1 2 3 4
65
Programme selector
Sorting and loading the laundry
Observe the care information provided by the manufacturer.
Sort according to the information on the care labels.
Sort according to type, colour, soiling and temperature.
Remove any foreign objecbts - risk of rusting.
Do not exceed the maximum load. apage 7
Observe the instructions in the important information section. a page 9
Load both large and small items of laundry.
Close the washing machine door. Take care not to trap any items of clothing
between the loading door and rubber seal.
Add detergent and care product
Add the appropriate dose according to:
Amount of laundry, soiling, water hardness (ask your water supply
company) and manufacturers instructions.
Models without insert for liquid detergent: pour liquid detergent into an
appropriate dispenser and place in the drum.
During operation: close the detergent drawer!
2
Correct installation according to
separate installation instructions.
Check the machine
Never switch on a damaged machine!
Inform your customer service!
Insert mains plug
With dry hands only!
Only hold the plug itself!
Turn on the tap
Compartment II: Detergent for the main wash, water softener,
bleacher, stain remover
Your washing machine
Congratulations  You have opted for a modern, highquality
domestic appliance manufactured by Bosch. The washing machine
is distinguished by its economical use of water and energy.
Each appliance which leaves our factory has been inspected
thoroughly to ensure that it functions properly and is in perfect
condition.
Intended use
Contents Page
ʋIntended use .......................................................................................1
ʋPreparation ..........................................................................................2
ʋSetting and adjusting programmes ........................................... 3/4
ʋRemoving laundry ..............................................................................4
ʋSet programmes, additional functions ...................................... 5/6
ʋProgramme overview .........................................................................7
ʋSafety instructions .............................................................................8
ʋConsumption values ........................................................................8
ʋImportant information .........................................................................9
ʋCare ................................................................................................... 10
ʋInformation on the display ............................................................ 10
ʋMaintenance .................................................................................... 11
ʋWhat to do if ..............................................................................12/13
ʋEmergency release.......................................................................... 13
ʋCustomer service ............................................................................. 13
Preparation
Before washing for the first time,
wash once with Easy care 40
apage 9
Setting and adjusting programmes
Display panel/
Option buttons/
Additional functions
Start/
Reload
3
4

Washing
Compartment ~: Fabric softener
Compartment I: Detergent for prewash, pulp powder
ʋFor domestic use only.
ʋFor washing machine-washable fabrics in a detergent
solution.
ʋTo be operated with cold mains water and
commercially available low foam detergents and care
products which are suitable for use in washing
machines.
ʋOperating conditions:
࣊ambient temperature 0-40°C.
relative humidity of air: under 95% (tested at 25°C).
Do not leave children unattended near the
washing machine!
The washing machine is not to be used by
children or persons not familiar with the
operating instructions.
Keep pets away from the washing machine!
Install and operate the washing machine in a
room with a drain.
In order to ensure your safety, you must plug the
cable into a socket which is connected with
reliable earth correctly.
Do not wash carpets!
Dilute viscous fabric softener and fabric conditioner with water.
This prevents blockages.
ʑ
Additional
functions
Choose the additional functions before start . a Page 7
S
peed wash For a shorter wash time with a comparable washing effect.
R
inse plus Additional rinse cycle, extended washing time. For areas with
very soft water or for further improvement of the rinsing result.
Intensive For saving energy with a comparable washing effect to the
standard programme.
ʑ
Start / Reload
For starting or reloading the programme, with the function of adding the laundry in the process.
ʑ
Signals
ʑ
Childproof lock ( Programme will not be changed by accidental operation.
To activate the childproof lock:
After the programme starts or finish in time is activated, press and hold the Start/
Reload button for 5 seconds;
Release when the ( symbol lights up. If button signal is on, an acoustic signal will be
heard.
( symbol flashes if the programme has been changed while childproof lock is activated.
When the programme ends, is displayed, (is still on. The Start/Reload indicator
remains on to remind you to deactivate the childproof lock.
To deactivate the childproof lock:
Select the Start/Reload button until the ( symbol turns off.
Release the button.
Set to  for
5 seconds
Press and
hold
1 step
clockwise
Button signals** Information signals**
Press
button and
Set volume
*
Press
button and Set
volume
*
1 step
clockwise
Set to Â
Release
*If required, set repeatedly.
** Button signals : Select additional functions, set programme or Start/Reload can be hinted.
 Information signals : Programme finished or given an alarm.
direct
1. Start signal mode
1. Set volume for ...
Removing laundry
Open washing machine door and remove laundry.
Leave washing machine door and detergent drawer
open so that any residual water can evaporate!
Turn off the tap
Switch off
displaying, Set Programme selector to ÂOff then
you can open the door.
7
Detergent drawer with
compartments I, II, ~
Control panel
Door handle
Drum
Set programmes, additional functions
Closing the door
Drain pump mulch
For additional functions and
option buttons apage 5, 6
Programmes
Detailed programme overview.
apage 7
Super 15 / 30 Extra short programme
Denim Jeans and dark color textiles
Sportswear Sportsweare made of microfibre
Kidswear
Textiles for Kids
Mix Textiles made of cotton and
synthetics
Easy care Synthetics, easy-care textiles
Silk Silk and delicate washable textiles
Outdoor Textiles with membrane coating and
water-resistant textiles
Cotton Hard-wearing textiles
Prewash Heavily soiled hard-wearing textiles
Intensive
Heat-resistant textiles made of cotton
or linen
Antibacteria
Program for allergic people and
advanced hygiene
Wool d Hand and machine-washable wool
or wool-rich textiles
Rinse Extra rinse with spin
Spin / Empty Additional spin cycle or to empty the
drum
1
5
Selecting Start / Reload
6
Programme ended when ...
Start/Reload goes out and or (if was
selected, no final drain/spin) is indicated on the display
panel, the buzzer sounds. Set volume of buzzer. apage 6
If displays, Spin/Empty was selected, choose the
Start/Reload button, the programme will run with draining
the water and spinning the laundry.
Change the programme ...
If you have selected the wrong programme by mistake:
Reselect the programme.
If necessary, set programme and select additional
functions. apage 5,6
Select Start/Reload.
Pause the programme ...
Select the Start/Reload button.
Follow the instructions in the display field: when r lights
up and appears in the display, the door can be
opened. If required, add/remove a laundry item; If is
displayed, it means the door can not be opened due to
a high water level in drum or a high temperature.
Select Start/Reload button to continue the programme.
... or terminate the programme
Programmes with high temperature:
Cool down laundry: Select Rinse.
Select Start/Reload.
Programmes at lower temperature:
Select Spin/Empty.
Select Start/Reload.
Programme selector for switching the
machine on and off and for selecting the
programme. Can be rotated in either
direction.
ʑ
Display symbols


ʑ
Display information

Time, spin speed and
kilogramme will rolled
diaplay before start, only
to dispaly finish in time
when it start. Display
information is depended
on different machine and
programme.
ʑ
Programme setting buttons
You can change the spin
speed and temperature
beforehand and while the
selected programme is
running.
Washing: On if machine is washed, if flashes, too
much detergent is used. a
Page 12
Rinse: On if machine is rinsed.
S
pin: On if machine is spun.
r Door: On if door can be opened.
(ü
C
hildproof lock: On if childproof lock is activated.
Flashing aPage 6 ,Activate/deactivate childproof lock
Time e.g. * : programme remaining time.
* : Finish in time defined by user. a
Page 5
°C Temperature FH°C:programme rinse temperture.
Spin speed FHc : programme spin speed.
kg e.g. kg*: maximum load recommendation for
selected programme aPage 7, Programme overview
: Door can be opened when programme was
paused.
: Door can not be opened due to a high water level
in drum or a high temperature.
: Finish of programme.
: End of programme with the setting (without
final spin)
: Set signal mode and volume. aPage 6
Information on the display. a Page 10
°C Temperature: You can alter the display temperature,
and the highest temperature is depend on what
programme you choose. aPage 7, Programme
overview
Spin: Select the spin speed (* depending on model)
or (Rinse hold = without final spin, the washing
remains in the final rinsing water, on the display
panel); when you choose Spin/Empty, on the
display means it switches to empty programme.
Finish in: When you select a programme, the
respective programme duration is displayed. You can
delay the start of the programme before it begins. The
finish-in time indicates when the programme will be
finished. It can be set in hour increments up to a
maximum of 24h. Press and hold the Finish in button
until the required number of hours is shown (h=hour).
Select Start/Reload.
Set programmes, additional functions
 Read these instructions and the separate installation
instructions before operating the washing machine.
GB Standards:
GB4706.1-2005
GB4706.24-2008
GB19606-2004
GB4343.1- 2009
GB17625.1-2003
GB/T 4288-2008
GB12021.4-2004
Chief Distributor: BSH Home Appliances (China) Co., Ltd.
20, 21F CN International Mansion No. 129 Zhongshan Road
210005 Nanjing, Jiangsu Province, P.R.China
Protection of the environment/Conservation tips
Always fill the washing machine with a maximum amount of
laundry for the relevant programme.
Wash normally soiled laundry without prewash.
Select Intensive 60 °C programme can reach good cleaning
result with significantly lower energy consumption.
Does detergent according to the manufacturers instructions
and water hardness.
If the laundry is then dried in the tumble dryer, select spin
speed according to the instructions of the dryer manufacturer.
Any failure and losses caused by ingoring the above
mentioned items and cautions mentioned in the operation
and installation instruction are not covered by our warranty
and liability.
 Please keep all documents in a safety place for further
reference. If you have any doubt, please contact our local
service center.
Follow the safety instructions on page 8!
7
BSH Electrical Appliances (Jiangsu) Co., Ltd.
No.208 Yaoxin Road, Nanjing Economy and Technology Development Zone
210046, Jiangsu Province, P.R.China
WLO20260TI WAP20268TI
WLO20268TI WAP24269TI
9000852412
0113
Programme overview (see also the information on page 5,6)
Programmes

max. load
 (kg)
Type of laundry 
Compartment
*
Speed wash
Rinse plus
Intensive
Rinse cycles
**
***
~
Outdoor
$PME
2.0 Weatherproof and outdoor clothing with membrane coating and water-resistant textiles.
()
Cotton
$PME
7.5/5.6**
Standard washing program for hard-wearing textiles made of cotton or linen.
()
Prewash
Energy-intensive program for heavily soiled hard-wearing textiles made of cotton or linen.
()
Intensive
$PME
Long time washing program for heavily soiled hard-wearing textiles made of cotton or linen.
()
Antibacteria
$PME
7.5/5.6**
Program special designed for allergic people and advanced hygiene, suitable for hard-wearing
textiles made of cotton or linen.
()
Wool
$PME
2.0
Hand and machine-washable wool or wool-rich textiles. Especially gentle wash program to
prevent shrinkage, longer program pauses (textiles rest in wash liquor)
e.g. cashmere, ohair or angora. Also suited for hand washable silk.
Super15/30
2.0
Extra short program approx. 15 / 30 minutes, suitable for lightly soiled and small amounts of laun-
dry.
3.5
Denim
3.0
Program suitable for washing Jeans and other dark color textiles made of cotton or synthetic
textiles.
()
Sportswear
2.0
Suitable for sportsweare made of microfibre e.g Acrylic, Nylon, Spandex etc.
()
Kidswear
$PME
3.0 Program suitable for washing kidswear made of cotton or synthetic textiles.
()
Mix
$PME
4.0/3.5
**
Mixed load consisting of textiles made of cotton and synthetics.
()
Easy care
$PME
Textiles made of synthetic materials or blended fabrics.
()
Silk
$PME
2.0 For delicate, washable textiles, e.g.made of silk, satin, synthetic fibres or blended fabrics.
()
Rinse Extra rinse with spin.
()
SpinEmpty
Select for additional spin cycle or to empty the drum.
/
The programmes are time-controlled for lightly soiled textiles. If textiles are heavily soiled, reduce the load and select additional function, e.g. Intensive.
Max. load according to GB 12021.4-2004.
* :RObligate ;:optional.
** /,Digram in the left refer to WAP serious, in the right refer to WLO serious.Defalut rinse cycles (Max. Rinse cycles after selecting Rinse plus function.)
Download manual in English (PDF, 4.24 MB)
(Consider the environment and only print this manual if it is really necessary)

Loading…

Rating

Let us know what you think about the Bosch WAP24269TI Washing Machine by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.
Are you satisfied with the Bosch WAP24269TI Washing Machine?
Yes No
Be the first to rate this product
0 votes

Join the conversation about this product

Here you can share what you think about the Bosch WAP24269TI Washing Machine. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.

More about this manual

We understand that it’s nice to have a paper manual for your Bosch WAP24269TI Washing Machine. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Bosch. They might be able to provide an original manual. Are you looking for the manual of your Bosch WAP24269TI Washing Machine in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

Brand Bosch
Model WAP24269TI
Category Washing Machines
File type PDF
File size 4.24 MB

All manuals for Bosch Washing Machines
More manuals of Washing Machines

Frequently Asked Questions about Bosch WAP24269TI Washing Machine

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

My washing machine won't start when I press the start-button, what can I do? Verified

In many cases the door of the washing machine hasn't closed properly. Open and close the door and try again.

This was helpful (23040) Read more

My washing machine won’t drain, what can I do? Verified

The main reason a washing machine won’t drain is because of blockage in either the pump or the drain hose. If your washing machine has access to these parts, try to remove any blockage. If this does not solve the problem or if you don’t have access to these parts you should contact a mechanic or the manufacturer.

This was helpful (22447) Read more

There is no water coming into my washing machine, what can I do? Verified

Check if the water inlet is open and if there aren't any kinks in the hose of the water inlet. If this doesn't solve the problem you should contact the manufacturer.

This was helpful (8865) Read more

The door of my washing machine won't open, what can I do? Verified

There can be several causes. The most common cause is the filter being clogged. Unplug the appliance and check the filter. Remove any blockage if necessary. The location of the filter is different depening on the model. It is also possible that there is a special lever to open the door. If these options don't help, the last option is unplug the appliance for a period of 30-60 minutes and try to open the door after that. If this doesn't work, contact the manufacturer or a mechanic.

This was helpful (7346) Read more

My washing machine makes a lot of noice and/or vibrates loudly, what can I do about that? Verified

It's possible that the washing machine has not been leveled. You can do this by adjusting the feet to make it perfectly level. The problem can also be caused by inserting to much clothes in the machine. If these are not the cause of your problem you should contact the manufacturer.

This was helpful (6358) Read more

In which compartment should the detergent go? Verified

Most washing machines have 3 compartments for detergent. These compartments are often marked with I, II and * to show where the detergent goes. Compartment I is used for a pre-wash cycle, II is for the main wash cycle and * is for fabric softener. Compartment II is used most often.

This was helpful (4334) Read more

My washing machine smells, what can I do about it? Verified

There are washing machines with self-cleaning features. If these features are not available it's possible to add 100ml of white vinegar or 100gr of soda crystals and have the washing machine run a 90 ℃ program.

This was helpful (3548) Read more

Can I connect my washing machine to a warm water outlet? Verified

Although washing machines can probably handle water intake up to 65°C, this is not recommended by most manufacturers. There are wash cycles that specifically make use of cold water. In those cases warm water can harm the results of your wash cycle. Also, many washing machines are designed to be connected to a cold water outlet.

This was helpful (2832) Read more

What should I pay attention to when moving a washing machine? Verified

When moving a washing machine, you should secure the drum. You can use the transit bolt which come with every washing machine and will prevent the drum from moving around inside the machine. You also need to drain all the water.

This was helpful (1391) Read more

What is the difference in usage between a washer-dryer and a separate washing machine and dryer? Verified

The biggest advantage of a washer-dryer is that it takes less space. However, a separate dryer will be able to dry more than a washer-dryer. A washer-dryer also uses relatively more energy and requires more time.

This was helpful (1097) Read more

Can I stack my dryer and washing machine? Verified

In general it is possible to directly stack a dryer and washing machine directly on top of each other. This only works with front loading models. However, it is advisable to use a fitting accessory to do so. This will prevent the machines from vibrating and falling off and also prevents damage to the bottom machine.

This was helpful (1094) Read more

Can I connect a washing machine to an extension cord? Verified

Appliances that require large amounts of power, like a washing machine, can not be connected to all extension cords. See what the power usage of the washing machine is, which is indicated in Watt, and check if the extension cord can handle this. There are extension cords with thicker cables that are made to handle larger appliances.

This was helpful (1093) Read more

My Bosch washing machine displays error "F21", what does this mean? Verified

Error "F21" indicates a wiring problem or a problem with the programming of the module of the machine. It is recommended to contact a mechanic.

This was helpful (359) Read more

Where can I find the model number of my Bosch washing machine? Verified

In general the model number can be found on a sticker on the inside of the door of your appliance.

This was helpful (280) Read more

My Bosch washing machine displays error 'E17', what does this mean? Verified

Error E17 indicates that the water supply is taking too long to start. It's possible that the water supply is closed. If this isn't the cause of the problem you should contact the manufacturer.

This was helpful (276) Read more
Manual Bosch WAP24269TI Washing Machine

Related products

Related categories
