Total Input Power

Rated Voltage

Refrigerant

Product Dimension (mm)

Product Internal Dimension (mm)

: ARTICO EF-F4132E(GR)

: 410L

: T

: CLASS I

: 155W, 1.45A

: 220-240V / 50-60Hz

: R600a

: 1120 (W) x 700 (D) x 850 (H)

: 981 (W) x 530 (D) x 675 (H)

: ARTICO EF-F5138E(GR)

: 510L

: T

: CLASS I

: 180W, 1.65A

: 220-240V / 50-60Hz

: R600a

: 1300 (W) x 700 (D) x 850 (H)

: 1161 (W) x 530 (D) x 675 (H)

For hygenic reasons the appliance interior including accessories should be

cleaned regularly.

1. Always ensure that the electrical main has been turned off and unplug before

cleaning the appliance.

2. Wrap the food and keep them in a cool place.

3. Do not use chemical, steel, wooden or abrasive cleaners to clean the

appliance.

4. Never use sharp instruments to scrape off frost or ice.

5. Never use steam cleaning product to clean the appliance.

6. After cleaning, wipe the appliance until it is completely dry.

7. Use warm water to clean the oil and stains on the gasket in order to keep its

elasticity.

8. This appliance should be serviced by an authorised service technician.

Please contact the service centre if you required service on the appliance.

9. Under no circumstances should you attempt to repair the appliance by

yourself.

10. Repairs carried out by inexperienced persons may cause injury or serious

malfunctioning.

POWER SUPPLY. ONLY A QUALLIFIED TECHNICIAN OR COMPETENT

PERSON CAN PERFORM THE TROUBLESHOOTING GUIDE IN THIS

MANUAL. CONTACT THE SERVICE CENTRE IF YOU NEED ASSISTANCE.

CAUTION! BEFORE TROUBLESHOOTING, DISCONNECT THE

NOTICE

This product must not be disposed together with domestic waste. It has to be disposed at an

authorized place for recycling of electrical and electronic appliances. By collecting and

recycling waste, you help to save natural resources and make sure the product is disposed in

an environmental friendly and healthy way.

Appliance does not

work.

Appliance too cold.

The food does not

get frozen.

Heavy built up of

frost on the door

seal.

Unusual noises

If the problem persists, please contact the authorized service centre for immediate service. Retain

the warranty card and proof of purchase for warranty purpose.

Main plug in not plug in or loose.

Fuse has blown or defective.

Socket is defective.

Temperature has been set too cold

or at the MAX position.

Temperatue is not properly

adjusted.

Door has been opened for too

long.

A large quantity of food was placed

in the compartment for the past 24

hours.

The appliance is near a heat

source.

The door seal is not air tight.

The appliance is not in level or

close to foreign object.

The compressor is faulty.

Make sure the appliance is in level

and leave a gap to the wall.

Request for service by contacting the

authorized service centre.

Request for service by carefully

warming the uneven section of the

door seal with a hair dryer.

Relocate the appliance according

to the installation requirement.

Open the door only when

necessary.

Turn the thermostat to higher level

temporary.

Turn the thermostat lower and

optimum at level 5.

Turn the thermostat higher and

optimum at level 5.

Plug in ithe main plug completely.

Check fuse and replace if necessary.

Mains malfunctions are to be serviced

by a technician.
