BEFORE USING THE DISHWASHER/

CONNECTIONS

1. Removing the packaging and controls:

After unpacking, make sure that the dishwasher is

undamaged and that the door closes correctly. If in

doubt, contact a qualified technician or your local

retailer.

•

Keep the packaging materials (plastic bags,

polystyrene parts, etc.) out of reach of children, as

they are potentially dangerous.

•

This dishwasher has been factory tested to ensure

it functions correctly.

Such testing may leave slight water marks that will

disappear with the first wash.

2. Water and electrical connections:

All water and electrical connections must be

carried out by a qualified technician in compliance

with the manufacturer's instructions (refer to the

enclosed installation booklet) and current local

safety regulations.

The appliance must only be used in the household

for the prescribed uses.

Do not use the dishwasher if it has been damaged

in transit. Consult your local retailer or our

After-Sales Service.

(Refer to the separate installation

instructions booklet)

3. Water inlet and drain:

•

Observe any special regulations issued by your local

Water Board.

Water supply pressure: 0,03 - 1,0 MPa.

•

Make sure the inlet and drain hoses are kink-free

and are not crushed.

•

If the hose length is not sufficient, please contact

your local dealer or our After-Sales Service.

•

The inlet hose must be securely clamped to the

water tap to prevent leaks.

•

The inlet water temperature varies according to

the model installed. Inlet hose marked “25°C Max”:

maximum temperature 25°C.

All other models: maximum temperature 60°C.

•

When installing the appliance, make sure the drain

water discharges correctly (if necessary, remove

the wire gauze from the sink siphon).

•

Fix the drain hose to the spigot with a clamp to

prevent it from coming off during operation.

For appliances with water-stop system only: If the

water connections are made correctly, the water-

stop system safeguards your home against damage

caused by flooding.

4. Electrical connection:

•

Closely adhere to local Electricity Board

regulations.

•

Voltage information is shown on the rating plate

mounted inside the door on the right hand side.

•

The appliance must be earthed as prescribed by law.

•

Do not use extension leads or multiple adapters.

•

Before carrying out maintenance, disconnect the

mains plug.

•

If necessary, the power cable may be replaced with

one the same obtained from our After-Sales

Service. The power cable must only be replaced by

a qualified technician.

Warning for models provided with LCD

display:

The mains plug must be positioned in an easily

accessible place.

•For Austria:

if the apparatus is series connected to

a fault current switch, this must be sensitive to the

pulsating current.

EC Declaration of conformity

This appliance has been designed, constructed and

distributed in compliance with the safety

requirements of EC Directives:

•

73/23/EEC

•

89/336/EEC

•

93/68/EEC

Load capacity:

12 place settings.

49694157GB.fm Page 12 Friday, February 10, 2006 3:22 PM

Black process 45.0° 150.0 LPI
