Manual

Overview of programmes aObserve table of consumption values on Page 8 and instructions on Page 6!

The programmes are time-controlled for lightly soiled textiles. If textiles are heavily soiled, reduce the load or select additional function, e.g. 1eco

When washing at maximum load using programmes marked with *, always select 1eco

, additional function.

Irrespective of the type of washing, sintéticos (Easy-Care) 40 °C at max. selectable spin speed is best suited as a short programme.

Programmes without Prewash – pour detergent into dispenser II, programmes with Prewash – divide detergent between dispensers I and II.

Programmes °C max.

Type of washing

Additonal functions; information

algodón/algodão (Cotton) : – 90 °C

7 kg *

Hard-wearing textiles, heat-resistant textiles made of

cotton or linen

1eco

, prelav. (Prewash),  menos (Less Ironing),extra (Extra

Rinse)

algodón/algodão eco

(Cotton eco

)

: – 60 °C

power wash 60 min : – 60 °C 5 kg Hardwearing textiles made of cotton or blended fabrics Time-controlled programme, short programme for normally soiled washing.

sintéticos (Easy-Care) : – 60 °C

3.5 kg *

Easy-Care textiles made of cotton, linen, synthetic fibres

or blended fabrics

1eco

, Prewash, Less Ironing, Extra Rinse

mix (Mixed Fabrics) : – 40 °C Textiles made of cotton or easy-care textiles

1eco

, Prewash, Less Ironing, Extra Rinse

Different types of washing can be washed together

sintético plus

(Easy-Care Dark)

: – 40 °C Dark textiles made of cotton and dark easy-care textiles

1eco

, Prewash, Less Ironing, Extra Rinse

Reduced rinse and final spin cycle

camisas (Shirts/Business) : – 60 °C

2 kg

Non-iron shirts made of cotton, linen, synthetics fibres or

blended fabrics

1eco

, Prewash, Extra Rinse

Short spin only, hang up dripping wet

delicados (Delicates/Silk) : – 40 °C

Delicate, washable textiles, e.g. made of silk, satin,

synthetic fibres or blended fabrics

1eco

, Prewash, Less Ironing, Extra Rinse

No spin cycle between the rinse cycles

microfibra (Outdoor) : – 40 °C

Weather, sport and outdoor textiles also with climate

protection membrane

1eco

, Less Ironing, Extra Rinse

Reduced final spin at intervals

ÿlana/lã (Wool) : – 40 °C Hand or machine-washable wool or rich-wool textiles

Especially gentle wash programme to prevent shrinkage, longer

programme pauses (textiles rest in wash liquor)

super rápido 15 min

: – 40 °C

Easy-Care textiles made of cotton, linen, synthetic fibres

or blended fabrics

Short programme approx. 15 minutes,

suitable for lightly soiled washing

Additional programmes 5 (Rinse), 6 (Spin), 4](Empty), 6suave (Low spin)

9401/ 9000888408

*888408*

3TI74121A

Siemens Electrogeräte GmbH

Carl-Wery-Str. 34

81739 München/Deutschland

Safety instructions

– Read and follow the operating and installation instructions and all other information enclosed with the washing

machine.

– Retain documents for subsequent use.

Risk of electric shock – Never pull out the mains plug by tugging the power cord!

– Insert/pull out the mains plug with dry hands only.

Danger to life On redundant appliances:

– Pull out the mains plug!

– Sever the power cord and discard together with the plug.

– Destroy the lock on the washing-machine door. This will prevent children from

locking themselves in and suffocating.

Risk of suffocation – Keep packaging, plastic film and packaging parts out of the reach of children.

Risk of poisioning – Keep detergents and care products out of the reach of children.

Risk of explosion – Caused by detergents containing solvents, e.g. stain remover/items of washing

pretreated with solvent naphtha may result in an explosion after being loaded into

the washing machine.

Before hand thoroughly rinse items of washing by hand.

Risk of injury – Washing machine door may become very hot.

– Caution when draining hot detergent solution.

– Do not climb on the washing machine.

– Do not lean on the open washing machine door.

– Do not reach into the drum in case it is still rotating.

Consumption values

Programme

Additonal

function

Load Current

*** Water***

Programme

duration***

algodón/ algodão cold (Cotton) :- 7 kg 0,17 kWh 77 l 1@ h

algodón/algodão (Cotton) 20 °C –

7 kg 0,21 kWh 77 l 1@ h

algodón/algodão (Cotton) 40 °C*

1eco

7 kg 0,78 kWh 77 l 2@ h

algodón/algodão (Cotton) 60 °C –

7 kg 1,30 kWh 77 l 1Bh

algodón/algodão (Cotton) 90 °C –

7 kg 2,26 kWh 90 l 2 h

sintéticos (Easy-Care) 40 °C*

1eco

3,5 kg 0,58 kWh 57 l 1@ h

delicados (Delicates/Silk) 30 °C –

2 kg 0,17 kWh 30 l B h

ÿlana/lã (Wool) 30 °C –

2 kg 0,20 kWh 40 l B h

* Programme setting for test according to currently valid European standard 60456.

Information about comparability tests: To test the test programmes, wash indicated load, with 1eco

additional function

and at maximum selectable spin speed.

Programme

Additonal

function

Load

Annual energy

consumption

Annual water

consumption

algodón/algodão (Cotton) 40,60°C

1eco

7/3.5 kg 218 kWh 10560 l

** Programme setting for testing and energy labelling according to directive 2010/30/EU with cold water (15 °C).

*** The values may deviate from the stated values depending on water pressure and hardness, room temperature, type and

amount of laundry, detergents used, fluctuations in the mains voltage and selected additional functions.

Insert for liquid detergent depending on model

Position insert for dosing liquid detergent:

– Completely remove detergent drawer. aPage 10

– Push insert forwards.

Do not use insert (push upwards):

– For gel-like detergents and washing powders.

– For programmes with

prelav. (Prewash) or acabado en (Finish in) option.

Care

Machine housing, control panel

– Remove detergent residue immediately.

– Wipe with a soft, damp cloth.

– Do not clean the appliance with a water jet.

Clean the detergent drawer ...

... if it contains detergent or fabric softener residue.

1. Pull out, depress insert, take out drawer all the way.

2. Take out insert: using your finger, press insert upwards.

3. Clean detergent dispenser and insert with water and a brush and dry.

4. Attach insert and lock into position (push cylinder onto guide pin).

5. Slide in the detergent dispenser.

Leave detergent drawer open so that residual water can evaporate.

Drum

Leave washing machine door open so that the drum can dry out.

Use chlorine-free cleaning agent, not steel wool.

Descaling No washing in the machine!

Not required if detergent dosed correctly. However, if this does occur, follow the instructions of the descaling agent

manufacturer. Suitable descalers can be purchased on our website or from customer service.

Information on the display panel depending on model

¨:³±Close the washing machine door properly; washing may be caught.

¨:³Å, ÉTurn on tap fully, supply hose kinked/jammed; clean filter aPage 10, water pressure too low.

¨:³µDrain pump blocked; clean drain pump. aPage 10

Drainage hose/outlet pipe blocked; clean drainage hose on the siphon. aPage 10

¨: ´Water in the base pan, appliance leaking. Call customer service!

¨: , ´, Motor fault. Call customer service. aInstallation instructions

Other displays Switch off appliance, wait 5 seconds and switch on again. If the display is indicated again,

call customer service. aInstallation instructions

– Risk of electric shock! Pull out the mains plug!

– Risk of explosion! No solvents!

Maintenance

Detergent-solution pump

Set programme selector to {stop (Off), pull out the mains plug.

1. Take the drainage hose out of the holder.

Remove sealing cap, allow detergent solution to flow out.

Put the closing cap back on the hose.

2. Carefully unscrew the pump cover (residual water).

3. Clean the interior, pump cover thread and pump housing

(fan impeller in the detergent-solution pump must rotate).

4. Reinsert and screw on pump cover. Handle is upright. Insert the drain hose into the holder.

To prevent unused detergent from flowing into the outlet during the next wash: Pour 1 litre of water into dispenser II

and start the Empty programme.

Drainage hose on the siphon

Set programme selector to {stop (Off), pull out the mains plug.

1. Loosen hose clip, carefully remove drainage hose (residual water).

2. Clean drainage hose and siphon spigot.

3. Re-attach drainage hose and secure connection point with hose clip.

Filter in the water inlet hose

Risk of electric shock!

Do not immerse Aqua-Stop safety device in water (contains electric valve).

Release water pressure in the supply hose:

1. Turn off the tap!

2. Select any programme (except 6 (Spin)/4](Empty)).

3. Select inicio/pausa+carga (Start/Pause). Leave programme for approx. 40 seconds.

4. Turn the programme selector to {

stop (Off). Pull out the mains plug.

Clean the filter:

5. Disconnect the hose from the water tap.

Clean filter with small brush.

and/or for standard and Aqua-Secure models:

Remove hose from the rear of the appliance.

Take out filter with pliers and clean.

6. Connect the hose and check for leaks.

Risk of scalding!

– Allow detergent solution to cool down!

– Turn off the tap!

What to do if …

Water is running out. – Correctly attach/replace drainage hose.

– Tighten screw-fitting on the supply hose.

Water not flowing in.

Detergent not washed in.

–

inicio/pausa+carga (Start/Pause) not selected?

– Tap not open?

– Filter blocked? Clean the filter. aPage 10

– Supply hose kinked or jammed?

Washing-machine door cannot

be opened.

– Safety function active. Stop programme? aPage 4

–  (Rinse stop = without final spin) selected? aPage 3, 4

– Can be opened via emergency release only? aPage 6

Programme does not start.

–

inicio/pausa+carga (Start/Pause) or acabado en (Finish in) time selected?

– Door closed?

Detergent solution is not drained. –  (Rinse stop = without final spin) selected? aPage 3, 4

– Clean the drain pump. aPage 10

– Clean outlet pipe and/or drainage hose.

Water not visible in the drum. – Not a fault – water below the visible area.

Spin result not satisfactory.

Washing wet/too damp.

– Not a fault – unbalanced load detection system has stopped the spin cycle,

washing unevenly distributed.

Distribute small and large items of washing in the drum.

– menos (Less Ironing) selected? aPage 5

– Too low speed selected? aPage 5

The programme duration

changes during the wash cycle.

– Not a fault – the programme sequence is optimised for the particular wash process.

This may result in changes to the programme duration in the display field.

Spin cycle actuated several

times.

– Not a fault – unbalanced load detection system adjusts imbalance.

Residual water in the dispenser

for care product ~.

– Not a fault – effect of the care product not impaired.

– If required, clean insert. aPage 9

Odour formation in the washing

machine.

– Run algodón/algodão (Cotton) 90 °C programme without washing.

Use standard detergent.

Foam is coming out of the

detergent drawer.

– Too much detergent used?

Mix 1 tablespoon of fabric softener with ½ litre of water and pour into dispenser II

(not for outdoor, sports and down-filled textiles!).

– Reduce detergent dosage for the next wash cycle.

Loud noise formation, vibrations

and “Wandering” during spin

cycle.

– Appliance feet fixed? Secure appliance feet. aInstallation instructions

– Transportation protection devices removed?

Remove transportation protection devices. aInstallation instructions

Noises during spin and drain

cycles.

– Clean the drain pump. aPage 10

Display panel/indicator lights do

not function while the appliance

is running.

– Power failure?

– Fuse tripped? Switch on/replace fuse.

– If the fault occurs repeatedly, call customer service.

The programme takes longer

than usual.

– Not a fault – unbalanced load detection system adjusts imbalance by repeatedly

distributing the washing.

– Not a fault – foam detection system active – a rinse cycle is switched on.

Detergent residue on the

washing.

– Occasionally phosphate-free detergents contain water-insoluble residue.

– Select Rinse or brush the laundry after washing.

In the pause status

inicio/pausa+carga (Start/

Pause)

flashes very quickly and a

signal sounds.

– Water level too high. Washing cannot be reloaded.

Immediately close washing machine door.

– Select

inicio/pausa+carga (Start/Pause) to continue the programme.

If a fault cannot be rectified (switching the machine on and off) or a repair is required:

– Set programme selector to {stop (Off) and pull out the mains plug.

– Turn off the tap and call customer service. aInstallation instructions

Washing machine

operating instructions

Washing

machine

Observe the safety instructions on page 8.

Read these instructions and the separate

installation instructions before operating

the washing machine.

Download manual in English (PDF, 1.99 MB)

(Consider the environment and only print this manual if it is really necessary)

Rating

Let us know what you think about the Balay 3TI74121A Washing Machine by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.

Are you satisfied with the Balay 3TI74121A Washing Machine?
Yes No

Be the first to rate this product

0 votes

Join the conversation about this product

Here you can share what you think about the Balay 3TI74121A Washing Machine. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.

José Tangeman 09-10-2023
Can I open the drum in between?

reply | This was helpful (0) (Translated by Google)

More about this manual

We understand that it’s nice to have a paper manual for your Balay 3TI74121A Washing Machine. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Balay. They might be able to provide an original manual. Are you looking for the manual of your Balay 3TI74121A Washing Machine in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

Brand	Balay
Model	3TI74121A
Category	Washing Machines
File type	PDF
File size	1.99 MB

All manuals for Balay Washing Machines
More manuals of Washing Machines

Frequently Asked Questions about Balay 3TI74121A Washing Machine

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

My washing machine won't start when I press the start-button, what can I do? Verified

In many cases the door of the washing machine hasn't closed properly. Open and close the door and try again.

This was helpful (25277) Read more

My washing machine won’t drain, what can I do? Verified

The main reason a washing machine won’t drain is because of blockage in either the pump or the drain hose. If your washing machine has access to these parts, try to remove any blockage. If this does not solve the problem or if you don’t have access to these parts you should contact a mechanic or the manufacturer.

This was helpful (24044) Read more

There is no water coming into my washing machine, what can I do? Verified

Check if the water inlet is open and if there aren't any kinks in the hose of the water inlet. If this doesn't solve the problem you should contact the manufacturer.

This was helpful (9759) Read more

The door of my washing machine won't open, what can I do? Verified

There can be several causes. The most common cause is the filter being clogged. Unplug the appliance and check the filter. Remove any blockage if necessary. The location of the filter is different depening on the model. It is also possible that there is a special lever to open the door. If these options don't help, the last option is unplug the appliance for a period of 30-60 minutes and try to open the door after that. If this doesn't work, contact the manufacturer or a mechanic.

This was helpful (8332) Read more

My washing machine makes a lot of noice and/or vibrates loudly, what can I do about that? Verified

It's possible that the washing machine has not been leveled. You can do this by adjusting the feet to make it perfectly level. The problem can also be caused by inserting to much clothes in the machine. If these are not the cause of your problem you should contact the manufacturer.

This was helpful (6947) Read more

In which compartment should the detergent go? Verified

Most washing machines have 3 compartments for detergent. These compartments are often marked with I, II and * to show where the detergent goes. Compartment I is used for a pre-wash cycle, II is for the main wash cycle and * is for fabric softener. Compartment II is used most often.

This was helpful (5104) Read more

My washing machine smells, what can I do about it? Verified

There are washing machines with self-cleaning features. If these features are not available it's possible to add 100ml of white vinegar or 100gr of soda crystals and have the washing machine run a 90 ℃ program.

This was helpful (4256) Read more

Can I connect my washing machine to a warm water outlet? Verified

Although washing machines can probably handle water intake up to 65°C, this is not recommended by most manufacturers. There are wash cycles that specifically make use of cold water. In those cases warm water can harm the results of your wash cycle. Also, many washing machines are designed to be connected to a cold water outlet.

This was helpful (3043) Read more

What should I pay attention to when moving a washing machine? Verified

When moving a washing machine, you should secure the drum. You can use the transit bolt which come with every washing machine and will prevent the drum from moving around inside the machine. You also need to drain all the water.

This was helpful (1599) Read more

Can I stack my dryer and washing machine? Verified

In general it is possible to directly stack a dryer and washing machine directly on top of each other. This only works with front loading models. However, it is advisable to use a fitting accessory to do so. This will prevent the machines from vibrating and falling off and also prevents damage to the bottom machine.

This was helpful (1355) Read more

Can I connect a washing machine to an extension cord? Verified

Appliances that require large amounts of power, like a washing machine, can not be connected to all extension cords. See what the power usage of the washing machine is, which is indicated in Watt, and check if the extension cord can handle this. There are extension cords with thicker cables that are made to handle larger appliances.

This was helpful (1315) Read more

What is the difference in usage between a washer-dryer and a separate washing machine and dryer? Verified

The biggest advantage of a washer-dryer is that it takes less space. However, a separate dryer will be able to dry more than a washer-dryer. A washer-dryer also uses relatively more energy and requires more time.

This was helpful (1315) Read more
