Manual Bauknecht GSIK 6518/1 WS Dishwasher

Manual

GB

-1-

Chart

START

DELAY

option

ON/OFF

BUTTON

PROGRAM

SELECTOR

KNOB

(see “Table of

programs”

below).

START BUTTON

The indicator lights up during operation, flashes when a fault occurs, and goes off

at the end of the program.

START BUTTON RESET FUNCTION:

Press this button for at least 2 seconds; the selected program and options will be

cancelled. Main failure displays (repeated flashing of the START indicator lamp) can be

cancelled by RESETTING. Detailed instructions are given in chapter “What to do if...”.

(see at right for options description)

1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions

(without additional options) and may vary depending on conditions. Differences of up to 20 minutes are possible

with sensor programs as a result of the appliance’s automatic calibration system.

2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for

detailed information on the EN/Standard loading comparison test and other tests, contact the following address:

“[email protected]”.

3) The antibacterial action has been tested by the Institut Pasteur of Lille (France), based on the NF EN 13697

standard of November 2001.

Table of programs

Deter-

gent

Consumption

P

Programs

Available

options

Loading instructions

Litres kWh

Minutes

1)

1

Quickwash 45°C

Delay

Lightly soiled crockery, with no dried-

on food.

* Use of tablets not

recommended.

X * 11.0 0.80 30

2

Bio Normal

2)

50°C

Delay

Normally soiled crockery.

Energy-saving program.

X 12.0 1.05 165

3

Intensive 70°C

Delay

Recommended program for heavily

soiled crockery, especially suitable for

pots and pans.

X 14.0 1.55 155

4

Hygienic +

3)

Delay

Normally or heavily soiled crockery,

with additional antibacterial wash.

Program interruption (e.g. due to door

opening) can compromise elimination

of germs.

X 13.0 1.50 115

5

Half Load 50°C

Delay

Ideal for washing a half load of lightly

or normally soiled crockery.

X 10.0 1.04 145

5019 496 01672GSIK 6518

DELAYED START

BUTTON

Press the button

(repeatedly) to delay the

start of the program.

Adjustable from 1 to 24

hours. With each press of

the button, the delayed

start indicator increases by

one hour and after 24

restarts from 00. Then

press the START button.

The dishwasher will start

after the set time.

RINSE AID INDICATOR

When lit, the rinse aid dispenser

needs to be refilled.

SALT INDICATOR

When lit, the salt reservoir

needs to be refilled.

FAULT INDICATION AND WASH TIME DISPLAY

In normal operation it indicates the remaining time

(h:mm), whereas with “Delayed start” selected it

indicates the time remaining until program start (hh).

If “F..” appears on the display, see chapter “What to do if...”.

Options and display description

BEFORE USING THE APPLIANCE FOR THE

FIRST TIME CAREFULLY READ THIS QUICK

REFERENCE GUIDE AND THE ASSEMBLY

INSTRUCTIONS! THE GUARANTEE IS NOT

APPLICABLE IF FAULTS ARE CAUSED BY

INCORRECT USE OF THE APPLIANCE.

Quick reference guide
