1) ELECTRICAL CONNECTIONS

“Warning - this appliance must be

earthed”

This appliance is normally supplied with a

mains lead having a plug fitted in the factory

which has been checked for correct earth

continuity.

If the fitted plug is not suitable for your socket

outlet, or if the machine’s mains lead is not

fitted with a plug, you should fit a suitable new,

good quality plug by following the instructions in

(2) below.

Any unsuitable plug should be cut off and

disposed of in order to avoid a possible shock

hazard should it be inserted into a socket.

2) CONNECTION TO A REWIRABLE

PLUG - to be carried out only by a

qualified electrician

The wires in the mains lead are coloured in

accordance with the following code:

BLUE - “NEUTRAL” (“N”)

BROWN - “LIVE” (“L”)

GREEN AND YELLOW - “EARTH” (“E”)

To fit a new plug, proceed as follows:

2.1Polarized Plugs (e.g. 3 pin, 13 amp plug

conforming to BS 1363A)

The GREEN AND YELLOW wire must be

connected to the terminal in the plug which

is marked with the letter “E” or by the Earth

symbol or coloured yellow or green and

yellow.

The BLUE wire must be connected to the

terminal which is marked with the letter “N”

or coloured black.

The BROWN wire must be connected to the

terminal which is marked with the letter “L”

or coloured red.

2.2Non-polarized plugs (e.g. 2 pin with side

earth contact)

The wire which is coloured GREEN AND

YELLOW must be connected to the earth

contact. The other two wires should be

connected to the two pins, irrespective of

colour.

3) FUSE REPLACEMENT

If the mains lead of this appliance is fitted with

a BS 1363A 13 amp fused plug, replace the

fuse only with an A.S.T.A. approved type

conforming to BS 1362 and proceed as follows:

Remove the fuse cover (

) and the fuse

(

Fit the replacement 13 A fuse into the fuse

cover.

Refit both into the plug.

For all other types of plug, the supply socket

should be protected by a 16 A fuse or circuit

breaker at the distribution board.

ELECTRICAL CONNECTION
