Before using the washing machine
1.Remove the packaging
and check
After unpacking, make sure
that the washing machine is
undamaged. If in doubt, do
not use the washing
machine. Contact After-
Sales Service or your local
dealer.
Keep the packaging
materials (plastic bags,
polystyrene parts, etc.) out of
reach of children, since it is a
possible source of danger.
2.Remove the transit
bolts
The appliance is fitted with
transit bolts to prevent
internal damage during
transport.
Before using
the washing machine you
must remove the transit
bolts
(see “Installation/
Remove the transit bolts”).
3.Install the washing
machine
Install the appliance on a
solid and level floor surface.
In the case of a yielding sub-
floor, the appliance should
be installed in the corner of
a room.
Adjust the feet to ensure that
the machine is stable and level
on the floor (see “Installation/
Adjust the feet”).
4.Water inlet
Connect the water supply
inlet hose in accordance
with the regulations of your
local water company (see
"Installation/Connect the
water supply hose").
Water
supply: Cold water only
Tap: 3/4” threaded
hose connection
Pressure: 100-1000 kPa
(1-10 bar).
5.Drain hose
Connect the drain hose to
the ventilated siphon or
hook it over the edge of a
sink by means of the "U"
bend (see "Installation/
Connect the water drain
hose").
6.Electrical connections
Electrical connections must
be carried out by a qualified
electrician in compliance
with the manufacturer's
instructions and local safety
regulations.
Voltage information, power
consumption and electrical
fusing data are supplied on
the front panel behind the
door frame.
The appliance must be
connected to the mains
exclusively by means of a
socket with an earth
connection in accordance
with established
regulations. The appliance
must be earthed by law. The
manufacturer declines all
liability for possible damage
to property or injury to
persons or pets deriving
from failure to observe the
a/m directions.
Do not use extension leads
or multi sockets.
Before any maintenance on
the washing machine
disconnect the power plug or
switch off the power supply.
Access to the mains plug or
to disconnection from mains
supply via a double-pole
switch must be ensured at all
times following the
installation.
Do not operate the washing
machine if it has been
damaged during transport.
Inform the After-Sales
Service.
Mains cable replacement is
only to be carried out by
After-Sales Service.
The washing machine must
only be used in the
household for the
prescribed uses.
4gb15150.fm Page 2 Monday, July 8, 2002 7:00 PM
Download manual in English (PDF, 0.66 MB)
(Consider the environment and only print this manual if it is really necessary)

Loading…

Rating

Let us know what you think about the Bauknecht WAB 1000 SW Washing Machine by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.
Are you satisfied with the Bauknecht WAB 1000 SW Washing Machine?
Yes No
Be the first to rate this product
0 votes

Join the conversation about this product

Here you can share what you think about the Bauknecht WAB 1000 SW Washing Machine. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.

More about this manual

We understand that it’s nice to have a paper manual for your Bauknecht WAB 1000 SW Washing Machine. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Bauknecht. They might be able to provide an original manual. Are you looking for the manual of your Bauknecht WAB 1000 SW Washing Machine in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

Brand Bauknecht
Model WAB 1000 SW
Category Washing Machines
File type PDF
File size 0.66 MB

All manuals for Bauknecht Washing Machines
More manuals of Washing Machines

Frequently Asked Questions about Bauknecht WAB 1000 SW Washing Machine

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

My washing machine won't start when I press the start-button, what can I do? Verified

In many cases the door of the washing machine hasn't closed properly. Open and close the door and try again.

This was helpful (25275) Read more

My washing machine won’t drain, what can I do? Verified

The main reason a washing machine won’t drain is because of blockage in either the pump or the drain hose. If your washing machine has access to these parts, try to remove any blockage. If this does not solve the problem or if you don’t have access to these parts you should contact a mechanic or the manufacturer.

This was helpful (24040) Read more

There is no water coming into my washing machine, what can I do? Verified

Check if the water inlet is open and if there aren't any kinks in the hose of the water inlet. If this doesn't solve the problem you should contact the manufacturer.

This was helpful (9757) Read more

The door of my washing machine won't open, what can I do? Verified

There can be several causes. The most common cause is the filter being clogged. Unplug the appliance and check the filter. Remove any blockage if necessary. The location of the filter is different depening on the model. It is also possible that there is a special lever to open the door. If these options don't help, the last option is unplug the appliance for a period of 30-60 minutes and try to open the door after that. If this doesn't work, contact the manufacturer or a mechanic.

This was helpful (8331) Read more

My washing machine makes a lot of noice and/or vibrates loudly, what can I do about that? Verified

It's possible that the washing machine has not been leveled. You can do this by adjusting the feet to make it perfectly level. The problem can also be caused by inserting to much clothes in the machine. If these are not the cause of your problem you should contact the manufacturer.

This was helpful (6946) Read more

In which compartment should the detergent go? Verified

Most washing machines have 3 compartments for detergent. These compartments are often marked with I, II and * to show where the detergent goes. Compartment I is used for a pre-wash cycle, II is for the main wash cycle and * is for fabric softener. Compartment II is used most often.

This was helpful (5104) Read more

My washing machine smells, what can I do about it? Verified

There are washing machines with self-cleaning features. If these features are not available it's possible to add 100ml of white vinegar or 100gr of soda crystals and have the washing machine run a 90 ℃ program.

This was helpful (4256) Read more

Can I connect my washing machine to a warm water outlet? Verified

Although washing machines can probably handle water intake up to 65°C, this is not recommended by most manufacturers. There are wash cycles that specifically make use of cold water. In those cases warm water can harm the results of your wash cycle. Also, many washing machines are designed to be connected to a cold water outlet.

This was helpful (3043) Read more

What should I pay attention to when moving a washing machine? Verified

When moving a washing machine, you should secure the drum. You can use the transit bolt which come with every washing machine and will prevent the drum from moving around inside the machine. You also need to drain all the water.

This was helpful (1599) Read more

Can I stack my dryer and washing machine? Verified

In general it is possible to directly stack a dryer and washing machine directly on top of each other. This only works with front loading models. However, it is advisable to use a fitting accessory to do so. This will prevent the machines from vibrating and falling off and also prevents damage to the bottom machine.

This was helpful (1355) Read more

Can I connect a washing machine to an extension cord? Verified

Appliances that require large amounts of power, like a washing machine, can not be connected to all extension cords. See what the power usage of the washing machine is, which is indicated in Watt, and check if the extension cord can handle this. There are extension cords with thicker cables that are made to handle larger appliances.

This was helpful (1315) Read more

What is the difference in usage between a washer-dryer and a separate washing machine and dryer? Verified

The biggest advantage of a washer-dryer is that it takes less space. However, a separate dryer will be able to dry more than a washer-dryer. A washer-dryer also uses relatively more energy and requires more time.

This was helpful (1315) Read more
