EN -2-

First time use

5

7

86

1

4

10

9

2

3

1- salt reservoir

2- rinse aid dispenser

3- detergent dispenser

4- racks system

5,6,7,8- available functions on the panel

9- filters

10- spray arms

1. Ask your water supply company what the water hardness is... 2. ...enter this value on

your dishwasher

Suggestions for detergent use

German

degrees °dH

French

degrees °fH

English

degrees °eH

Water hardness

level

3 first PROGRAM LEDs

lit on the panel

(see table of programs)

P1 P2 P3

Gel or Powder

(rinse aid and

salt)

Tabl et s

0 - 5 0 - 9 0 - 6.3 Soft 1

go to step 1

(see “Daily

check”)

6 - 10 10 - 18 7 - 12.6 Medium 2

11 - 15 19 - 27 13.3 - 18.9 Average 3

16 - 21 28 - 37 19.6 - 25.9 Medium-hard 4

if water is

HARD extra salt

needs to be

added

(go to step 1,

“Daily check”)

22 - 28 38 - 50 26.6 - 35 Hard 5

29 - 35 51 - 63 35.7 - 44.1 Very hard 6

36 - 50 64 - 90 44.8 - 62.4 Extremely hard 7

Water hardness should be set only

before the first wash or if water

hardness has been changed

1

Visual indicator

(depending

on the model).

Unscrew cap.

Fill the salt reservoir with water

before the first wash only.

(depending on the model)

The salt level indicator lamp may remain lit

at the end of several wash cycles. If the

water hardness level falls within category

(soft), no salt is required.

Salt indicator on the control panel Salt indicator on the salt reservoir cap

The indicator lamp lights up when SALT

NEEDS TO BE ADDED.

green: OK.

clear: NEEDS TO

BE ADDED

Daily check

Filling the salt reservoir - Dissolve limescale (not necessary if water hardness level is set to “soft”!)

- Press and hold together Programs and CANCEL/Off buttons for minimum 3 seconds.

- Programs LEDs will indicate the water hardness setting.

- Press the Programs button to increase setting (when the level reaches 7, the next key press will set the level back to 1.

- Wait 30 seconds (control panel switches off) or press START/Resume button to save setting.

Water hardness level is factory

set for medium-hard water

(level 4).

Even if you use tablets which

include salt functionality, you

must still add regeneration salt

since such detergents are not

effective enough at softening

hard water.

At first time use, the salt

reservoir has to be filled

independently from water

hardness level (see

description below in step 1

“Daily check”).

Screw on the cap.

Salt residual

around the cap

need to be

removed. Some

salt reservoir have

a level indicator

integrated in the

cap (see below

how to check).

Once regeneration salt is added, immediately start a wash program (the “Pre-wash” program alone is not sufficient). Residual saline solution or grains of salt can

lead to deep-down corrosion, irreparably damaging the stainless steel components. The guarantee is not applicable if faults are caused by such circumstances.

Add salt (never add detergent!)

min. 0.8 kg / max. 1 kg

How to set water hardness in order to always assure the best cleaning results
