Manual Whirlpool WS68V8CCXT Range

Need a manual for your Whirlpool WS68V8CCXT Range? Below you can view and download the PDF manual for free in English. This product currently has 9 frequently asked questions, 0 comments and has 0 votes. If this is not the manual you want, please contact us.

Is your product defective and the manual offers no solution? Go to a Repair Café for free repair services.

Manual

Before operating your new appliance please read

this instruction booklet carefully. It contains

important information concerning the safe installation

and operation of the appliance.

Please keep these operating instructions for future

reference. Make sure that the instructions are kept

with the appliance if it is sold, given away or moved.

The appliance must be installed by a qualified

professional according to the instructions provided.

Any necessary adjustment or maintenance must be

performed after the appliance has been

disconnected from the electricity supply.

Positioning and levelling

It is possible to install the appliance alongside

cupboards whose height does not exceed that of the

hob surface.

This cooker should be installed directly on

. Do not install this cooker on an

artificial base of any kind.

Make sure that the wall in contact with the back of

the appliance is made from a non-flammable, heat-

resistant material (T 90°C).

Important: Do not install this appliance

adjacent to the door or other means ofadjacent to the door or other means of

access to minimise the likelihood of personsaccess to minimise the likelihood of persons

using the door making contact with pans on

the hob surface.the hob surface.

conductor.

WARNING : This operation must be perfomed

by a qualified technician

Important: Do not install this appliance

INSTALLATIONINSTALLATIONINSTALLATIONINSTALLATIONINSTALLATION

This appliance must not be fitted on a platform.

The cooker is designed to fit between kitchen cabinets

spaced 600mm apart. The space either side need

only be sufficient to allow withdrawal of the cooker for

servicing. It can be used with cabinets one side or

both as well as in a corner setting. It can also be used

free-standing.

Adjacent side walls which project above hob level,

must not be nearer to the cooker than 150mm

and should be protected by heat resistant

material. Any overhanging surface or cooker hood

should not be nearer than 650mm.

a. The cooker may be located in a kitchen, a kitchen/

diner or bed sitting room, but not in a bathroom or

shower room.

b. The hoods must be installed according to the

requirements in the hood handbook.

c. The wall in contact with the back of the cooker must

be of flameproof material.

d. The cooker is fitted with a safety chain that must be

attached to a hook, secured to the wall behind the

appliance.

The appliance must not be installed behind

a decorative door in order to avoid overheating

Electrical connection

Ovens with a three-pole power supply cable are

designed to operate with alternated current at the

supply frequency and voltage indicated on the data

plate (at the bottom of the oven dashboard). The

earthing conductor of the cable is the yellow-green

conductor.

Connecting the supply cable to the mains

Before moving your cooker check that it is cool, and

your cooker is most easily achieved by lifting the

front as follows:

Open the grill door sufficiently to allow a comfortable

grip on the underside front edge of the oven roof,

avoiding any grill elements. (FIG.A)

Take care in moving the cooker as it is heavy.

Take care to ensure that any floor covering is not

damaged.

The following instructions should be read by a

qualified technician to ensure that the appliance is

installed, regulated and technically serviced

correctly in compliance with current regulations.

Before moving your cooker check that it is cool, and

switched off at the cooker control unit. Movement of

your cooker is most easily achieved by lifting the

front as follows:

Open the grill door sufficiently to allow a comfortable

grip on the underside front edge of the oven roof,

avoiding any grill elements. (FIG.A)

Take care in moving the cooker as it is heavy.

Take care to ensure that any floor covering is not

damaged.

The following instructions should be read by a

qualified technician to ensure that the appliance is

installed, regulated and technically serviced

correctly in compliance with current regulations.

WARNING : This operation must be perfomed

by a qualified technician

Important: Do not install this appliance

adjacent to the door or other means ofadjacent to the door or other means of

access to minimise the likelihood of personsaccess to minimise the likelihood of persons

using the door making contact with pans on

the hob surface.the hob surface.

Important: Do not install this appliance Important: Do not install this appliance

adjacent to the door or other means ofadjacent to the door or other means of

access to minimise the likelihood of personsaccess to minimise the likelihood of persons

using the door making contact with pans on

the hob surface.the hob surface.

Important: Do not install this appliance Important: Do not install this appliance

adjacent to the door or other means ofadjacent to the door or other means of

access to minimise the likelihood of personsaccess to minimise the likelihood of persons

using the door making contact with pans on

the hob surface.the hob surface.

Important: Do not install this appliance

. Do not install this cooker on an. Do not install this cooker on an. Do not install this cooker on an

the floor

artificial base of any kind.artificial base of any kind.artificial base of any kind.

. Do not install this cooker on an

Moving the Cooker

Fig. A

Moving the Cooker

Fig. A

switched off at the cooker control unit. Movement of

Download manual in English (PDF, 17.92 MB)

(Consider the environment and only print this manual if it is really necessary)

Rating

Let us know what you think about the Whirlpool WS68V8CCXT Range by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.

Are you satisfied with the Whirlpool WS68V8CCXT Range?
Yes No

Be the first to rate this product

0 votes

Join the conversation about this product

Here you can share what you think about the Whirlpool WS68V8CCXT Range. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.

More about this manual

We understand that it’s nice to have a paper manual for your Whirlpool WS68V8CCXT Range. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Whirlpool. They might be able to provide an original manual. Are you looking for the manual of your Whirlpool WS68V8CCXT Range in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

Brand	Whirlpool
Model	WS68V8CCXT
Category	Ranges
File type	PDF
File size	17.92 MB

All manuals for Whirlpool Ranges
More manuals of Ranges

Frequently Asked Questions about Whirlpool WS68V8CCXT Range

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

The oven in my range does not get warm enough, what should I do? Verified

The thermostat makes sure the ovens heats up to the designated temperature. It is likely that the thermostat is defective. Have it replaced. When in doubt, contact the manufacturer.

This was helpful (1209) Read more

Why does the ignition on my range make a clicking sound? Verified

If the range has ben cleaned with a lot of water, the knobs might have gotten wet, triggering the ignition. Let the knobs dry. If the problem persists you should contact the manufacturer.

This was helpful (1205) Read more

Which pans can be used on an induction range? Verified

In general all pans that are magnetic can be used on an induction range. Almost all new pans are suited for induction.

This was helpful (914) Read more

What does '6th Sense' mean? Verified

Whirlpool appliances that are equipped with 6th Sense technology have sensors that ensure optimal operation of the machine. For example in dryers, these sensors measure the moisture left in the wash and stops the machine when everything is completely dry.

This was helpful (909) Read more

My range has a power plug that doesn't fit a regular socket, what should I do? Verified

Many electric ranges (both ceramic and induction) have a different plug. This is because these appliances require a lot of power. Have the installation of the appliance done by a professional.

This was helpful (542) Read more

What is pyrolysis? Verified

Some ovens are equipped with a pyrolysis function. This is a cleaning system that burns dirt and fat in the oven by using very high temperatures. After pyrolysis, all the dirt will have turned to ash and can be easily removed. If the oven has a pyrolysis function, it is advisable to use it 3 to 4 times a year to keep the oven clean.

This was helpful (478) Read more

Can I connect a range to an extension cord? Verified

Appliances that require large amounts of power, like a range, can not be connected to all extension cords. See what the power usage of the range is, which is indicated in Watt, and check if the extension cord can handle this. There are extension cords with thicker cables that are made to handle larger appliances.

This was helpful (247) Read more

When I use the oven there often food remains that fall on the bottom, causing smoke. How can I prevent this? Verified

Many ovens come with both a grid and a baking tray. When food is prepared on the grid, the baking tray can be placed on the bottom to prevent food remains from burning and causing smoke.

This was helpful (240) Read more

Can I prepare several items simultaneously by using more grill trays? Verified

Technically this is possible. However, it depends on the type of food if you need to adjust the preparation time or swap the trays halfway during the preparation.

This was helpful (239) Read more
