Manual

GB -1-

Chart

PROGRAM SELECTION

BUTTON

Push “Programs” button

(repeatedly) until the indicator

of the required program lights

up (see “Table of programs”

below).

(see at right for options description)

START/RESUME BUTTON

Push this button to start the selected program: the

indicator lights up and goes off at the end of the program.

When the door is opened during a washing cycle, the

cycle is temporarily paused: the Start indicator blinks.

To resume the cycle push Start button and close

the door within 3 seconds.

CANCEL/OFF BUTTON

Push this button to switch off the control panel.

If pressed when a program is running it cancels the

program ongoing draining water for 1 minute

(0:01 is shown into the display).

If pressed when the dishwasher is switched off,

it drains any possible liquids from dishwasher

(1 minute process).

1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions (without additional

options) and may vary depending on conditions. Differences of up to 20 minutes are possible with sensor programs as a result of the

appliance’s automatic calibration system.

2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information

on the EN/Standard loading comparison test and other tests, contact the following address: “nk_cust[email protected]”.

3) The antibacterial action has been tested by the Institut Pasteur of Lille (France), based on the NF EN 13697 standard of November 2001.

Table of programs

Deter-

gent

Consumption

Drying

Phase

Programs

Available

options

Loading instructions

Litres kWh

Minutes

Sensor 40-70°C

Delay

Power Clean

Antibacterial

rinse

Normally or heavily soiled crockery,

including pots and pans. Thanks to steam

action, soaking or hand pretreatment is no

longer needed. In addition hygiene is

ensured due to the high temperature steam.

X 7-14 0.99-1.80 70-160 Full

Pre-Wash cold

Delay Crockery to be washed later. — 4.0 0.03 14 NO

Glasses 40°C

Delay

Light soiling, for example glasses and

cups.

X 10.0 0.85 100 Light

Quickwash 45°C

Delay

Lightly soiled crockery, with no dried-

on food.

X 11.0 0.80 30 NO

Bio Normal

50°C

Delay

Power Clean

Antibacterial

rinse

Normally soiled crockery.

Energy-saving program.

X 11.0 1.03 170 Full

Daily 60°C

Delay

Antibacterial

rinse

Normally to heavily soiled crockery. X 10.0 1.30 80 Full

5019 496 01696

Options and display description

POWER CLEAN

Thanks to the additional power

jets this option provides a more

intensive and powerful wash in

the lower rack, in the specific

area. This option is

recommended for washing pots

and casseroles (see page 4).

Press this button to activate

Power Clean (the indicator

lights up).

TABLET SETTING

This setting allows to

optimize the cycle

performances according

the type of detergent

used. Push the Tablet

button for 3 seconds (until

the indicator lights up) if

you are using the

combined detergents in

tablet (rinse aid, salt and

detergent in 1 dose). If you

are using powder

detergent or liquid

detergent, the Tablet

indicator on the control

panel has to be off.

DELAYED START

BUTTON

Push the button

(repeatedly) to delay the

start of the program.

Adjustable from 1 to 24

hours. With each press of

the button, the delayed

start indicator increases

by one hour and after 24

restarts from 0. Then

press the START button.

The dishwasher will start

after the set time.

ANTIBACTERIAL RINSE

This function activates an

antibacterial rinse at the end of the

wash cycle, guaranteeing a further

reduction of bacteria. Press the

button to activate or deactivate the

function. This function can be used

with the programs indicated in the

table of programs. The dishwasher

door must be kept shut for the entire

duration of the program in order to

guarantee reduction of bacteria. If

the door is opened the indicator lamp

starts flashing.

BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ

THIS QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!

SALT INDICATOR

When lit (at the end of the cycle),

the salt reservoir needs to be

refilled.

RINSE AID INDICATOR

When lit (at the end of the cycle),

the rinse aid dispenser needs to be

refilled.

WASH TIME DISPLAY

Indicated the cycle duration and the remaining time (h:min). With “Delayed start” selected it indicates

the time remaining until program start (h.00) - below 1h (0:min).

If “Fx Ey” messages appears on the display, see page 6 - chapter “What to do if...”.

THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING

ANY BUTTON EXCEPT CANCEL/OFF BUTTON. FOR ENERGY SAVING

THE CONTROL PANEL DEACTIVATES AUTOMATICALLY AFTER 30

SECONDS IF NO CYCLE HAS STARTED.

Quick reference guide
