Manual Bauknecht Excellence 4470U Washing Machine

Manual

5019 400 00334

Bauknecht is a registered trademark of Whirlpool USA

Load the laundry, close the door and turn the programme selector to

the desired programme; the

“Start/Pause”

indicator blinks.

The

temperature

and

spin speed

shown on the display can be

altered by pressing the “Temperature” or “Spin” button .

If you do not use the “Dosing Aid” , add detergent now. The

washing machine is designed to save energy; therefore, if you

have selected a programme but do not start it within about a

quarter of an hour, it will switch off automatically.To switch it on

again, turn the programme selector to “Off/O” and then to the

desired programme.

When the combination of programme and additional option(s) is

not possible, the indicators switch off automatically. Unsuitable

combinations of options are deselected automatically.

“15° Green & Clean” button

• Enables ecological washing by saving energy used for water

heating, while maintaining a good wash result.

• Bright colours live longer with this option; this was tested and

approved by the German “wfk” laundry research institute.

• Recommendable for lightly soiled laundry without stains.

• Make sure that your detergent is suitable for cold wash

temperatures (15 or 20°C).

• Not selectable for Cotton 70 - 95°C.

“Intensive rinse” button

• More water is added and rinse cycle is prolonged.

• This option is particularly suitable for areas with very soft water

or for washing baby linen, and helps people with allergies.

“Rapid” button

• Enables quicker washing by shortening the programme

duration.

• Recommendable for only lightly soiled laundry.

• Not selectable for Cotton 70 - 95 °C.

“Prewash” button

• Adds a prewash cycle to the wash programme selected;

prolongs the programme by about a quarter of an hour.

• Recommended for heavily soiled laundry (e.g. with sand or

granular dirt).

• Do not use liquid detergent for the main wash when activating

the “Prewash” option.

“Soil level” button

• Adapts the programme duration to the soil level of your

laundry. Also influences the detergent quantity

recommendation when using the “Dosing Aid” button.

= lightly soiled - = normally soiled - = heavily soiled

Not all soil levels are selectable for each programme.

“Spin” button (incl. “Rinse Hold” )

• Every programme has a predefined spin speed.

• Press the button to set another spin speed.

• If you select spin speed “0”, the final spinning is cancelled and

the water is drained out only. However, intermediate spin

phases remain during the rinse.

• If you select “Rinse hold” , the laundry remains in the last

rinse water without progressing to the final spin cycle, to avoid

creasing and prevent colours from changing. To activate the

“Rinse hold”, press the “Spin” button repeatedly until the “Rinse

hold” symbol on the display lights up.

- The wash programme stops to “Rinse hold” when the “Rinse

hold” symbol on the display blinks; the

“Start/Pause”

indicator also blinks.

- To terminate the “Rinse hold” by spinning the laundry, press

“Start/Pause”

- the laundry will be spun with the default

spin speed. You can also select another spin speed with the

“Spin” button before you start the spin cycle with

“Start/

Pause”

.

- To terminate the “Rinse hold” by draining the water without

spinning, press the “Spin” button until spin speed “0”

appears on the display; then press

“Start/Pause”

to start the

CONSUMPTION DATA

Programme Temperature (°C)

Load

(kg)

Water (l)

Energy

(kWh)

Approx. Programme Duration

(hours : minutes)

without “Rapid” with “Rapid”

Mixed 40 4.0 46 0.40 1:00 —

Cotton 95 7.0 74 2.20 2:40 —

Cotton 60 7.0 56 1.30 2:20 1:45

Cotton 40 7.0 68 0.75 2:05 1:15

Synthetics 60 3.0 48** 0.94 1:37 1:12

Synthetics 40 3.0 42 0.40 1:20 0:55

Delicates 40 1.5 60 0.65 0:50 —

Wool/Handwash 40 1.0 45 0.55 0:40 —

White 40 7.0 68 0.80 2:20 —

Light colours 40 4.0 50 0.45 1:20 —

Dark 40 4.0 40 0.53 1:40 1:15

Cotton *

60 7.0 46 0.87 4:00 —

Cotton *

60 3.5 37 0.68 3:00*** —

Cotton *

40 3.5 37 0.66 3:00*** —

AquaEco 40 3.0 19 0.50 1:00 —

Speed 15 30 3.0 20 0.15 0:15 —

Jeans 40 4.0 53 0.46 1:30 1:10

Consumption values were measured in normalized conditions, in compliance with IEC/EN 60456. In the home, they may vary depending on the individual

water supply pressure and temperature, the load and the type of wash. The consumption data indicated are based on an inlet water temperature of approx.

15 °C through the cold fill valve as well as the hot fill valve (if available). If your washing machine has a hot fill valve, connection of this valve to hot water

supply will lower the energy consumption by reduced heating times, depending on the individual hot fill inlet water temperature.

Water and energy consumptions refer to the default setting of the programmes, with temperature and load as indicated in the table; selecting any options

or changing the spin speed will also change the consumption data.

The programme duration may differ from the values indicated above as it depends on the operation conditions applicable at that time (see also

“Troubleshooting Guide” in your Instructions for Use).

** To reduce the water temperature, some cold water is added at the end of the main wash cycle before the water is drained.

*** Automatic adaptation of programme duration after detection of wash load.

* Reference programmes for Energy Label. For reasons of energy saving, the real water temperature may deviate from the declared cycle

temperature.

LOAD LAUNDRY, CLOSE DOOR AND

SELECT PROGRAMME

SELECT ANY DESIRED OPTION

draining.

- Do not leave the laundry to soak for too long in the “Rinse

hold” (especially silk!).

With this function you can postpone your programme to complete

at a later time: press the button to select in how many hours the

programme shall be finished. Thus, it allows you to have your

laundry ready at a particular time and to profit from more

favourable energy rates during the night, for example.

• The time until the cycle end can be selected in full hour time

segments (1 to 24 h). When you press the button, the shortest

possible time will be displayed; keep on pressing the button to

loop through all the available times. To remove it again, keep

on pressing the button until you see the value “0:00”.

• When you have selected the desired time until the cycle end,

press

“Start/Pause”

- the countdown will begin.

• During the countdown, you can still modify the programme

setting (select or deselect options, change spin speed etc.).

If the modifications prolong the programme duration so that it

overruns the originally set time until the cycle end, the

programme will start immediately.

• Sometimes the programme may finish before the selected time

until the cycle end has expired (e.g. for small loads). In this case,

the washing machine will tumble the laundry regularly to keep it

fresh, until the selected “Finish in” time has expired. During

tumbling, the display will show an animation. The tumbling

phase can be stopped at any time either by pressing any button

or by rotating the programme selector; the animation will stop

and the door will unlock in about 1 minute as indicated on the

display.

With the “Dosing Aid” button, you can make your washing machine

indicate you the recommended detergent quantity for your wash

load, depending on the soil level selected and the size of the load.

• Helps to save detergent and protect the environment and also

sensitive skin by avoiding detergent overdosing.

• Before you use this function, you must adapt the washing

machine to the dosing amounts which are recommended for

the detergents you use. Also check if your region’s water

hardness corresponds with the water hardness level “soft”

of your washing machine - if not adapt it.

• Select programme, options and cycle end BEFORE using the

“Dosing Aid” button.

For any details, refer to the separate “Dosing Aid” Instructions for Use.

Before starting and after end of a programme, the lamp lights to

show that the door can be opened. As long as a wash programme

is running, the door remains locked and must on no account be

forced open. In case you have an urgent need to open it during a

running programme, refer to “Reset a running programme before

the end”.

The “Eco monitor” gives you a rough feedback about the power

consumption of the programme setting you selected.

As soon as you turn the programme selector to any programme,

the “Eco monitor” is on.

The indicator on the left is to show that the “Eco monitor” is active.

The four indicators next to it show the degree of consumption:

the less power your programme setting is forecasted to consume,

the less indicators will light up. This depends on the programme,

temperature and options selected, and also on the size of the wash

load. For that reason, the forecasted degree of power consumption

may adapt when the washing machine detects the wash load.

Open the tap and press the

“Start/Pause”

button .

The indicator next to the

“Start/Pause”

button lights up.

Activating the child lock prevents children from starting a wash

cycle or changing the settings of a running programme. The child

lock cannot be activated or deactivated when the programme

selector is in the “Off/O” position. To activate the child lock:

• Turn the programme selector to a programme position, or run

a programme as usual.

• Press and hold the 2 buttons marked with the key symbol

simultaneously for a few seconds. A key-like symbol will

shortly appear on the display to indicate that the child lock is

active.

Any time you try to change a programme setting with active

child lock, the display will briefly show the key-like symbol.

The programme setting cannot be changed anymore. The only

change possible is to switch the washer off by turning the

programme selector to the “Off/O” position. To deactivate the child

lock:

• Press and hold again the 2 buttons marked with the key symbol

simultaneously for a few seconds.

If one of the failure indicators blinks, consult the “Troubleshooting

Guide” in your Instructions for Use.

“Water tap closed”:

no or not sufficient inlet water.

“Service”:

failure or malfunction of an electrical component.

“Clean pump”:

waste water is not pumped out.

Spin speed on display blinks:

unbalance during spinning.

The “Door open” indicator lights up, and the display shows

“End”. After about a quarter of an hour, the washing machine will

switch off completely to save energy.

1. Turn the programme selector to the “Off/O” position.

2. Close the water tap.

3. Open the door and unload the machine.

4. Leave the door ajar to allow the drum to dry.

The symbol will light up at the end of the programme if you used

too much detergent. Use less detergent next time. If the symbol

lights up and the display shows “Fod”, too much foam interrupted

the wash process; refer to the “Troubleshooting Guide” in your

Instructions for Use.

1. Press the

“Start/Pause”

button to pause the

programme. The indicator blinks.

2. Select the new programme, temperature, any options and

another spin speed if you want.

3. Press the

“Start/Pause”

button again. The new

programme continues at the same position where the

previous programme was interrupted. Do not add detergent

for this programme.

The

“Reset/Drain”

button cancels a programme before the

end.

• Press and hold the

“Reset/Drain”

button for a few

seconds; an animation appears on the display. The water is

drained; it may last some time until you can open the door.

SET CYCLE END (Finish in)

DETERGENT DOSING RECOMMENDATION

“DOOR OPEN” INDICATOR

ECO MONITOR

Eco Monitor

less more

PROGRAMME START

CHILD LOCK

FAILURE INDICATORS

PROGRAMME END

DETERGENT OVERDOSAGE INDICATOR

CHANGE PROGRAMME AND/OR OPTIONS

AFTER PROGRAMME START

RESET A RUNNING PROGRAMME

- the sensor technology adapts drum movement, water, energy and programme duration to your wash load.

Power consumption: in off-mode 0.16 W / in left-on mode 0.16 W.

Rating

More about this manual

We understand that it’s nice to have a paper manual for your Bauknecht Excellence 4470U Washing Machine. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Bauknecht. They might be able to provide an original manual. Are you looking for the manual of your Bauknecht Excellence 4470U Washing Machine in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

All manuals for Bauknecht Washing Machines
More manuals of Washing Machines

Frequently Asked Questions about Bauknecht Excellence 4470U Washing Machine

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

Related products

Manual

Bauknecht WM Style 1224 ZEN Washing Machine

Manual

Bauknecht WM Pure 7G42 Washing Machine

Manual

Bauknecht WM Care 8418 Z Washing Machine

Manual

Bauknecht WM Sense 9D43PS Washing Machine

Manual

Bauknecht WM Sense 8G43PS Washing Machine

Manual

Bauknecht WM Trend 724 ZEN Washing Machine

Manual

Bauknecht WAT Pure 32 FLD Washing Machine

Manual

Bauknecht WM Steam 7 100 Washing Machine

Related categories
