Manual

1 2 3 4 5

End of programme when ...

... the indicator light terminado (End) is on.

Terminating the programme

For programmes at high temperature:

– Cool washing: select 5plus (Rinse).

– Select inicio/pausa+carga (Start/Pause).

For programmes at low temperature:

– Select

6(Spin) or 4plus (Drain).

– Select

inicio/pausa+carga (Start/Pause).

Change programme if ...

... you have mistakenly selected a wrong programme:

– Reselect programme.

– Select inicio/pausa+carga (Start/Pause).

The new programme starts from the beginning.

Cancel Programme

– Select inicio/pausa+carga (Start/Pause).

– If required, top up washing (do not leave door open

for a long time – water from the washing could run out

of the open door).

– Select

inicio/pausa+carga (Start/Pause).

Correct installation according

to separate installation instructions.

Checking the machine

– Never switch on a damaged machine!

– Inform your customer service!

Insert mains plug

With dry hands only!

Take hold of the plug only!

Turn on the tap

Dispenser II: Detergent for main wash, softener,

bleach, stain remover

Sorting and inserting the washing

Follow manufacturer’s care information!

According to the information on the care labels.

According to type; colour; soiling and temperature.

Do not exceed maximum load. aPage 7

Follow important instructions! a Page 6

Insert large and small items of washing!

Close the washing machine door. Do not jam items of washing between the

washing machine door and rubber seal.

Add detergent and care product

Dose according to:

amount of washing, soiling, water hardness (available from your water utility

company) and manufacturer’s instructions.

Pour liquid detergent into corresponding dispenser and place in drum.

Caution when opening the detergent drawer while the appliance is running!

Your washing machine

Congratulations – You have opted for a modern, high-quality

domestic appliance manufactured by Balay. The washing machine is

distinguished by its economical consumption of water and energy.

Each appliance which leaves our factory is inspected thoroughly to

ensure that it functions properly and is in perfect condition.

Further information on our products, accessories, spare parts and

services can be found at: www.balay.es or contact our

customer service centres.

Intended use

Contents Page

ʋIntended use........................................................................................1

ʋProgrammes ........................................................................................1

ʋSelecting and adjusting a programme ...........................................3

ʋWashing............................................................................................3/4

ʋAfter washing.......................................................................................4

ʋIndividual settings ...............................................................................5

ʋImportant information .........................................................................6

ʋOverview of programmes..................................................................7

ʋSafety instructions...............................................................................8

ʋConsumption values...........................................................................8

ʋCare.......................................................................................................9

ʋInformation about the indicator lights .............................................9

ʋMaintenance ..................................................................................... 10

ʋWhat to do if … ................................................................................. 11

Protection of the environment/Conservation tips

– Utilise the maximum amount of washing for the particular

programme.

– Wash normally soiled washing without prewash.

– The selectable temperatures apply to the care labels on the

textiles. The temperatures in the machine may deviate from this

so that you get the optimum mix of energy-saving and washing

results.

– Measure detergent according to the manufacturer’s instructions

and water hardness.

– If the washing is then dried in the tumble dryer, select spin speed

according to the instructions of the dryer manufacturer.

Preparation

Before using your washing machine for the first time

wash once without any washing. aPage 9

Set and adjust programme

Spin

speed *

Programme selectorStart/

Pause

Programme selector for switching

the machine on and off and for

selecting the programme.

Can be rotated in either direction.

Programmes

Detailled overview of programmes aPage 7

Spin speed can be selected individually irrespective of the

selected programme and programme progress.

algodón/algodão

(Cottons)

hard-wearing textiles

algodón/algodão eco

(Cottons eco) ~

hard-wearing textiles

mix (Mixed Load) different types of washing

5plus (Rinse) extra rinse with spin

6(Spin)

washing washed by hand;

extra spin with selectable spin speed

4plus (Drain) the rinsing water when  (rinse stop =

without final spin) is activated

ÿlana/lã (Wool) hand-/machine-washable wool

delicado

(Delicates/Silk)

delicate washable textiles

sintéticos

(Easy-Care)

easy-care textiles

Additional functions and spin

speed aIndividual settings,

Page 5

Select

inicio/pausa+carga

(Start/Pause)

Washing

Detergent drawers

with dispensers I, II, ~

Door handle

Dispenser ~: Fabric softener, starch

Dispenser I: Detergent for prewash

ʋfor use in the household only,

ʋfor washing machine-washable textiles and hand-

washable wool in wash liquor,

ʋto be operated with cold drinking water and

commercially available detergents and care products

which are suitable for use in washing machines.

– Do not leave children unattended near the

washing machine!

– Children and uninstructed persons must not use

the washing machine!

– Keep pets away from the washing machine!

– Switch on washing machine only with base strip

attached

Dilute viscous fabric softener and fabric conditioner with water.

Prevents blockage of the overflow.

Individual settings

Spin speed adepending on model

You can change the indicated spin speed or select  (rinse stop = without final spin cycle,

washing remains in the water after the last rinse cycle). Effects dependent on the

programme progress.

The maximum selectable spin speed depends on the model and the set programme.

Additional functions aOverview of programmes, Page 7

1eco



(Intensive Wash)

Extension of the washing time for a more intensive washing of highly

soiled washing.

prelav. (Prewash)

For heavily soiled washing. Prewash at 30 °C.

menos

(Reduced Ironing)

Special spin sequence with subsequent fluffing. Gentle final spin

at reduced spin speed. Residual moisture of the washing slightly

increased.

extra (Extra Rinse)

Additional rinse cycle. Longer programme duration. For areas with

very soft water or for further improvement of the rinsing result.

inicio/pausa (Start/Pause)

For starting or interrupting the programme.

Signal

1 step

to right

2. Set volume for ...

1. Activate setting

mode for signal

volume

set to

1 step

to right

select and

hold

release

... Button signals ... Information signals

set to

set volume **set volume **

direct

** If required, select repeatedly

Blind mode *

ON–OFF

Optional:

ON–OFF

set to

* Long signal – function on.

Short signal – function off.

1 step

to right

intensivo

Important information

Before using your washing machine for the first time

Do not put any washing in the washing machine! Turn the tap on. Pour into dispenser II:

– approx. 1 litre of water,

– detergent (dosage according to manufacturer’s instructions for light soiling and according

to degree of water hardness).

Set programme selector to sintéticos (Easy-Care) 60 °C and select inicio/pausa+carga

(Start/Pause). At the end of the programme set the programme selector to {stop (Off).

Protecting the washing and the machine

– When dosing all detergents, cleaning aids and cleaning agents, always follow

the manufacturer's instructions.

– Empty pockets. Remove metal parts (paper clips, etc.).

– Wash delicates in the net/bag (tights, curtains, underwired bras).

– Close zips, button up covers.

– Brush sand out of pockets and collars.

– Remove curtain fittings or include in the net/bag.

Insert laundry

Insert large and small items of washing!

Do not jam items of washing between the washing machine door and rubber seal.

Washing with different degrees of soiling

Wash new items separately.

Light Do not prewash.

If required, pretreat stains. Select 1eco

 additional function.

Heavy Load less washing. Prewash. If required, pretreat stains.

Select 1eco

 (Intensive Wash) additional function.

Soaking Load washing of the same colour.

Pour soaking agent/detergent into dispenser II according to the manufacturer’s instructions.

Set programme selector to algodón/algodão (Cottons)

frio (cold)

and select inicio/pausa+carga (Start/Pause). After approx. 10 minutes select inicio/

pausa+carga (Start/Pause) to stop the programme. After the required soaking time

reselect inicio/pausa+carga (Start/Pause) if the programme is to be continued or

change the programme.

Starching Washing should not be treated with fabric softener.

Liquid starch can be used in all wash programmes. Pour starch into the fabric softener

dispenser ~ according to manufacturer’s specifications (if required clean beforehand).

Dyeing/Bleaching

Dye in household quantities only. Salt may attack stainless steel! Observe specifications of

the dye manufacturer! Do not bleach washing in the washing machine!

Emergency release e.g. if power failure occurs

The programme continues running when the power supply is restored.

If the washing is still to be removed, the door can be opened as described below:

Risk of scalding!

Detergent solution and washing may be hot. If required, leave to

cool down.

Do not reach into the drum in case it is still rotating.

Do not open the door if you can still see water through the glass.

1. Set programme selector to {stop (Off), pull out the mains plug.

2. Removing base strip a see separate installation instructions.

3. Drain the water. aPage 10

4. Pull down emergency release with a tool and release.

Door can then be opened.

5. Attaching base strip a see separate installation instructions.

Additional

functions

Door

Fascia

Status

displays

Switching off

Turn the programme selector to {stop (Off).

Turn off tap

Not required for Aqua-Stop models. aInformation,

Installation Instructions

Remove the washing

Open washing machine door and remove washing.

If  (rinse stop = without final spin) active:

Set programme selector to 4plus (Drain) or

6(Spin).

Select

inicio/pausa+carga (Start/Pause).

– Remove any foreign objects – risk of rusting.

– Leave detergent drawer and door open so that

residual water can evaporate.

(* depending on model)

Emergency lock release

Detergent-solution pump

Drainage hose

Rating

Let us know what you think about the Balay 3TI71102A Washing Machine by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.

Are you satisfied with the Balay 3TI71102A Washing Machine?
Yes No

Be the first to rate this product

0 votes

Join the conversation about this product

Here you can share what you think about the Balay 3TI71102A Washing Machine. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.

More about this manual

We understand that it’s nice to have a paper manual for your Balay 3TI71102A Washing Machine. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Balay. They might be able to provide an original manual. Are you looking for the manual of your Balay 3TI71102A Washing Machine in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

Brand	Balay
Model	3TI71102A
Category	Washing Machines
File type	PDF
File size	1.8 MB

All manuals for Balay Washing Machines
More manuals of Washing Machines

Frequently Asked Questions about Balay 3TI71102A Washing Machine

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

My washing machine won't start when I press the start-button, what can I do? Verified

In many cases the door of the washing machine hasn't closed properly. Open and close the door and try again.

This was helpful (23020) Read more

My washing machine won’t drain, what can I do? Verified

The main reason a washing machine won’t drain is because of blockage in either the pump or the drain hose. If your washing machine has access to these parts, try to remove any blockage. If this does not solve the problem or if you don’t have access to these parts you should contact a mechanic or the manufacturer.

This was helpful (22428) Read more

There is no water coming into my washing machine, what can I do? Verified

Check if the water inlet is open and if there aren't any kinks in the hose of the water inlet. If this doesn't solve the problem you should contact the manufacturer.

This was helpful (8855) Read more

The door of my washing machine won't open, what can I do? Verified

There can be several causes. The most common cause is the filter being clogged. Unplug the appliance and check the filter. Remove any blockage if necessary. The location of the filter is different depening on the model. It is also possible that there is a special lever to open the door. If these options don't help, the last option is unplug the appliance for a period of 30-60 minutes and try to open the door after that. If this doesn't work, contact the manufacturer or a mechanic.

This was helpful (7329) Read more

My washing machine makes a lot of noice and/or vibrates loudly, what can I do about that? Verified

It's possible that the washing machine has not been leveled. You can do this by adjusting the feet to make it perfectly level. The problem can also be caused by inserting to much clothes in the machine. If these are not the cause of your problem you should contact the manufacturer.

This was helpful (6348) Read more

In which compartment should the detergent go? Verified

Most washing machines have 3 compartments for detergent. These compartments are often marked with I, II and * to show where the detergent goes. Compartment I is used for a pre-wash cycle, II is for the main wash cycle and * is for fabric softener. Compartment II is used most often.

This was helpful (4327) Read more

My washing machine smells, what can I do about it? Verified

There are washing machines with self-cleaning features. If these features are not available it's possible to add 100ml of white vinegar or 100gr of soda crystals and have the washing machine run a 90 ℃ program.

This was helpful (3540) Read more

Can I connect my washing machine to a warm water outlet? Verified

Although washing machines can probably handle water intake up to 65°C, this is not recommended by most manufacturers. There are wash cycles that specifically make use of cold water. In those cases warm water can harm the results of your wash cycle. Also, many washing machines are designed to be connected to a cold water outlet.

This was helpful (2830) Read more

What should I pay attention to when moving a washing machine? Verified

When moving a washing machine, you should secure the drum. You can use the transit bolt which come with every washing machine and will prevent the drum from moving around inside the machine. You also need to drain all the water.

This was helpful (1390) Read more

What is the difference in usage between a washer-dryer and a separate washing machine and dryer? Verified

The biggest advantage of a washer-dryer is that it takes less space. However, a separate dryer will be able to dry more than a washer-dryer. A washer-dryer also uses relatively more energy and requires more time.

This was helpful (1094) Read more

Can I connect a washing machine to an extension cord? Verified

Appliances that require large amounts of power, like a washing machine, can not be connected to all extension cords. See what the power usage of the washing machine is, which is indicated in Watt, and check if the extension cord can handle this. There are extension cords with thicker cables that are made to handle larger appliances.

This was helpful (1093) Read more

Can I stack my dryer and washing machine? Verified

In general it is possible to directly stack a dryer and washing machine directly on top of each other. This only works with front loading models. However, it is advisable to use a fitting accessory to do so. This will prevent the machines from vibrating and falling off and also prevents damage to the bottom machine.

This was helpful (1093) Read more
