Manual Bauknecht GSXA 6130 TR A+ Dishwasher

Manual

EN -1-

Chart

5019 400 00417

BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ THIS QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!

THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING ANY BUTTON EXCEPT CANCEL/OFF BUTTON.

FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES AUTOMATICALLY AFTER 30 SECONDS IF NO CYCLE HAS STARTED.

PROGRAMS SELECTION

BUTTON

Push “Programs” button

(repeatedly) until the indicator

of the required program lights

up (see “Table of programs” -

next page).

ANTIBACTERIAL

RINSE

3)

This function activates an

antibacterial rinse at the end of

the wash cycle, guaranteeing a

further reduction of bacteria.

Press the button to activate or

deactivate the function. This

function can be used with the

programs indicated in the table

of programs. The dishwasher

door must be kept shut for the

entire duration of the program

in order to guarantee

reduction of bacteria. If the

door is opened the indicator

lamp starts flashing.

DELAYED START

BUTTON

Push the button (repeatedly)

to delay the start of the

program. Adjustable from 1 to

24 hours. With each press of

the button, the delayed start

indicator increases by one

hour and after 24 restarts from

0. Then press the START

button. The dishwasher will

start after the set time.

TABLET SETTING

This setting allows to optimize

the cycle performances

according the type of

detergent used. Push the

Tablet button for 3 seconds

(until the indicator lights up) if

you are using the combined

detergents in tablet (rinse aid,

salt and deteregent in 1 dose).

If you are using powder

detergent or liquid detergent,

the Tablet indicator on the

control panel has to be off.

START/RESUME

BUTTON

Push this button to start the

selected program: the

indicator lights up and goes off

at the end of the program.

When the door is opened

during a washing cycle, the

cycle is temporarily paused:

the Start indicator blinks.

To resume the cycle push

Start button and close the

door within 3 seconds.

CANCEL/OFF BUTTON

Push this button to switch off

the control panel.

If pressed when a program is

running it cancels the program

ongoing draining water for

1 minute (0:01 is shown into

the display).

If pressed when the dishwasher

is switched off, it drains any

possible liquids from dishwasher

(1 minute process).

RINSE AID INDICATOR

When lit (at the end of the cycle),

the rinse aid dispenser needs to

be refilled.

SALT INDICATOR

When lit (at the end of the cycle), the

salt reservoir needs to be refilled.

WASH TIME DISPLAY

Indicated the cycle duration and the remaining time (h:min). With “Delayed start” selected

it indicates the time remaining until program start (h.00) - below 1h (0:min).

If “Fx Ey” messages appears on the display, see page 9 - chapter “What to do if...”.

Quick reference guide
