Manual BEKO WTL160G Washing Machine

Manual

Other functionsCautionsCautions

FULLY AUTOMATIC WASHING MACHINE

Operation Manual

It is most important that this instruction book should be retained with the

appliance for future reference. Should the appliance be sold or transferred

to another owner, or should you move house and leave the appliance, always

ensure the book is supplied with the appliance in order that the new owner

can get to know the functioning of the appliance and the relevant warnings.

These warnings have been provided in the interest of safety. You must read

them carefully before installing or using the appliance.

16.0kg

WTL160G

Use of detergent

Specification

Weight

220-240V~ 50Hz

Rated voltage and

frequency

Rated capacity of wash

and spin

Water level/water volume

(about)

Inlet pressure

WTL160GModel

Rated input power

Product Dimensions

Wash：570W

spin：375W

0.05MPa-0.85MPa

16.0kg

10/112L 9/104L 8/96L 7/90L

6/82L 5/74L 4/68L 3/60L

2/54L 1/48L

About 54kg

W665mm D675mm H1060mm

Do not put hands into the working machine.

It is dangerous even if the speed is very slow.

Take special care of the children, and forbid

them to climb on the washing machine.

It is dangerous to alter the specifications or

attempt to modify this product in any way.

Do not overload the appliance or put any

hotgoods(such as the kettle with hot water)

on thewashing machine.

Garments which have been in contact with

volatile petroleum products should not be

machine washed.

Keep the appliance away from direct

sunlight and heat sources like the heater.

This appliance is not intended for use by

persons(including children) with reduced

physical, sensory or mental capabilities, or lack

of experience and knowledge, unless they have

been given supervision or instruction concerning

use of the appliance by a person responsible for

their safety.

Children should be supervised to ensure that

they do not play with the appliance.

Preparation before operation

Preparation before washing

1. Connect the inlet hose and open the tap.

2. This appliance must be earthed. Confirm

the socket is earthed reliably and insert the

power plug. The earth terminal should not

link to gas pipeline, tap pipeline etc.

3. Hang up the drainpipe.

Warning: the temperature of the water should be less than 50℃！

Before washing the laundries, please pay attention to the

followings:

Make sure if

there is special

requirements for

the laundries

Before washing,

empty all pockets of

small objects which

may have been left

inside(coins, keys,

screws etc.).

Knot the long

band, fasten the

buttons and close

the zippers.

Do not overload

the machine.

Load the laundry

loosely alternating

large items with

small ones.

Sort the laundry

according to the

type of fabric,

color-fastness and

how dirty it is. Put

thin laundries,

woolens and such

prone to wear and

tear laundries into

washing bag.

A. Make sure the laundries are washable.

B. It is essential to wash new colored items separately when washing for the first time. White

items should not be washed with colored items.

C. Please immerge the non-absorbable laundries by hand.

D. Some stains such as fruit, wine, grass, rust etc. are difficult to remove and should be treated

before washing with specific products, which can be found in most household shops.

In some cases it may help to soak the stain before washing with a special pre-soak product

or biological detergent.

E. Overturn the nap fabric and long floss laundries before putting them into the machine.

F. Do not put the laundries polluted by chemicals into the machine directly.

G.Very small item(handkerchiefs, ribbons, socks etc) should be washed in a washing bag or a

pillow case.

Load laundries

The capacity of washing and spinning of the machine is refer

to the largest weight of the standard laundries under dry

condition. Washing quantity shall be lower than the rated

capacity. The maximum capacity of this machine is 16.0kg.

Different thickness, size and type of the laundries will

influence the actual washing capacity.

Do not select high water level when laundries are less than

1.5kg to avoid water splashing.

Remarks：avoid splashing of water and waste of washing powder, water level should not

be too high if laundries are too small.

How to use bleach

How to use the washing powder

Dissolve in the machine directly（not suitable

for preset program）

1. Low water level.

2. Add the washing powder, and run for 30

seconds to dissolve it completely.

3. Put laundries in and select suitable water

level.

The instant dissolving of the washing powder

1. Prepare warm water of 30℃ in a container.

2. Pour the powder while stirring to fully

dissolve it.

Washing powder with poor quality or not used

for a long period may get blocked, please clean

the detergent box in time.

Fill water to the selected level,

dilute the bleach in the container,

and pour it slowly into the washing

tub.

Do not use bleach for colored or

figured laundries as they are prone

to lose colors.

Do not put bleach to laundries

directly.

Refer to the manual for the usage

and quantity of the bleach.

Please dissolve powder bleach

before use.

Before washing, please ensure the tap is openand the inlet hose is installed properly.

It is suggested to use low foam washing powder.

Any objects such as coins, safety pins, nails, screws, stones or any other hard, sharp

material can cause extensive damage and must not be

placed into the machine.

Error Code Error Code explanation Solution

E1

After draining for 7 minutes,it still

does not reach to the minimum

of water level

Please refer to Page 8 for troubleshooting

E0

The top lid is opened

when preset is started

Close the top lid and clear the alarm

E2

The top lid open when spinning Close the top lid and clear the alarm

E4

After inflow of water for 40

minute, it still does not reach to

the water level set

Please refer to Page 8 for troubleshooting

E3

Spin is not balance

Open the top lid, place the laundries equally,

then close it and clear the alarm

E5

F1

The top lid is opened after setting

child-lock

Close the top lid an d cl ear the ala rm

Water Level sensor is abnormal

Cut off the power supply to find a professional

staff to process

Notice: if there is still fault after check above items, please remove the plug from power supply

and contact with local service team

Fault explanation

Notice:

1.Imbalance adjustment:

During spinning, if the laundries are not placed equally in the tub, it would cause Violent vibration.

This machine has imbalance adjustment function, and the vibration testing system will supervise

the running. Once vibration is beyond certain level, the adjustment system will start automatically

to adjust the imbalance.

2.Power supply is cut off automatically:

1) If you did not start the program in 10 minutes after pressing the power supply button, the power

supply will be cut off automatically.

2) After the washing is finished, alarm buzzes and the power supply will cut off automatically.

3.Child lock function:

1)When child lock function is set, all the buttons will be locked including POWER. If the top lid is

opened during the washing machine working, the washing will be stopped and give an alarm. But if

you can close the top lid in 5 seconds, the alarm will stop and the washing machine will continue

working. If cannot close the top lid in 5 seconds, the washing machine will begin draining if there is

water in the inner tub, even closing the top lid is not valid. During the draining, alarm will buzz

every 10 seconds, when the water in the inner tub is about 5cm higher, alarm will buzz every 10

minutes.When the draining is finished, the washing machine will be in the state of waiting, if close

the top lid, the washing machine is unlocked and start working as previous setting.

2)Once child lock is set, if top lid is opened over 5 seconds during washing or rinse(there is water

in the inner tub), washing machine will drain and alarm will buzz. If you unlock the function during

draining, the washing machine will add water to water level set and continue working.

4.Water recycle function

When water recycle function is set, after the last rinse finished, the washing machine will not drain

and spin.SPIN and WATER RECYCLE indicator light will be flashing and alarm will be given,the

washing machine will stop working (if nobody operate, the alarm will be given every 10 minutes,

in 1 hour, power supply will be cut off automatically). When press START/PAUSE, WATER RECYCLE

indicator light is on and the washing machine begin to drain and spin, the user can reuse the water.

Please insert the plug into the power socket

with rated voltage 240V A/C.

Do not make the electric cable bended, stretched, twisted, strapped or changed, pressed or

nipped. If the supply cord is damaged, it must be replaced by the manufacturer,its service

agent or similarly qualified persons in order to avoid a hazard. The pin of the

plug must remain clean. Please clean it carefully

with dry cloth if it is dirty.

Do not use water hotter than 50℃

Ventilation holes

at the bottom

Soft item

Do not share the same socket with other electric

appliances. Do not use the damaged plug or loose

socket.

Warning

Symbol definition

Always unplug the appliance and turn off

the water when the power is cut, moving or

cleaning the washing machine, or it is not in

use. Do not insert or pull off the plug with

wet hand.

Do not wash raincoat, bike cover, feather

dress and waterproof laundries, which will

caused the washing machine to have

abnormal vibrations during spinning.

If the machine is situated on a carpeted

floor, please adjust the feet in order to allow

air to circulate freely.

Forbidden

Pay special attention to the

warning symbols. There may be

serious risks to personal body

safety or damages to the washing

machine if not follow.

Please stop doing the contents with

this symbol, otherwise it will damage

the appliance or injure your personal

body.

Don t install the washing machine in

bathroom or damp places. Do not wash the

machine with water, do not put wet clothes

on the control panel film.

How to use softener

The machine automatically adds the softener to the

inner tub during the last "rinse" process.

pls put the needed washing power

in the detergent box and softener in

softener box evenly

Softener box

Rating
