POSSIBILITIES FOR

INSERTION

Kitchen unit with door

Proper arrangements must be

taken in designing the forniture

unit, in order to avoid any contact

with the bottom of the hob which

can be heated when it is operated.

The recommended solution is

shown in Fig. 12.

The panel fitted under the hob

should be easily removable to

allow an easy access if a technical

assistance intervention is needed.

Kitchen unit with oven

The hob recess dimensions must

comply the indication given in

Figs. 13 and 16 and must be

provided with brackets to allow a

continuous supply of air.

To avoid overhating, the building

in should be carried out as shown

in Figs. 14 and 15.

The hob's electric connection and

the oven's one must be carried out

separately, both for safety reasons

and to allow the oven to be easily

taken off the unit.

Hanging forniture units or hoods

must be placed at 650 mm.

minimum from the hob (Fig. 17).

a) Removable panel

b) Space possibly useful for

connections

550 min.

560 min.

Fig. 12

Fig. 13

Fig. 14

Fig. 15

Fig. 16

Fig. 17

FO 2103 FO 1017

FO 2104

FO 2105

FO 0198

FO 2150

20 min

50 cm

360 cm

120 cm

180 cm

490

591

380

140

650 min
