Manual

COOKTOP USE

The control knobs can be set to anywhere between Hi and Lo.

Push in and turn to setting.

Ceramic Glass

The surface cooking area will glow red when an element is on.

Some parts of the surface cooking area may not glow red when

an element is on. This is normal operation. The burner will cycle

on and off to maintain the selected heat level. It will also randomly

cycle off and back on again even while in Hi to keep the cooktop

from extreme temperatures.

It is normal for the surface of light colored ceramic glass to appear

to change color when surface cooking areas are hot. As the glass

cools, it will return to its original color.

Clean the cooktop after each use to help avoid scratches, pitting,

abrasions and to condition the glass surface. Ceramic glass

cooktop cleaner and a cooktop scraper are also recommended

for stubborn soils. Do not use abrasive cleaners, cleaning pads, or

harsh chemicals for cleaning. The Cooktop Care Kit Part Number

31605 contains all of the items needed to clean and condition

your ceramic glass cooktop. Refer to the “Range Care” section

for additional information.

IMPORTANT: To avoid permanent damage to the cooktop surface

and to make soils easier to remove, clean the cooktop after each

use to remove all soils.

■ Avoid storing jars or cans above the cooktop. Dropping

a heavy or hard object onto the cooktop could crack the

cooktop.

■ To avoid damage to the cooktop, do not leave a hot lid on

the cooktop. As the cooktop cools, air can become trapped

between the lid and the cooktop and the ceramic glass could

break when the lid is removed.

■ For foods containing sugar in any form, clean up all spills and

soils as soon as possible. Allow the cooktop to cool down

slightly. Then, while wearing oven mitts, remove the spills

using a scraper while the surface is still warm. If sugary spills

are allowed to cool down, they can adhere to the cooktop and

can cause pitting and permanent marks.

■ To avoid scratches, do not slide cookware or bakeware across

the cooktop. Aluminum or copper bottoms and rough ﬁnishes

on cookware or bakeware could leave scratches or marks on

the cooktop.

■ Do not cook popcorn in prepackaged aluminum containers on

the cooktop. They could leave aluminum marks that cannot be

removed completely.

■ To avoid damage to the cooktop, do not allow objects that

could melt, such as plastic or aluminum foil, to touch any part

of the entire cooktop.

■ To avoid damage to the cooktop, do not use the cooktop as a

cutting board.

■ Use cookware about the same size as the surface cooking

area. Cookware should not extend more than 1/2" (13 mm)

outside the area.

■ Use ﬂat-bottomed cookware for best heat conduction and

energy efﬁciency. Cookware with rounded, warped, ribbed, or

dented bottoms could cause uneven heating and poor cooking

results.

■ Determine ﬂatness by placing the straight edge of a ruler

across the bottom of the cookware. While you rotate the

ruler, no space or light should be visible between it and the

cookware.

■ Cookware designed with slightly indented bottoms or small

expansion channels can be used.

■ Make sure the bottoms of pots and pans are clean and dry

before using them. Residue and water can leave deposits

when heated.

WARNING

Fire Hazard

Turn off all controls when done cooking.

Failure to do so can result in death or fire.

REMEMBER: When range is in use, the entire cooktop area

may become hot.

A. Surface cooking area

B. Cookware/canner

C. 1/2" (13 mm) maximum overhang

Keypad Feature Instructions

CONTROL

LOCK

Oven and

cooktop control

lockout

1. Check that the oven and cooktop are off.

2. Press and hold CONTROL LOCK for 3 seconds.

A tone will sound and a lock will be displayed.

3. Repeat to unlock. No keypads will function with the controls locked.

NOTE: The control lock cannot be activated or deactivated while the Hot Surface indicator light is

on. Wait for the Hot Surface indicator light to turn off before activating or deactivating the control

lock.

AQUALIFT

SELF CLEAN

Self-Cleaning

cycle

See the “Self-Cleaning Cycle” section.
